LESHAN RADIO COMPANY, LTD.
Schottky Barrier Diodes
BAT54RLT1
These Schottky barrier diodes are designed for high speed switching
applications, circuit protection, and voltage clamping. Extremely low forward
voltage reduces conduction loss. Miniature surface mount package is excellent
for hand held and portable applications where space is limited.
• Extremely Fast Switching Speed
• Low Forward Voltage — 0.35 Volts (Typ) @ I
F
= 10 mAdc
30 VOLTS
SILICON HOT- CARRIER
DETECTOR AND
SWITCHING
DIODES
3
3
CATHODE
1
ANODE
1
2
CASE 318–08, STYLE 8
SOT–23 (TO–236AB)
DEVICE MARKING
BAT54RLT1 = LV3
MAXIMUM RATINGS
(T
J
= 125°C unless otherwise noted)
Rating
Reverse Voltage
Forward Power Dissipation
@ T
A
= 25°C
Derate above 25°C
Operating Junction
Temperature Range
Storage Temperature Range
Symbol
V
R
P
F
Value
30
200
2.0
T
J
T
stg
–55 to +125
–55 to +150
°C
°C
Unit
Volts
mW
mW/°C
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted)
Characteristic
Reverse Breakdown Voltage (I
R
= 10
µA)
Total Capacitance (V
R
= 1.0 V, f = 1.0 MHz)
Reverse Leakage (V
R
= 25 V)
Forward Voltage (I
F
= 0.1 mAdc)
Forward Voltage (I
F
= 30 mAdc)
Forward Voltage (I
F
= 100 mAdc)
Reverse Recovery Time
(I
F
= I
R
= 10 mAdc, I
R(REC)
= 1.0 mAdc) Figure 1
Forward Voltage (I
F
= 1.0 mAdc)
Forward Voltage (I
F
= 10 mAdc)
Symbol
V
(BR)R
C
T
I
R
V
F
V
V
F
F
Min
30
—
—
—
—
—
—
—
—
Typ
—
7.6
0.5
0.22
0.41
0.52
—
0.29
0.35
Max
—
10
2.0
0.24
0.5
1.0
5.0
0.32
0.40
Unit
Volts
pF
µAdc
Vdc
Vdc
Vdc
ns
Vdc
Vdc
t
rr
V
F
V
F
G11–1/2
LESHAN RADIO COMPANY, LTD.
BAT54RLT1
820
Ω
2.0 k
0.1µF
t
r
t
p
10%
t
I
F
t
rr
t
+10 V
100
µH
I
F
0.1
µF
50
Ω
OUTPUT
PULSE
GENERATOR
D.U.T.
50
Ω
INPUT
SAMPLING
OSCILLOSCOPE
90%
i
R(REC)
= 1.0 mA
INPUT SIGNAL
V
R
I
R
OUTPUT PULSE
(I
F
= I
R
= 10 mA; MEASURED
at i
R(REC)
= 1.0 mA)
Notes: 1. A 2.0 kΩ variable resistor adjusted for a Forward Current (I
F
) of 10mA.
Notes:
2. Input pulse is adjusted so I
R(peak)
is equal to 10mA.
Notes:
3. t
p
» t
rr
Figure 1. Recovery Time Equivalent Test Circuit
100
1000
T
A
= 150°C
I
R
, REVERSE CURRENT (µA)
I
F
, FORWARD CURRENT (mA)
100
10
150°C
T
A
= 125°C
10
1.0
125°C
1.0
T
A
= 85°C
0.1
85°C
25°C
– 40°C
–55°C
0.01
T
A
= 25°C
0.001
0
5
10
15
20
25
30
0.1
0
0.1
0.2
0.3
0.4
0.5
0.6
V
F
, FORWARD VOLTAGE (VOLTS)
V
R
, REVERSE VOLTAGE (VOLTS)
Figure 2. Forward Voltage
Figure 3. Leakage Current
14
12
C
T
TOTAL CAPACITANCE (pF)
10
8
6
4
2
0
0
5
10
15
20
25
30
V
R
, REVERSE VOLTAGE (VOLTS)
Figure 4. Total Capacitance
G11–2/2
