EGP20A thru EGP20G
Vishay General Semiconductor
Glass Passivated Ultrafast Rectifier
®
Major Ratings and Characteristics
I
F(AV)
V
RRM
I
FSM
t
rr
V
F
T
j
max.
2.0 A
50 V to 400 V
75 A
50 ns
0.95 V, 1.25 V
150 °C
ted*
aten
P
* Glass Encapsulation
technique is covered by
Patent No. 3,996,602,
brazed-lead assembly
to Patent No. 3,930,306
DO-204AC (DO-15)
Features
•
•
•
•
•
•
•
Cavity-free glass-passivated junction
Ultrafast reverse recovery time
Low forward voltage drop
Low leakage current
Low switching losses, high efficiency
High forward surge capability
Solder Dip 260 °C, 40 seconds
Mechanical Data
Case:
DO-204AC, molded epoxy over glass body
Epoxy meets UL-94V-0 Flammability rating
Terminals:
Matte tin plated leads, solderable per
J-STD-002B and JESD22-B102D
E3 suffix for commercial grade, HE3 suffix for high
reliability grade (AEC Q101 qualified)
Polarity:
Color band denotes cathode end
Typical Applications
For use in high frequency rectification and freewheel-
ing application in switching mode converters and
inverters for consumer, computer and Telecommuni-
cation
Maximum Ratings
T
A
= 25 °C unless otherwise specified
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current 0.375"
(9.5 mm) lead length at T
A
= 55 °C
Peak forward surge current 8.3 ms single half sine-
wave superimposed on rated load
Operating and storage temperature range
Symbol EGP20A EGP20B EGP20C EGP20D EGP20F EGP20G
V
RRM
V
RMS
V
DC
I
F(AV
)
I
FSM
T
J
,T
STG
50
35
50
100
70
100
150
105
150
2.0
75
- 65 to + 150
200
140
200
300
210
300
400
280
400
Unit
V
V
V
A
A
°C
Document Number 88583
10-Aug-05
www.vishay.com
1
EGP20A thru EGP20G
Vishay General Semiconductor
Electrical Characteristics
T
A
= 25 °C unless otherwise specified
Parameter
Maximum instantaneous
forward voltage
Maximum DC reverse current
at rated DC blocking voltage
Maximum reverse recovery
time
Typical junction capacitance
Test condition
at 2.0 A
T
A
= 25 °C
T
A
= 125 °C
at I
F
= 0.5 A, I
R
= 1.0 A,
I
rr
= 0.25 A
at 4.0 V, 1 MHz
Symbol EGP20A EGP20B EGP20C EGP20D EGP20F EGP20G Unit
V
F
I
R
t
rr
C
J
70
0.95
5.0
100
50
45
1.25
V
µA
ns
pF
Thermal Characteristics
T
A
= 25 °C unless otherwise specified
Parameter
Typical thermal resistance
(1)
Notes:
(1) Thermal resistance from junction to ambient, and from junction to lead at 0.375" (9.5 mm) lead length, P.C.B. mounted
Symbol
R
θJA
R
θJL
EGP20A EGP20B EGP20C EGP20D EGP20F EGP20G
40
15
Unit
°C/W
www.vishay.com
2
Document Number 88583
10-Aug-05
EGP20A thru EGP20G
Vishay General Semiconductor
Ratings and Characteristics Curves
(T
A
= 25
°C
unless otherwise noted)
3.0
Instantaneous Reverse Leakage Current (µA)
Average Forward Rectified Current (A)
Resistive or Inductive Load
0.375" (9.5mm) Lead Length
100
EGP20A~EGP20D
10
T
j
= 150 °C
T
j
= 125 °C
1
T
j
= 100 °C
2.0
0.1
1.0
0.01
T
j
= 25 °C
0
0
25
50
75
100
125
150
175
0.001
0
20
40
60
80
100
Ambient Temperature (°C)
Percent of Peak Reverse
Voltage
(%)
Figure 1. Maximum Forward Current Derating Curve
Figure 4. Typical Reverse Leakage Characteristics
90
75
60
Instantaneous Forward Current (A)
Peak Forward Surge Current (A)
T
J
= T
J
max.
8.3ms Single Half Sine-Wave
100
EGP20F~EGP20G
T
j
= 150 °C
10
T
j
= 125 °C
1
T
j
= 100 °C
0.1
T
j
= 25 °C
0.01
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
45
30
15
0
1
10
100
Number of Cycles at 60 H
Z
Instantaneous Forward
Voltage
(V)
Figure 2. Maximum Non-Repetitive Peak Forward Surge Current
Figure 5. Typical Instantaneous Forward Characteristics
Instantaneous Reverse Leakage Current (µA)
100
Instantaneous Forward Current (A)
EGP20A~EGP20D
T
j
= 150 °C
10
T
j
= 125 °C
1
100
EGP20F~EGP20G
10
T
j
= 150 °C
T
j
= 125 °C
1
T
j
= 100 °C
0.1
T
j
= 25 °C
0.01
T
j
= 100 °C
0.1
T
j
= 25 °C
0.01
0.2
0.4
0.6
0.8
1
1.2
0.001
0
20
40
60
80
100
Instantaneous Forward
Voltage
(V)
Percent of Peak Reverse
Voltage
(%)
Figure 3. Typical Instantaneous Forward Characteristics
Figure 6. Typical Reverse Leakage Characteristics
Document Number 88583
10-Aug-05
www.vishay.com
3
EGP20A thru EGP20G
Vishay General Semiconductor
140
120
100
100
80
60
40
20
0
0.1
Transient Thermal Impedance (°C/W)
T
J
= 25°C
f = 1.0 MH
Z
Vsig = 50mVp-p
Junction Capacitance (pF)
10
1
EGP20A - EGP20D
EGP20F & EGP20G
1
10
100
1000
0.1
0.01
0.1
1
10
100
Reverse Voltage (V)
t, Pulse Duration (sec.)
Figure 7. Typical Junction Capacitance
Figure 8. Typical Transient Thermal Impedance
Package outline dimensions in inches (millimeters)
DO-204AC (DO-15)
0.034 (0.86)
0.028 (0.71)
Dia.
1.0 (25.4)
min.
0.300 (7.6)
0.230 (5.8)
0.140 (3.6)
0.104 (2.6)
Dia.
1.0 (25.4)
min.
www.vishay.com
4
Document Number 88583
10-Aug-05
