Proximity Sensors Inductive Nickel-plated Brass Housing

Preview

Download Datasheet

View All

Proximity Sensors Inductive

Nickel-plated Brass Housing

Types DJ, M 14, PG 21, Namur

• Nickel-plated brass housing, cylindrical

• Diameter: M 14, PG 21

• Sensing distance: 2 to 6 mm

• Power supply: 8.2 VDC (Namur)

• Output: Namur (DIN 19 234)

• 2 m cable

Product Description

Proximity switch in M 14 and

PG 21 nickel-plated brass

housings, for flush mounting

and non-flush mounting. Am-

plifier relay SD ... available.

Delivered with 2 m cable.

Ordering Key

Type: Inductive proximity

switch

Rated operating dist. (mm)

Housing material

DJ 2 G

Type Selection

Housing

diameter

M 14

PG 21

Rated

operating

dist. (S

n

)

2 mm

1)

5 mm

2)

6 mm

1)

Ordering no.

Namur

DJ 2 G

DJ 5 G

DJ 6 G

1)

2)

For flush mounting in metal

For non-flush mounting in metal

Specifications

Rated operational volt.

(U

e

)

(U

B

)

8.2 VDC

7 to 9 VDC

(6 to 35 VDC, all specifica-

tions not observed in

extended supply range)

≤

300 mH

≤

120 nF

Activated:

≤1

mA

Not activated:

DJ 2 G

≥

3 mA

DJ 5 G

≥

2.2 mA

DJ 6 G

≥

2.2 mA

Max.:

9.35 mA

None

(DJ10

G:

reverse polarity)

≤

1 kV/0.5 J (prepared)

DJ 2 G

DJ 5 G

DJ 6 G

DJ 2 G

DJ 5 G

DJ 6 G

≤

10%

2000 Hz

1000 Hz

0 to 1.44 mm

0 to 4.05 mm

0 to 4.32 mm

Usable operating dist.

(S

u

)

DJ 2 G

0.8 x S

r

≤

S

u

≤

1.2 x S

r

DJ 5 G

0.9 x S

r

≤

S

u

≤

1.1 x S

r

DJ 6 G

0.8 x S

r

≤

S

u

≤

1.2 x S

r

DJ 2 G

-20° to +60°C (-4° to +140°F)

DJ 5 G

-25° to +70°C (-13° to +158°F)

DJ 6 G

-20° to +60°C (-4° to +140°F)

DJ 2 G

-25° to +70°C (-13° to +158°F)

DJ 5 G

-30° to +80°C (-22° to +176°F)

DJ 6 G

-25° to +70°C (-13° to+158°F)

IP 67

(Nema 1, 3, 4, 6, 13)

Nickel-plated brass

Blue ABS

DJ 2 G

2 m, 2 x 0.25 mm

2

DJ 5 G

2 m, 2 x 0.25 mm

2

DJ 6 G

2 m, 2 x 0.50 mm

2

grey PVC, oil proof

Ambient temperature

Operating

Self-inductance

Self-capacitance

No-load supply current

(I

o

)

Storage

Protection

Transient voltage

Frequency of operating

cycles

(f)

Degree of protection

Housing material

Body

Front

Back

Cable

Assured operating dist. (S

a

)

Repeat accuracy

(R)

Hysteresis

(H)

(Differential travel)

Dependent on amplifier relay

Specifications are subject to change without notice (25.06.99)
