Document 253-1
SMT Power Inductors – DO1605T Series
• Only 1.8 mm high
• Handles current up to 2.3 Amps rms
Designer’s Kit C353
contains 3 each of all values
Core material
Ferrite
Core and winding loss
See www.coilcraft.com/coreloss
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
101 – 110 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +125°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
1000/7″reel; 3500/13″ reel Plastic tape: 12 mm wide,
0.25 mm thick, 8 mm pocket spacing, 2.3 mm pocket depth
PCB washing
Only pure water or alcohol recommended
1
Part number
1
L
2
±20%
(µH)
1.0
1.5
2.2
3.3
4.7
6.8
8.2
10
15
22
33
47
68
100
150
220
330
470
680
1000
1
DCR
max
(Ohms)
0.04
0.06
0.07
0.12
0.15
0.20
0.23
0.27
0.35
0.54
0.74
1.1
1.6
2.3
3.5
5.7
8.2
10.8
17.2
22.6
SRF
3
ref
(MHz)
230
180
140
110
100
80
70
60
45
35
30
22
20
15
10
9
8
7
5
4
1. When ordering, please specify
termination
and
packaging
codes:
Isat
4
(A)
2.5
2.2
1.8
1.4
1.2
1.1
1.0
1.0
0.8
0.6
0.5
0.45
0.35
0.30
0.25
0.20
0.16
0.14
0.12
0.08
Irms
5
(A)
2.3
2.1
1.7
1.3
1.1
1.0
0.95
0.90
0.70
0.50
0.45
0.40
0.35
0.30
0.25
0.18
0.16
0.12
0.10
0.08
DO1605T-102ML_
DO1605T-152ML_
DO1605T-222ML_
DO1605T-332ML_
DO1605T-472ML_
DO1605T-682ML_
DO1605T-822ML_
DO1605T-103ML_
DO1605T-153ML_
DO1605T-223ML_
DO1605T-333ML_
DO1605T-473ML_
DO1605T-683ML_
DO1605T-104ML_
DO1605T-154ML_
DO1605T-224ML_
DO1605T-334ML_
DO1605T-474ML_
DO1605T-684ML_
DO1605T-105ML_
DO1605T-105MLC
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit
Special order: T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: C=
7″ machine-ready reel. EIA-481 embossed plastic
tape (1000 parts per full reel).
B=
Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D=
13″ machine-ready reel. EIA-481 embossed plastic
tape (3500 parts per full reel).
2. Inductance tested at 100 kHz, 0.1 Vrms.
3. SRF >13 MHz measured using Agilent/HP 8753D network analyzer;
<13 MHz using Agilent/HP 4192A.
4. DC current at which the inductance drops 10% (typ) from its value
without current.
5. Current that causes a 40°C temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 253-1
Revised 10/08/08
© Coilcraft, Inc. 2009
