BAS79A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BAS79A

BAS79A: Description1 A, 2 ELEMENT, SILICON, SIGNAL DIODE; CategoryDiscrete semiconductor diode; File Size66KB，3 Pages; ManufacturerSIEMENS; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

BAS79A Overview

1 A, 2 ELEMENT, SILICON, SIGNAL DIODE

BAS79A Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SIEMENS
package instruction	R-PSSO-G3
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	CATHODE
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	2 V
JESD-30 code	R-PSSO-G3
JESD-609 code	e0
Number of components	2
Number of terminals	3
Maximum operating temperature	25 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum power dissipation	1.2 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	50 V
Maximum reverse current	1 µA
Maximum reverse recovery time	1 µs
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	SINGLE
Base Number Matches	1

Preview

Download Datasheet

View All

Silicon Switching Diodes

BAS 79 A

… BAS 79 D

Switching applications

High breakdown voltage

Common cathode

Type

BAS 79 A

BAS 79 B

BAS 79 C

BAS 79 D

Marking

BAS 79 A

BAS 79 B

BAS 79 C

BAS 79 D

Ordering Code

(tape and reel)

Q62702-A914

Q62702-A915

Q62702-A916

Q62702-A917

Pin Configuration

Package

SOT-223

Maximum Ratings

Parameter

Symbol

BAS

79 A

Reverse voltage

Peak reverse voltage

Forward current

Peak forward current

Surge forward current,

= 1

Total power dissipation,

= 114 ˚C

Junction temperature

Storage temperature range

Thermal Resistance

Junction - ambient

Junction - soldering point

Values

BAS

79 B

79 C

100

1.2

150

– 65 … + 150

200

Unit

BAS

79 D

400

tot

stg

˚C

th JA

th JS

≤

170

≤

K/W

For detailed information see chapter Package Outlines.

Package mounted on epoxy pcb 40 mm

40 mm

1.5 mm/6 cm

Cu.

Semiconductor Group

5.91
