FNA25012A
1200 V Motion SPM
)
2 Series
The FNA25012A is a Motion SPM
®
2 module providing
a fully−featured, high−performance inverter output stage for AC
induction, BLDC, and PMSM motors. These modules integrate
optimized gate drive of the built−in IGBTs to minimize EMI and
losses, while also providing multiple on−module protection features:
under−voltage lockouts, over−current shutdown, temperature sensing,
and fault reporting. The built−in, high−speed HVIC requires only
a single supply voltage and translates the incoming logic−level gate
inputs to high−voltage, high−current drive signals to properly drive the
module’s internal IGBTs. Separate negative IGBT terminals are
available for each phase to support the widest variety of control
algorithms.
Features
General Description
www.onsemi.com
•
1200 V
−
50 A 3−Phase IGBT Inverter, Including Control Ics for
•
•
•
•
•
•
•
•
Gate Drive and Protections
Low−Loss, Short−Circuit−Rated IGBTs
Very Low Thermal Resistance Using AIN DBC Substrate
Built−In Bootstrap Diodes and Dedicated Vs Pins Simplify PCB
Layout
Separate Open−Emitter Pins from Low−Side IGBTs for Three−Phase
Current Sensing
Single−Grounded Power Supply Supported
Built−In NTC Thermistor for Temperature Monitoring and
Management
Adjustable Over−Current Protection via Integrated Sense−IGBTs
Isolation Rating of 2500 Vrms/1 min.
SPMCA−A34/34 LD, PDD STD, DBC DIP TYPE
CASE MODFQ
Figure 1. 3D Package Drawing
(Click to Activate 3D Content)
MARKING DIAGRAM
Applications
•
Motion Control
−
Industrial Motor (AC 400 V Class)
Related Resources
FNA25012A
XXX YWW
•
AN9075
−
Users Guide for 1200 V SPM
®
2 Series
•
AN9076
−
Mounting Guide for New SPM
®
2 Package
•
AN9079
−
Thermal Performance of 1200 V Motion SPM
®
2 Series
by Mounting Torque
FNA25012A
XXX
YWW
= Specific Device Code
= Lot Code
= Work Week Code
ORDERING INFORMATION
See detailed ordering and shipping information on page 2 of
this data sheet.
©
Semiconductor Components Industries, LLC, 2018
October, 2018
−
Rev. 3
1
Publication Order Number:
FNA25012A/D
FNA25012A
PACKAGE MARKING AND ORDERING INFORMATION
Device
FNA25012A
Device Marking
FNA25012A
Package
SPMCB−A34
Packing Type
Rail
Quantity
6
Integrated Power Functions
•
1200 V
−
50 A IGBT inverter for three−phase DC/AC power conversion (Refer to Figure 3)
Integrated Drive, Protection and System Control Functions
•
For inverter high−side IGBTs: gate−drive circuit, high−voltage isolated high−speed level shifting control circuit,
Under−Voltage Lock−Out Protection (UVLO), Available bootstrap circuit example is given in Figures 5 and 15
•
For inverter low−side IGBTs: gate−drive circuit, Short−Circuit Protection (SCP) control circuit, Under−Voltage
Lock−Out Protection (UVLO)
•
Fault signaling: corresponding to UV (low−side supply) and SC faults
•
Input interface: active−HIGH interface, works with 3.3/5 V logic, Schmitt−trigger input
PIN CONFIGURATION
(34) V
S(W)
(33) V
B(W)
(1) P
(32) V
BD(W)
(31) V
CC(WH)
(30) IN
(WH)
(29) V
S(V)
(28) V
B(V)
(27) V
BD(V)
(26) V
CC(VH)
(25) IN
(VH)
(24) V
S(U)
(23) V
B(U)
(22) V
BD(U)
(21) V
CC(UH)
(20) COM
(H)
(19) IN
(UH)
(18) R
SC
(5) N
W
(6) N
V
(7) N
U
(8) R
TH
(9) V
TH
(17) C
SC
(16) C
FOD
(15) V
FO
(14) IN
(WL)
(13) IN
(VL)
(12) IN
(UL)
(11) COM
(L)
(10) VCC
(L)
(2) W
(3) V
Case Temperature (T
C
)
Detecting Point
(4) U
Figure 2. Top View
www.onsemi.com
2
FNA25012A
PIN DESCRIPTIONS
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Pin Name
P
)
W
V
U
N
W
N
V
N
U
R
TH
V
TH
V
CC(L)
COM
(L)
IN
(UL)
IN
(VL)
IN
(WL)
V
FO
C
FOD
C
SC
R
SC
IN
(UH)
COM
(H)
V
CC(UH)
V
BD(U)
V
B(U)
V
S(U)
IN
(VH)
V
CC(VH)
V
BD(V)
V
B(V)
V
S(V)
IN
(WH)
V
CC(WH)
V
BD(W)
V
B(W)
V
S(W)
Positive DC−Link Input
Output for W−Phase
Output for V−Phase
Output for U−Phase
Negative DC−Link Input for W−Phase
Negative DC−Link Input for V−Phase
Negative DC−Link Input for U−Phase
Series Resistor for Thermistor (Temperature Detection)
Thermistor Bias Voltage
Low−Side Bias Voltage for IC and IGBTs Driving
Low−Side Common Supply Ground
Signal Input for High−Side U−Phase
Signal Input for High−Side V−Phase
Signal Input for High−Side W−Phase
Fault Output
Capacitor for Fault Output Duration Selection
Capacitor (Low−Pass Filter) for Short−Circuit Current Detection Input
Resistor for Short−Circuit Current Detection
Signal Input for High−Side U Phase
High−Side Common Supply Ground
High−Side Bias Voltage for U Phase IC
Anode of Bootstrap Diode for U Phase High−Side Bootstrap Circuit
High−Side Bias Voltage for U Phase IGBT Driving
High−Side Bias Voltage Ground for U Phase IGBT Driving
Signal Input for High−Side V Phase
High−Side Bias Voltage for V Phase IC
Anode of Bootstrap Diode for V Phase High−Side Bootstrap Circuit
High−Side Bias Voltage for V Phase IGBT Driving
High−Side Bias Voltage Ground for V Phase IGBT Driving
Signal Input for High−Side W Phase
High−Side Bias Voltage for W Phase IC
Anode of Bootstrap Diode for W Phase High−Side Bootstrap Circuit
High−Side Bias Voltage for W Phase IGBT Driving
High−Side Bias Voltage Ground for W Phase IGBT Driving
Pin Description
www.onsemi.com
3
FNA25012A
INTERNAL EQUIVALENT CIRCUIT AND INPUT/OUTPUT PINS
(1) P
V
B
V
CC
OUT
IN
(33) V
B(W)
(32) V
BD(W)
(31) V
CC(WH)
(30) IN
(WH)
(34) V
S(W)
(28) V
B(V)
(27) V
BD(V)
(26) V
CC(VH)
(25) IN
(VH)
(29) V
S(V)
(23) V
B(U)
(22) V
BD(U)
(21) V
CC(UH)
(20) COM
(H)
(19) IN
(UH)
(24) V
S(U)
(17) C
SC
(16) C
FOD
(15) V
FO
(14) IN
(WL)
(13) IN
(VL)
(12) IN
(UL)
(11) COM
(L)
(10) VCC
(L)
HVIC
OUT
V
S
(2) W
V
B
V
CC
OUT
IN
HVIC
OUT
V
S
(3) V
V
B
V
CC
OUT
IN
HVIC
OUT
V
S
(4) U
C
SC
C
FOD
V
FO
IN
IN
IN
COM
V
CC
OUT
(5) N
W
LVIC
OUT
(6) N
V
OUT
Thermistor
(18) R
SC
(7) N
U
(8) R
TH
(9) V
TH
NOTES:
1. Inverter high−side is composed of three normal−IGBTs, freewheeling diodes, and one control IC for each IGBT.
2. Inverter low−side is composed of three sense−IGBTs, freewheeling diodes, and one control IC for each IGBT. It has gate drive and
protection functions.
3. Inverter power side is composed of four inverter DC−link input terminals and three inverter output terminals.
Figure 3. Internal Block Diagram
www.onsemi.com
4
FNA25012A
ABSOLUTE MAXIMUM RATINGS
(T
J
= 25°C unless otherwise noted)
INVERTER PART
Symbol
V
PN
V
PN(Surge)
V
CES
±I
C
±I
CP
P
C
T
J
Supply Voltage
Supply Voltage (Surge)
Collector−Emitter Voltage
Each IGBT Collector Current
Each IGBT Collector Current (Peak)
Collector Dissipation
Operating Junction Temperature
T
C
= 25°C, T
J
=150°C
(Note 4)
Parameter
Conditions
Applied between P−N
U
, N
V
, N
W
Applied between P−N
U
, N
V
, N
W
Rating
900
1000
1200
50
75
347
−40∼150
Unit
V
V
V
A
A
W
°C
T
C
= 25°C, T
J
=150°C, Under 1 ms
Pulse Width
(Note 4)
T
C
=25°C per One Chip
(Note 4)
CONTROL PART
Symbol
V
CC
V
BS
V
IN
V
FO
I
FO
V
SC
Parameter
Control Supply Voltage
High−Side Control Bias Voltage
Input Signal Voltage
Fault Output Supply Voltage
Fault Output Current
Current Sensing Input Voltage
Conditions
Applied between V
CC(H)
, V
CC(L)
−COM
Applied between V
B(U)
−V
S(U)
,
V
B(V)
−V
S(V)
, V
B(W)
−V
S(W)
Applied between IN
(UH)
, IN
(VH)
, IN
(WH)
,
IN
(UL)
, IN
(VL)
, IN
(WL)
−COM
Applied between V
FO
−COM
Sink Current at V
FO
pin
Applied between C
SC
−COM
Rating
20
20
−0.3∼V
CC
+0.3
−0.3∼V
CC
+0.3
2
−0.3∼V
CC
+0.3
Unit
V
V
V
V
mA
V
BOOTSTRAP DIODE PART
Symbol
V
RRM
I
F
I
FP
T
J
Parameter
Maximum Repetitive Reverse Voltage
Forward Current
Forward Current (Peak)
Operating Junction Temperature
T
C
= 25°C, T
J
≤150°C
(Note 4)
Conditions
Rating
1200
1.0
2.0
−40∼150
Unit
V
A
A
°C
T
C
= 25°C, T
J
=150°C, Under 1 ms
Pulse Width
(Note 4)
TOTAL SYSTEM
Symbol
V
PN(PROT)
T
C
T
STG
V
ISO
Parameter
Self Protection Supply Voltage Limit
(Short Circuit Protection Capability)
Module Case Operation Temperature
Storage Temperature
Isolation Voltage
60 Hz, Sinusoidal, AC 1 minute,
Connection Pins to Heat Sink Plate
Conditions
V
CC
= V
BS
= 13.5∼16.5 V, T
J
= 150°C,
V
CES
= < 1200 V, Non−repetitive, < 2
ms
See Figure 2
Rating
800
−40∼125
−40∼125
2500
Unit
V
°C
°C
V
rms
THERMAL RESISTANCE
Symbol
R
th(j−c)Q
R
th(j−c)F
Parameter
Junction to Case Thermal
Resistance
(Note 5)
Conditions
Inverter IGBT part (per 1/6 module)
Inverter FWD part (per 1/6 module)
Min.
−
−
Typ.
−
−
Max.
0.36
0.66
Unit
°C/W
°C/W
4. These values had been made an acquisition by the calculation considered to design factor.
5. For the measurement point of case temperature (T
C
), please refer to Figure 2.
www.onsemi.com
5
