ZMDBB55W-7: DescriptionDual Color LED, Red/blue, Water Clear, 1.6mm, 3.20 X 1.60 MM, 1.80 MM HEIGHT, ROHS COMPLIANT PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size283KB，4 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/; Environmental Compliance

Download Datasheet Parametric View All

ZMDBB55W-7 Overview

Dual Color LED, Red/blue, Water Clear, 1.6mm, 3.20 X 1.60 MM, 1.80 MM HEIGHT, ROHS COMPLIANT PACKAGE-2

ZMDBB55W-7 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	SUNLED
package instruction	3.20 X 1.60 MM, 1.80 MM HEIGHT, ROHS COMPLIANT PACKAGE-2
Reach Compliance Code	compli
color	RED/BLUE
Configuration	COMMON BIPOLAR TERMINAL, 2 ELEMENTS
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	695.0/297.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	DUAL COLOR LED
total height	1.8 mm
method of packing	TAPE AND REEL
peak wavelength	640/468 nm
shape	ROUND
size	1.6 mm
surface mount	YES
Terminal pitch	3.2 mm
perspective	40 deg

Preview

Download Datasheet

View All

Part Number:

ZMDBB55W-7

www.SunLED.com

3.2mm x 1.6mm BI-COLOR SURFACE

MOUNT LED LAMP

Features

3.2mmx1.6mm SMT LED,1.8mm THICKNESS.

LOW POWER CONSUMPTION.

WIDE VIEWING ANGLE.

IDEAL FOR BACKLIGHT AND INDICATOR.

PACKAGE : 2000PCS / REEL.

MOISTURE SENSITIVITY LEVEL : LEVEL 3.

RoHS COMPLIANT.

ATTENTION

OBSERVE PRECAUTIONS

FOR HANDLING

ELECTROSTATIC

DISCHARGE

SENSITIVE

DEVICES

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is ± 0.1(0.004") unless otherwise noted.

Absolute Maximum Ratings

=25°C)

)

Forward Current

Forward Current (Peak)

1/10 Duty Cycle

0.1ms Pulse Width

Power Dissipation

Operating Temperature

Storage Temperature

Tstg

—

(InGaA

lP)

185

170

(InGaN)

160

102

Unit

Operating Characteristics

=25°C)

)

Forward Voltage (Typ.)

=20mA)

Forward Voltage (Max.)

=20mA)

Wavelength of Peak

Emission (Typ.)

=20mA)

Wavelength of Dominant

Emission (Typ.)

=20mA)

Spectral Line Full Width

At Half-Maximum (Typ.)

=20mA)

Capacitance

=0V, f=1MHz)

(InGaA

lP)

1.9

2.5

(InGaN)

3.65

4.2

Unit

-40 ~ +85

1000

640

468

Electrostatic Discharge Threshold

(HBM)

628

470

∆λ

Part

Number

Emitting

Color

Emitting

Material

Lens-color

Luminous

Intensity

(IF=20mA)

mcd

min.

typ.

695

297

Wavelength

Viewing

Angle

1/2

ZMDBB55W-7

Red

Blue

InGaAlP

InGaN

Water Clear

280

640

468

40°

Published Date : MAY 26, 2006

Drawing No : SDSA4565

Checked : B.L.LIU

P.1/4
