DF04S/D Series
4W DC/DC CONVERTER, DIP-Package, 4:1 Wide Input Range
FEATURES
Efficiency up to 85%
DIP Package with Industry Standard Pinout
Short Circuit Protection
4:1 Wide Input Range
UL60950-1 Safety Approval
Complies with EN55022 Class A
Temperature Performance -40℃ to +71℃
1500VDC Voltage Isolation
Internal SMD Construction
Lead free, RoHs Compliant
3 Years Product Warranty
The DF04S/D series are miniature, DIP Package, isolated 4W DC/DC converters. It allows a wide over input voltage ranges of
9-36VDC and 18-75VDC. It alos offers short circuit protection and allows a wide operating temperature range of –40°C to +71°C.
These isolated DC/DC converters are the latest offering from a world leader in power systems technology and manufacturing
―
Delta Electronics, Inc. With creative design technology and optimization of component placement, these converters possess
outstanding electrical and thermal performance, as well as extremely high reliability under highly stressful operating conditions.
Model List
Model
Number
Input
Voltage
(Range)
VDC
DF04S2403A
DF04S2405A
DF04S2412A
DF04S2415A
DF04D2405A
DF04D2412A
DF04D2415A
DF04S4803A
DF04S4805A
DF04S4812A
DF04S4815A
DF04D4805A
DF04D4812A
DF04D4815A
Output
Voltage
VDC
3.3
5
12
15
±5
±12
±15
3.3
5
12
15
±5
±12
±15
Output
Current
Max.
mA
900
660
333
267
±300
±167
±133
900
660
333
267
±300
±167
±133
Min.
mA
90
66
33
27
±30
±17
±13
90
66
33
27
±30
±17
±13
Input Current
@Max. Load
mA(typ.)
161
170
201
201
156
201
201
79
84
98
98
76
98
98
@No Load
mA(typ.)
Reflected
Ripple
Current
mA(typ.)
Max. capacitive
Load
uF
3000
20
5
680*
Efficiency
(typ.)
@Max. Load
%
77
81
83
83
80
83
83
78
82
85
85
82
85
85
* For each output
24
(9 ~ 36)
3000
10
5
680*
48
(18 ~ 75)
DS_DF04S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P1
Input Characteristics
Parameter
Input Surge Voltage (1 sec. max.)
Start-Up Voltage
Under Voltage Shutdown
Reverse Polarity Input Current
Short Circuit Input Power
Internal Power Dissipation
Conducted EMI
Model
24V Input Models
48V Input Models
24V Input Models
48V Input Models
24V Input Models
48V Input Models
Min.
Typ.
Max.
Unit
-0.7
50
---
-0.7
100
---
4.5
6
8.5
VDC
8.5
12
17
---
---
8
---
---
16
---
---
1
A
---
1000
2000
mW
---
---
2500
mW
Compliance to EN 55022,class A and FCC part 15,class A
All Models
Output Characteristics
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Transient Recovery Time
Transient Response Deviation
Temperature Coefficient
Over Load Protection
Short Circuit Protection
Conditions
Dual Output, Balanced Loads
Vin=Min. to Max.
Io=10% to 100%
Over Line, Load & Temp.
25% Load Step Change
Foldback
Min.
---
---
---
---
---
---
---
---
---
---
120
Typ.
±0.5
±0.5
±0.2
±0.3
50
---
---
150
±2
±0.01
TBD
Continuous
Max.
±1.0
±2.0
±0.5
±1.0
75
100
15
500
---
±0.02
---
Unit
%
%
%
%
mV
P-P
mV
P-P
mV rms
uS
%
%/℃
%
General Characteristics
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Resistance
I/O Isolation Capacitance
Switching Frequency
MTBF (calculated)
Safety Approvals
MIL-HDBK-217F@25℃, Ground Benign
Conditions
60 Seconds
500 VDC
100KHz, 1V
Min.
1500
1000
---
---
1,000,000
Typ.
---
---
380
350
---
Max.
---
---
500
---
---
Unit
VDC
MΩ
pF
KHz
Hours
UL/cUL 60950-1 recognition(UL certificate), IEC/EN 60950-1
Recommended Input Fuse
24V Input Models
1000mA Slow-Blow Type
48V Input Models
500mA Slow-Blow Type
Environmental Characteristics
Parameter
Operating Temperature Range
(with Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature
(1.5mm from case for 10Sec.)
Conditions
Ambient
Min.
-40
---
-50
---
Free-Air convection
---
260
℃
Max.
+85
+90
+125
95
Unit
℃
℃
℃
% rel. H
DS_DF04S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P2
Power Derating Curve
Notes
1
2
3
4
5
6
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Transient recovery time is measured to within 1% error band for a step change in output load of 50% to 100%
Ripple & Noise measurement bandwidth is 0-20MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will not
damage these modules; however they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
Specifications subject to change without notice.
Mechancial Drawing
Mechanical Dimensions
10.2
[0.40]
Output Power (%)
Pin Connections
Pin
Single Output
2
-Vin
3
9
11
-Vin
No Pin
NC
+Vout
-Vout
+Vin
+Vin
Dual Output
-Vin
-Vin
Common
-Vout
+Vout
Common
+Vin
+Vin
0.50 [0.02]
4.1
[0.16]
14
16
22
23
2
3
9
11
15.22 [0.60]
20.3 [0.80]
NC: No Connection
Bottom View
23
22
16
14
►
All
dimensions in mm (inches)
X.X±0.25 (X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
2.54
[0.10]
15.24 [0.60]
31.8 [1.25]
5.08 4.5
[0.20][0.18]
2.54
[0.10]
►
Tolerance:
►
Pin
diameter
⇔
0.5 ±0.05 (0.02±0.002)
Physical Outline
Case Size
Case Material
:
Weight
:
16.2g
:
31.8x20.3x10.2mm (1.25x0.80x0.40 Inches)
Metal With Non-Conductive Baseplate
DS_DF04S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P3
Part Numbering System
D
Form factor
D-DIP
P-SIP
S-SMD
F
Family series
A~Z
04
Watt
01:1W
02:2W
03:3W
04:4W
06:6W
S
Number of
Outputs
S - Single
D- Dual
24
Input Voltage
03:3.3V
05: 5V
12:12V
24: 24V
48:48V
05
Output Voltage
03:3.3V
05: 5V
12:12V
15: 15V
24: 24V
A
Option Code
A - Std. Functions
WARRANTY
Delta offers a three(3) years limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under
any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
DS_DF04S/D_03152012
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P4
