BAS78C datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BAS78C

BAS78C: Description1 A, SILICON, SIGNAL DIODE; CategoryDiscrete semiconductor diode; File Size66KB，3 Pages; ManufacturerSIEMENS; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

BAS78C Overview

1 A, SILICON, SIGNAL DIODE

BAS78C Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SIEMENS
package instruction	R-PSSO-G3
Reach Compliance Code	unknown
ECCN code	EAR99
Shell connection	CATHODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	2 V
JESD-30 code	R-PSSO-G3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	25 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum power dissipation	1.2 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	200 V
Maximum reverse current	1 µA
Maximum reverse recovery time	1 µs
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal location	SINGLE
Base Number Matches	1

Preview

Download Datasheet

View All

Silicon Switching Diodes

BAS 78 A

… BAS 78 D

Switching applications

High breakdown voltage

Type

BAS 78 A

BAS 78 B

BAS 78 C

BAS 78 D

Marking

BAS 78 A

BAS 78 B

BAS 78 C

BAS 78 D

Ordering Code

(tape and reel)

Q62702-A910

Q62702-A911

Q62702-A912

Q62702-A913

Pin Configuration

Package

SOT-223

Maximum Ratings

Parameter

Symbol

BAS

78 A

Reverse voltage

Peak reverse voltage

Forward current

Peak forward current

Surge forward current,

= 1

Total power dissipation,

124 ˚C

Junction temperature

Storage temperature range

Thermal Resistance

Junction - ambient

Junction - soldering point

th JA

th JS

≤

Values

BAS

78 B

78 C

100

1.2

150

– 65 … + 150

200

Unit

BAS

78 D

400

tot

stg

˚C

K/W

For detailed information see chapter Package Outlines.

Package mounted on epoxy pcb 40 mm

40 mm

1.5 mm/6 cm

Cu.

Semiconductor Group

5.91
