PM7545GPZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> PM7545GPZ

PM7545GPZ: DescriptionD/A Converter, 1 Func, Parallel, Word Input Loading, PDIP20, 0.300 INCH, PLASTIC, DIP-20; CategoryAnalog mixed-signal IC converter; File Size1MB，13 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/; Environmental Compliance

Download Datasheet Parametric View All

PM7545GPZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	PM7545GPZ	-	-	View	Buy Now

PM7545GPZ Overview

D/A Converter, 1 Func, Parallel, Word Input Loading, PDIP20, 0.300 INCH, PLASTIC, DIP-20

PM7545GPZ Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	conform to
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	20
Reach Compliance Code	unknow
Maximum analog output voltage	15 V
Minimum analog output voltage
Converter type	D/A CONVERTER
Enter bit code	BINARY, 2\'S COMPLEMENT BINARY
Input format	PARALLEL, WORD
JESD-30 code	R-PDIP-T20
JESD-609 code	e3
length	25.2 mm
Maximum linear error (EL)	0.012%
Number of digits	12
Number of functions	1
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	5.33 mm
Nominal supply voltage	15 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm
