The DG401B, DG403B, DG405B monolithic analog switches
are replacements for the popular DG401/403/405 analog
switches and provide improved performance, combining
high speed (t
ON
: 100 ns, typ) with low power consumption
make the DG401B series ideal for portable and battery
powered applications.
Built on the Vishay Siliconix proprietary high-voltage silicon-
gate process to achieve high voltage rating and superior
switch
on/off
performance,
break-before-make
is
guaranteed for the SPDT configurations.
Each switch conducts equally well in both directions when
on, and blocks up to 30 V peak-to-peak when off.
On-resistance is very flat over the full ± 15 V analog range.
The DG401B has two independent SPST switches. The
DG403B has four SPST switches in NO/NC combinations.
The DG405B has four switches in two SPST pairs (see
Functional Block Diagrams and Pin Configurations on pages
1 and 2.)
The DG401B, DG403B, DG405B is available in both 16-pin
plastic dip and 16-pin SOIC packages.
As a committed partner to the community and the
environment, Vishay Siliconix manufactures this product
with the lead (Pb)-free device terminations. For analog
switching products manufactured with 100 % matte tin
device terminations, the lead (Pb)-free “-E3” suffix is being
used as a designator.
FEATURES
•
•
•
•
•
•
•
•
44 V supply max rating
± 15 V analog signal range
On-resistance - R
DS(on)
: 23
Low leakage - I
D(on)
: 40 pA
Fast switching - t
ON
: 100 ns
Upgrade to DG401B, DG403B, DG405B
TTL, CMOS compatible
Single supply capability
BENEFITS
• Wide dynamic range
• Break-before-make switching action
(DG403B only)
• Simple interfacing
APPLICATIONS
•
•
•
•
Audio and video switching
Sample-and-hold circuits
Test equipment
PBX, PABX
FUNCTIONAL BLOCK DIAGRAM AND PIN CONFIGURATION
DG401B
Dual-In-Line and SOIC
D
1
NC
NC
NC
NC
NC
NC
D
2
1
2
3
4
5
6
7
8
Top View
16
15
14
13
12
11
10
9
S
1
IN
1
V-
GND
NC
V+
IN
2
S
2
Two SPST Switches per Package
TRUTH TABLE
Logic
0
1
Logic “0”
0.8
V
Logic “1”
2.4
V
Switch
OFF
ON
Document Number: 73069
S11-0179-Rev. B, 07-Feb-11
www.vishay.com
1
DG401B, DG403B, DG405B
Vishay Siliconix
FUNCTIONAL BLOCK DIAGRAM AND PIN CONFIGURATION
DG403B
Dual-In-Line and SOIC
D
1
NC
D
3
S
3
S
4
D
4
NC
D
2
1
2
3
4
5
6
7
8
Top View
16 S
1
15
14
13
12
11
10
9
IN
1
V-
GND
NC
V+
IN
2
S
2
Four SPST Switches in Two Pairs per Package
TRUTH TABLE
Logic
0
1
Logic “0”
0.8
V
Logic “1”
2.4
V
SW
1
, SW
2
OFF
ON
SW
3
, SW
4
ON
OFF
DG405B
Dual-In-Line and SOIC
D
1
NC
D
3
S
3
S
4
D
4
NC
D
2
1
2
3
4
5
6
7
8
16 S
1
15
14
13
12
11
10
9
IN
1
V-
GND
NC
V+
IN
2
S
2
Four SPST Switches in Two Pairs per Package
TRUTH TABLE
Logic
0
1
Logic “0”
0.8
V
Logic “1”
2.4
V
Switch
OFF
ON
Top View
ORDERING INFORMATION
Standard
Commercial
Part Number
DG401BDJ
DG403BDJ
DG405BDJ
DG401BDY
DG403BDY
DG405BDY
DG401BDY-T1
DG403BDY-T1
DG405BDY-T1
Lead (Pb)-free
Commercial
Part Number
DG401BDJ-E3
DG403BDJ-E3
DG405BDJ-E3
DG401BDY-E3
DG403BDY-E3
DG405BDY-E3
DG401BDY-T1-E3
DG403BDY-T1-E3
DG405BDY-T1-E3
16-Pin Narrow SOIC With Tape and
Reel
16-Pin Narrow SOIC
- 40 to 85 °C
16-Pin Plastic Dip
Package
Temperature
Range
www.vishay.com
2
Document Number: 73069
S11-0179-Rev. B, 07-Feb-11
DG401B, DG403B, DG405B
Vishay Siliconix
ABSOLUTE MAXIMUM RATINGS
Parameter
V+ to V-
GND to V-
Digital
Inputs
a
,
V
S
, V
D
Symbol
Limit
44
25
(V-) - 0.3 V to (V+) + 0.3 V or
30 mA, whichever occurs first
30
100
- 65 to 125
450
600
V
Unit
Current (Any Terminal) Continuous
Current, S or D (Pulsed 1 ms 10 % duty)
Storage Temperature
Power Dissipation (Package)
b
(DJ, DY Suffix)
16-Pin Plastic DIP
c
16-Pin SOIC
d
mA
°C
mW
Notes:
a. Signals on S
X
, D
X
, or IN
X
exceeding V+ or V- will be clamped by internal diodes. Limit forward diode current to maximum current ratings.
b. All leads welded or soldered to PC board.
c. Derate 6 mW/°C above 75 °C.
d. Derate 7.6 mW/°C above 75 °C.
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional operation
of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum
rating conditions for extended periods may affect device reliability.
SPECIFICATIONS
a
Test Conditions
Unless Specified
V+ = 15 V, V- = - 15 V
V
IN
= 2.4 V, 0.8 V
f
Limits
- 40 °C to 85 °C
Temp.
b
Min.
d
Unit
d
Parameter
Analog Switch
Analog Signal Range
e
Drain-Source
On-Resistance
Drain-Source
On-Resistance
Symbol
Typ.
c
Max.
V
ANALOG
R
DS(on)
R
DS(on)
I
S(off)
I
S
= - 10 mA, V
D
= ± 10 V
V+ = 13.5 V, V- = - 13.5 V
I
S
= - 10 mA, V
D
= ± 5 V, 0 V
V+ = 16.5 V, V- = - 16.5 V
V+ = 16.5, V- = - 16.5 V
V
D
= ± 15.5 V, V
S
= ± 15.5 V
V+ = 16.5 V, V- = - 16.5 V
V
S
= V
D
= ± 15.5 V
V
IN
under test = 0.8 V, all other = 2.4 V
V
IN
under test = 2.4 V, all other = 0.8 V
R
L
= 300
,
C
L
= 35 pF
see figure 2
R
L
= 300
,
C
L
= 35 pF
C
L
= 10 000 pF, V
gen
= 0 V, R
gen
= 0
R
L
= 100
,
C
L
= 5 pF, f =1 MHz
Full
Room
Full
Room
Full
Room
Hot
Room
Hot
Room
Hot
Full
Full
Room
Room
Room
Room
Room
Room
Room
f = 1 MHz, V
S
= 0 V
Room
Room
-15
23
0.72
- 0.5
-5
- 0.5
-5
-1
- 10
-1
-1
- 0.01
- 0.01
- 0.04
15
45
55
3
5
0.5
5
0.5
5
1
10
1
1
150
100
V
Switch Off Leakage Current
I
D(off)
Channel On Leakage Current
Digital Control
Input Current V
IN
Low
Input Current V
IN
High
Dynamic Characteristics
Turn-On Time
Turn-Off Time
Break-Before-Make Time Delay
(DG403B)
Charge Injection
Off Isolation Reject Ratio
Channel-to-Channel Crosstalk
Source Off Capacitance
Drain Off Capacitance
Channel On Capacitance
t
ON
t
OFF
t
D
Q
OIRR
X
TALK
C
S(off)
C
D(off)
C
D
, C
S(on)
I
IL
I
IH
I
D(on)
nA
0.005
0.005
100
60
µA
ns
5
12
60
- 81.7
- 94.8
12
12
39
pF
pC
dB
Document Number: 73069
S11-0179-Rev. B, 07-Feb-11
www.vishay.com
3
DG401B, DG403B, DG405B
Vishay Siliconix
SPECIFICATIONS
a
Test Conditions
Unless Specified
V+ = 15 V, V- = - 15 V
V
IN
= 2.4 V, 0.8 V
f
Limits
- 40 °C to 85 °C
Temp.
b
Unit
Parameter
Power Supplies
Positive Supply Current
Negative Supply Current
Ground Current
Symbol
Min.
d
Typ.
c
Max.
d
I+
I-
I
GND
V+ = 16.5 V, V- = - 16.5 V
V
IN
= 0 or 5 V
Room
Full
Room
Full
Room
Full
- 0.5
-1
- 0.5
-1
0.250
0.25
0.25
0.5
1
mA
Notes:
a. Refer to PROCESS OPTION FLOWCHART.
b. Room = 25 °C, Full = as determined by the operating temperature suffix.
c. Typical values are for DESIGN AID ONLY, not guaranteed nor subject to production testing.
d. The algebraic convention whereby the most negative value is a minimum and the most positive a maximum, is used in this data sheet.
e. Guaranteed by design, not subject to production test.
