TOS 020016
www.vishay.com
Vishay Draloric
RF Power Barrel Capacitors
with Screw Terminals, Class 1 and Class 2 Ceramic
FEATURES
• Small size
• Geometry minimizes inductance, optimizes voltage
withstand and maximizes heat radiation
APPLICATIONS
• Industrial and medical RF power supply
• Small broadcasting equipment
• Antenna couplers
• Induction heating equipment
QUICK REFERENCE DATA
DESCRIPTION
Ceramic Class
Ceramic Dielectric
Type
Voltage (V
p
)
Min. Capacitance (pF)
Max. Capacitance (pF)
Mounting
7500
10
300
Screw terminal
1
C0G, U2J, N5600
TOS 020016
7500
400
2500
VALUE
2
X7R, Y5U
CAPACITANCE RANGE
10 pF to 2.5 nF
CAPACITANCE TOLERANCE
• Class 1:
• Class 2:
± 10 %
± 20 %
CERAMIC DIELECTRICS
• Class 1:
• Class 2:
C0G, U2J, N5600
XR7, Y5U
RATED VOLTAGE
MATERIAL
Capacitor elements made from class 1 ceramic dielectric
with noble metal electrodes.
Connection terminals:
thread terminal, brass, silver plated.
Allowable torque: 1.47 Nm (13 lbf in)
7.5 kV
DC
DIELECTRIC STRENGTH TEST
150 % of rated voltage (8000 V
RMS
, 50 Hz, 3 minutes)
DISSIPATION FACTOR
• C0G, U2J: max. 0.05 % (1 MHz)
• N5600:
max. 0.20 % (1 MHz)
• X7R, Y5U: max. 2.5 % (1 kHz)
FINISH
Capacitor body completely protective lacquered.
MARKING
Type designator, capacitance value and tolerance, rated
peak voltage, ceramic material code, production date code,
manufacturer logo.
INSULATION RESISTANCE
• C0G, U2J, N5600, X7R: min. 100 000 M (at 25 °C)
• Y5U:
min. 50 000 M (at 25 °C)
OPERATING TEMPERATURE RANGE
• Class 1:
• Class 2:
-55 °C to +100 °C
-55 °C to +85 °C
Revision: 25-Feb-16
Document Number: 22086
1
For technical questions, contact:
powcap@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
TOS 020016
www.vishay.com
Vishay Draloric
MAX. POWER RATING
(1)
1.0 MHz
(kvar)
1.7
3.2
4.4
5.3
7.0
8.8
10
10
5.0
7.5
5.0
5.0
0.4
0.4
0.4
0.4
0.2
0.2
0.2
0.2
10 MHz
(kvar)
10
10
10
10
10
10
10
10
5.0
5.0
5.0
0.4
0.4
0.4
0.4
0.2
0.2
0.2
0.2
30 MHz
(kvar)
10
10
10
10
10
10
7.0
5.3
3.5
2.7
1.8
0.4
0.4
0.4
0.4
0.2
0.2
0.2
0.2
MAX. CURRENT RATING
1.0 MHz
(A
RMS
)
0.3
0.6
0.8
1.0
1.3
1.7
2.2
2.5
2.2
2.5
3.1
1.0
1.1
1.2
1.4
1.1
1.4
1.6
1.8
10 MHz
(A
RMS
)
2.5
3.1
4.0
4.4
5.1
5.6
6.9
7.9
6.9
7.9
9.7
3.2
3.6
3.9
4.5
3.6
4.3
5.0
5.6
30 MHz
(A
RMS
)
4.3
5.3
6.9
7.5
8.7
9.7
10
10
10
10
10
5.5
6.1
6.7
7.8
6.1
7.5
8.7
9.7
SAP PART NUMBER AND ELECTRICAL DATA
PART NUMBER
BS020016VZ10036AC1
BS020016VZ15036AC1
BS020016VZ25036AC1
BS020016VZ30036AC1
BS020016VZ40036AC1
BS020016VZ50036AC1
BS020016VZ75036AL1
BS020016VZ10136AL1
BS020016VZ15136AS1
BS020016VZ20136AS1
BS020016VZ30136AS1
BS020016VZ40138AT1
BS020016VZ50138AT1
BS020016VZ60138AU1
BS020016VZ80138AU1
BS020016VZ10238AV1
BS020016VZ15238AV1
BS020016VZ20238BA1
BS020016VZ25238BA1
Y5U
X7R
N5600
U2J
(N750)
C0G
(NP0)
CERAMIC
CAP.
VALUES
(pF)
10
15
25
30
40
50
75
100
150
200
300
400
500
600
800
1000
1500
2000
2500
RATED
VOLTAGE
(kV
DC
)
Notes
• # 14
th
to 15
th
digit: capacitance tolerance code ± 10 % = 36; ± 20 % = 38
• RoHS-compliant parts on request
(1)
The surface temperature during operation must not exceed +100 °C
DIMENSIONS
in millimeters (inches)
max. Ø 21
(max. Ø 0.83)
6.0
(0.236)
L
2 max.
=
16.0 ± 1.5 (0.630 ± 0.059)
(1)
L
1 max.
= 22.6 (0.890)
(1)
Note
Dimension L
1
and L
2
will vary depending upon capacitance value
6-32 UNC thread
min. 4.8 (0.189) depth
(1)
RELATED DOCUMENTS
General Information
www.vishay.com/doc?22071
Revision: 25-Feb-16
Document Number: 22086
2
For technical questions, contact:
powcap@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
