XZMO79W: DescriptionSingle Color LED, Orange, Water Clear, 3mm, 3.80 X 2 MM, 3.20 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN; CategoryLED optoelectronic/LED photoelectric; File Size93KB，3 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/; Environmental Compliance

Download Datasheet Parametric View All

XZMO79W Overview

Single Color LED, Orange, Water Clear, 3mm, 3.80 X 2 MM, 3.20 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN

XZMO79W Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	SUNLED
package instruction	3.80 X 2 MM, 3.20 MM HEIGHT, ROHS COMPLIANT, SMD, 2 PIN
Reach Compliance Code	compli
color	ORANGE
Configuration	SINGLE
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	795.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	3.2 mm
method of packing	TAPE AND REEL
peak wavelength	610 nm
shape	RECTANGULAR
size	3 mm
surface mount	YES
Terminal pitch	3.8 mm
perspective	35 deg

Preview

Download Datasheet

View All

3.8x2.0mm DOME LENS SMD CHIP LED LAMP

XZMO79W

SUN LED

Email

: sales@us.sunled.com

Web Site : www.sunled.com

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0.2(0.0079")

unless otherwise noted.

Absolute maximum ratings

(T

A

=25

°

C)

Reverse voltage

Forward current

Forward current (peak)

1/10Duty cycle

0.1ms pulse width

Power dissipation

Operating temperature

Storage temperature

V

R

I

F

i

FS

P

T

A

Tstg

MO

(I nGaAlP)

5

30

195

75

-40 ~ +85

Unit

V

mA

mW

°C

Op e r a t i n g Ch a r a c t e r i s t i c s

C)

( T

A

=25

°

C)

Forward voltage (typ.)

(I F=20mA)

Forward voltage (max.)

(I F=20mA)

Reverse current

(VR=5V)

Wavelength at peak

emission

(I F=20mA)

Wavelength at Dominate

emission

(I F=20mA)

Spectral Line half-width

(I F=20mA)

Capacitance

(VF=0V, f=1MHz)

V

F

V

F

I

R

λ

peak

MO

( In Ga Al P )

2.0

2.5

10

610

Un i t

V

uA

nm

λD

∆λ

C

601

29

30

nm

pF

P art

Nu m b e r

Em i t t i n g

Co l o r

Em i t t i n g

Ma te ria l

L e n s -c o l o r

L u min o u s

In t e n si t y

( I F = 20m A )

mc d

min .

ty p .

480

799

Wa v e l e n g t h

nm

λ

P

Vi e w i n g

An g l e

2θ1/2

θ

60°

(H)

35°

(V)

XZMO79W

Orange

I nGaAlP

Water Clear

610

Published Date :OCT 20,2002

Drawing No: XDSA1541

V2

Checked : B.L.LIU

3-1
