Noise Suppression Products/EMI Suppression Filters > Lead EMIFILr Capacitor Type > for General Small Type
Data Sheet
1
Lead EMIFILr Capacitor Type
DSN6 Series
I
Dimension
7.0 max.
2.54 max.
for General Small Type
DSN6/DSS6 Series
I
IL of Main Items
(50Ω - 50Ω)
0
1
2
8.0 max.
20
Insertion Loss (dB)
8
7
6
5
4
3
1 : 22pF
2 : 33pF
3 : 47pF
4 : 100pF
5 : 270pF
6 :1000pF
7 : 2200pF
8 : 10000pF
40
60
2.5±0.5
5.0±0.5
I
I
Q55 Type : 25.0 min.
Q56 Type : 6.0±1.0
Q54 Type : 4.0±0.5
80
100
120
ø0.6
GND
0.1
1
10
Frequency (MHz)
100
1000
(in mm)
I
Rated Value (p: lead type/packaging code)
Part Number
DSN6NC51H220p
DSN6NC51H330p
DSN6NC51H470p
DSN6NC51H101p
DSN6NC51H271p
DSN6NC51H102p
DSN6NC51H222p
DSN6NZ81H103p
Capacitance
22pF+20%-20%
33pF+20%-20%
47pF+20%-20%
100pF+20%-20%
270pF+20%-20%
1000pF+20%-20%
2200pF+20%-20%
10000pF+80%-20%
Rated Current
6A
6A
6A
6A
6A
6A
6A
6A
Rated Voltage
50Vdc
50Vdc
50Vdc
50Vdc
50Vdc
50Vdc
50Vdc
50Vdc
Operating
Temperature Range
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
DSS6 Series Straight Type
I
Dimension
8.0 max.
2.54 max.
*1
0
*2
7.0 max.
(50Ω - 50Ω)
2
20
Insertion Loss (dB)
1
12
11
10
9
8
5 4
3
1 : 22pF
2 : 33pF
3 : 47pF
4 : 100pF
5 : 150pF
6 : 220pF
7 : 270pF
8 : 470pF
9 : 1000pF
10 : 2200pF
11 : 10000pF
12 : 22000pF
I
IL of Main Items
40
7
6
2.5±0.5
I
5.0±0.5
I
Q55 Type : 25.0 min.
Q56 Type : 6.0±1.0
Q54 Type : 4.0±0.5
60
80
100
ø0.6
GND
120
(in mm)
0.1
1
10
Frequency (MHz)
100
1000
*1 There may be a hole on the top of ferrite beads,
which cause no characteristics deterioration.
*2 Bottom of the ferrite beads may not be level with each other.
Continued on the following page.
o
This data sheet is applied for Lead EMIFILr Capacitor Type used for General Electronics equipment for your design.
!
Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our
products in it may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
2006.11.2
http://www.murata.com/
Noise Suppression Products/EMI Suppression Filters > Lead EMIFILr Capacitor Type > for General Small Type
Data Sheet
Continued from the preceding page.
2
I
Rated Value (p: lead type/packaging code)
Part Number
DSS6NC52A220p
DSS6NC52A330p
DSS6NC52A470p
DSS6NC52A101p
DSS6NC52A151p
DSS6NC52A221p
DSS6NC52A271p
DSS6NC52A471p
DSS6NC52A102p
DSS6NE52A222p
DSS6NZ82A103p
DSS6NF31C223p
Capacitance
22pF+20%-20%
33pF+20%-20%
47pF+20%-20%
100pF+20%-20%
150pF+20%-20%
220pF+20%-20%
270pF+20%-20%
470pF+20%-20%
1000pF+20%-20%
2200pF+80%-20%
10000pF+30%-30%
22000pF+80%-20%
Rated Current
6A
6A
6A
6A
6A
6A
6A
6A
6A
6A
6A
6A
Rated Voltage
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
16Vdc
Operating
Temperature Range
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
DSS6 Series Incrimp Type
I
Dimension
8.0 max.
2.54 max.
*1
10.0 max.
0
1
2
12
11
10
9
8
5
4
3
1 : 22pF
2 : 33pF
3 : 47pF
4 : 100pF
5 : 150pF
6 : 220pF
7 : 270pF
8 : 470pF
9 : 1000pF
10 : 2200pF
11 : 10000pF
12 : 22000pF
I
IL of Main Items
20
Insertion Loss (dB)
*2
40
7 6
60
2.5±0.5
I
T51 Type : 25.0 min.
T41 Type : 4.0±0.5
I
80
5.0±0.5
ø0.6
GND
(in mm)
*1 There may be a hole on the top of ferrite beads,
which cause no characteristics deterioration.
*2 Bottom of the ferrite beads may not be level with each other.
100
120
0.1
1
10
Frequency (MHz)
100
1000
I
Rated Value (p: lead type/packaging code)
Part Number
DSS6NC52A220p
DSS6NC52A330p
DSS6NC52A470p
DSS6NC52A101p
DSS6NC52A151p
DSS6NC52A221p
DSS6NC52A271p
DSS6NC52A471p
DSS6NC52A102p
DSS6NE52A222p
DSS6NZ82A103p
Capacitance
22pF+20%-20%
33pF+20%-20%
47pF+20%-20%
100pF+20%-20%
150pF+20%-20%
220pF+20%-20%
270pF+20%-20%
470pF+20%-20%
1000pF+20%-20%
2200pF+80%-20%
10000pF+30%-30%
Rated Current
6A
6A
6A
6A
6A
6A
6A
6A
6A
6A
6A
Rated Voltage
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
100Vdc
Operating
Temperature Range
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
-25°C to +85°C
Continued on the following page.
o
This data sheet is applied for Lead EMIFILr Capacitor Type used for General Electronics equipment for your design.
!
Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our
products in it may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
2006.11.2
http://www.murata.com/
Noise Suppression Products/EMI Suppression Filters > Lead EMIFILr Capacitor Type > for General Small Type
Data Sheet
Continued from the preceding page.
3
Part Number
DSS6NF31C223p
Capacitance
22000pF+80%-20%
Rated Current
6A
Rated Voltage
16Vdc
Operating
Temperature Range
-25°C to +85°C
I
Equivalent circuit
DSN6 Series
I
Equivalent circuit
DSS6 Series
GND
No polarity.
GND
No polarity.
I
Packaging
Minimum Quantity
Minimum Order Quantity (order in sets only) (Pcs.)
Part Number
Ammo Pack
DS 6 Series
ø320mm
Paper reel
Bulk (Bag)
250
Q55/T51
500
Q54/Q56/T41
2000
—
Lead Type/Packaging
Code
Q55B
Q50B
Q52B
Q54B
Q56B
T41B
T51B
Q91J
Q92J
Q93J
Q91A
Q92A
Q93A
U21A
U31A
Incrimp
Straight
Incrimp
Straight
Lead Type
Lead Length* (in mm)
25.0 min.
4.0±0.5
6.0±1.0
4.0±0.5
6.0±1.0
4.0±0.5
25.0 min.
20.0±1.0
16.5±1.0
18.5±1.0
20.0±1.0
16.5±1.0
18.5±1.0
16.5±1.0
18.5±1.0
Ammo Pack
DSp6, DSN9N/H
All series except
DSS9N/H
DSS6N
Paper Reel (ø320mm)
DSS9N/H
Bulk
Packaging
All series
DST9N/H
DST9N
DSN6/9, DSS6/9
DSS6N
Series
*
Lead Distance between Reference and Bottom Planes except Bulk.
I
!Caution
(Rating)
Do not use products beyond the rated current and
rated voltage as this may create excessive heat
and deteriorate the insulation resistance.
o
This data sheet is applied for Lead EMIFILr Capacitor Type used for General Electronics equipment for your design.
!
Note:
1. This datasheet is downloaded from the website of Murata Manufacturing co., ltd. Therefore, it’s specifications are subject to change or our
products in it may be discontinued without advance notice. Please check with our sales representatives or product engineers before ordering.
2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please approve our product
specifications or transact the approval sheet for product specifications before ordering.
2006.11.2
http://www.murata.com/
