DPLS4140E
LOW V
CE(SAT)
PNP SURFACE MOUNT TRANSISTOR
Features
•
•
•
•
•
Epitaxial Planar Die Construction
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
Mechanical Data
•
•
•
•
Case: SOT-223
Case Material: Molded Plastic, "Green" Molding Compound. UL
Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminals: Finish - Matte Tin annealed over Copper Leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Marking Information: See Page 4
Ordering Information: See Page 4
Weight: 0.115 grams (approximate)
•
•
•
COLLECTOR
2,4
1
BASE
3
EMITTER
Top View
Device Schematic
3 E
C 4
2 C
1 B
TOP VIEW
Pin Configuration
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CM
Value
-180
-140
-7
-4
-10
Unit
V
V
V
A
A
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Continuous Collector Current
Peak Pulse Current
Thermal Characteristics
Characteristic
Power Dissipation (Note 3) @ T
A
= 25°C
Thermal Resistance, Junction to Ambient Air (Note 3) @ T
A
= 25°C
Operating and Storage Temperature Range
Notes:
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
1
125
-55 to +150
Unit
W
°C/W
°C
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 PCB; pad layout as shown on page 4 or in Diodes Inc. suggested pad layout document AP02001, which can be found on our
website at http://www.diodes.com/datasheets/ap02001.pdf.
DPLS4140E
Document number: DS31279 Rev. 3 - 2
1 of 4
www.diodes.com
October 2008
© Diodes Incorporated
DPLS4140E
Electrical Characteristics
Characteristic
OFF CHARACTERISTICS (Note 4)
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
ON CHARACTERISTICS (Note 4)
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-Emitter Turn-On Voltage
DC Current Gain
SMALL SIGNAL CHARACTERISTICS
Current Gain-Bandwidth Product
Output Capacitance
SWITCHING CHARACTERISTICS
Switching Times
Notes:
@T
A
= 25°C unless otherwise specified
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
Min
-180
-140
-7
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
100
100
45
⎯
⎯
⎯
⎯
⎯
Typ
-230
-190
-8.5
⎯
⎯
-40
-50
-75
-175
-910
-810
⎯
⎯
⎯
12
150
55
85
430
Max
⎯
⎯
⎯
-20
-0.5
-10
-60
-80
-120
-360
-1040
-930
⎯
300
⎯
⎯
⎯
⎯
⎯
⎯
Unit
V
V
V
nA
μA
nA
Test Condition
I
C
= -100μA, I
E
= 0
I
C
= -10mA, I
B
= 0
I
E
= -100μA, I
C
= 0
V
CB
= -150V, I
E
= 0
V
CB
= -150V, I
E
= 0,
T
A
= 100°C
V
EB
= - 6V, I
C
= 0
I
C
= -0.1A, I
B
= -5mA
I
C
= -0.5A, I
B
= -50mA
I
C
= -1A, I
B
= -100mA
I
C
= -3A, I
B
= -300mA
I
C
= -3A, I
B
= -300mA
I
C
= -3A, V
CE
= -5V
I
C
= -10mA, V
CE
= -5V
I
C
= -1A, V
CE
= -5V
I
C
= -3A, V
CE
= -5V
I
C
= -10A, V
CE
= -5V
I
C
= -100mA, V
CE
= -10V,
f = 100MHz
V
CB
= -10V, f = 1MHz
I
C
= -1A, I
B1
= -100mA
I
B2
= 100mA, V
CC
= -50V
V
CE(SAT)
V
BE(SAT)
V
BE(ON)
h
FE
mV
mV
mV
⎯
f
T
C
obo
t
on
t
off
MHz
pF
ns
4. Measured under pulsed conditions. Pulse width = 300μs. Duty cycle
≤2%
1.0
P
D
, POWER DISSIPATION (mW)
0.8
I
B
= -5mA
0.8
-I
C
, COLLECTOR CURRENT (A)
0.6
I
B
= -4mA
0.6
0.4
I
B
= -3mA
0.4
I
B
= -2mA
0.2
I
B
= -1mA
0.2
0
25
50
150
100
125
75
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Power Dissipation vs. Ambient Temperature (Note 3)
0
0
1
2
3
4
5
-V
CE
, COLLECTOR-EMITTER VOLTAGE (V)
Fig. 2 Typical Collector Current vs. Collector-Emitter Voltage
0
DPLS4140E
Document number: DS31279 Rev. 3 - 2
2 of 4
www.diodes.com
October 2008
© Diodes Incorporated
DPLS4140E
350
300
250
200
150
100
50
0
0.001
0.3
-V
CE(SAT)
, COLLECTOR-EMITTER
SATURATION VOLTAGE (V)
0.01
0.1
1
10
0.2
0.1
0
0.001
0.01
0.1
1
10
-I
C
, COLLECTOR CURRENT (A)
Fig. 4 Typical Collector-Emitter Saturation Voltage
vs. Collector Current
-V
BE(ON)
, BASE-EMITTER TURN-ON VOLTAGE (V)
-V
BE(SAT)
, BASE-EMITTER SATURATION VOLTAGE (V)
1.2
1.2
1
1.0
0.8
0.8
0.6
0.6
0.4
0.4
0.2
0.2
0
0.001
0
0.001
0.01
0.1
1
10
-I
C
, COLLECTOR CURRENT (A)
Fig. 5 Typical Base-Emitter Turn-On Voltage
vs. Collector Current
0.01
0.1
1
10
-I
C
, COLLECTOR CURRENT (A)
Fig. 6 Typical Base-Emitter Saturation Voltage
vs. Collector Current
1,000
200
f
T
, GAIN-BANDWIDTH PRODUCT (MHz)
f = 1MHz
150
V
CE
= -10V
f = 100MHz
100
100
C
obo
50
10
0.1
1
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 7 Typical Capacitance Characteristics
0
20 30 40 50 60 70 80 90 100
-I
C
, COLLECTOR CURRENT (mA)
Fig. 8 Typical Gain-Bandwidth Product vs. Collector Current
0
10
DPLS4140E
Document number: DS31279 Rev. 3 - 2
3 of 4
www.diodes.com
October 2008
© Diodes Incorporated
DPLS4140E
Ordering Information
Part Number
DPLS4140E-13
Notes:
(Note 5)
Case
SOT-223
Packaging
2500/Tape & Reel
5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
YWW
P414A
P414A = Product Type Marking Code
YWW = Date Code Marking
Y = Last digit of year (ex: 8 = 2008)
WW = Week code 01 - 52
Package Outline Dimensions
SOT-223
Dim Min Max Typ
A
1.55 1.65 1.60
A1
0.010 0.15 0.05
b1
2.90 3.10 3.00
b2
0.60 0.80 0.70
C
0.20 0.30 0.25
D
6.45 6.55 6.50
E
3.45 3.55 3.50
E1
6.90 7.10 7.00
e
—
—
4.60
e1
—
—
2.30
L
0.85 1.05 0.95
Q
0.84 0.94 0.89
All Dimensions in mm
A
A1
Suggested Pad Layout
X1
Y1
C1
Y2
C2
X2
Dimensions
X1
X2
Y1
Y2
C1
C2
Value (in mm)
3.3
1.2
1.6
1.6
6.4
2.3
