Plastic Film Capacitors
Stacked Metallized PPS Film Chip Capacitor
Type:
ECHU(X)
Stacked metallized PPS film as dielectric with simple
mold-less construction
■Features
•
Small in size (minimum size 1.6 mm
✕
0.8 mm)
•
85 ˚C, 85 %RH, W.V.
✕
1.0 for 500 hours
•
For reflow soldering
•
RoHS directive compliant
■Recommended
Applications
•
Time-constant
•
Filtering
•
Oscillation and resonance
■Explanation
of Part Numbers
1
2
3
4
5
6
7
8
9
10
11
12
E
C
H
U
Rated voltage
Capacitance
X
Cap. Tol. Suffix
Suffix
Product code
Dielectric &
construction
1C 16 VDC
1H 50 VDC
G ±2 %
J ±5 %
■Specifications
Category temp. range
(Including temperature-rise on unit surface)
Rated voltage
Capacitance range
Capacitance tolerance
Withstand voltage
Dissipation factor (tan )
Insulation resistance (IR)
Soldering conditions
−55
℃
to
＋125
℃
16 VDC，50 VDC
Tape width
Reel diameter
❈
Tape width 8 mm
and diameter
8 mm
5
size ø180 mm ø330 mm reel is
prepared.
12 mm
9
size ø330 mm
(50 VDC: 0.12 µF or more: Derating or rated voltage by 1.25 % /
℃at
more than 105
℃)
0.00010 µF to 0.22 µF (E12)
±2
%(G),
±5
%(J)
Between terminals : Rated volt. (VDC)
✕
150 % 60 s
tanδ≦0.6 % (20
℃,
1 kHz)
16 VDC：IR≧3000 MΩ (20
℃,
10 VDC, 60 s)
50 VDC：IR≧3000 MΩ (20
℃,
50 VDC, 60 s)
Reflow soldering : 260 ˚C max. and 95 sec max. at more than 220 ˚C (Temp. at cap. surface)
❈
Please consult us for flow soldering
❈
In case of applying voltage in alternating current (50 Hz or 60 Hz sine wave) to a capacitor with DC rated voltage, please
refer to the page of “Permissible voltage (R.M.S) in alternating current corresponding to DC rated voltage”.
■Construction
■Dimensions
in mm (not to scale)
saize
code
K1
J1
J2
H1
H2
H3
G1
G2
G3
E1
E2
D1
D3
D4
L
1.6
2.0
2.0
3.2
3.2
3.2
3.2
3.2
3.2
4.8
4.8
6.0
6.0
6.0
W
0.8
1.25
1.25
1.6
1.6
1.6
2.5
2.5
2.5
3.3
3.3
4.1
4.1
4.1
H
0.7
0.9
1.1
0.9
1.1
1.5
1.1
1.5
2.1
1.5
2.1
1.9
2.5
2.8
e
0.35
0.45
0.45
0.65
0.65
0.65
0.65
0.65
0.65
0.80
0.80
0.80
0.80
0.80
g
≧0.4
≧0.6
≧0.6
≧1.0
≧1.0
≧1.0
≧1.0
≧1.0
≧1.0
≧2.0
≧2.0
≧2.0
≧2.0
≧2.0
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
Plastic Film Capacitors
■Taping
Specification for Automatic Mounting
Refer to the page of taping specifications
■Rating,
Dimensions & Quantity/Reel
Rated volt. 16 VDC
Cap. (µF)
0.00010
0.00012
0.00015
0.00018
0.00022
0.00027
0.00033
0.00039
0.00047
0.00056
0.00068
0.00082
0.0010
0.0012
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
Part No.
ECHU1C101□X5
ECHU1C121□X5
ECHU1C151□X5
ECHU1C181□X5
ECHU1C221□X5
ECHU1C271□X5
ECHU1C331□X5
ECHU1C391□X5
ECHU1C471□X5
ECHU1C561□X5
ECHU1C681□X5
ECHU1C821□X5
ECHU1C102□X5
ECHU1C122□X5
ECHU1C152□X5
ECHU1C182□X5
ECHU1C222□X5
ECHU1C272□X5
ECHU1C332□X5
ECHU1C392□X5
ECHU1C472□X5
ECHU1C562□X5
ECHU1C682□X5
ECHU1C822□X5
ECHU1C103□X5
ECHU1C123□X5
ECHU1C153□X5
ECHU1C183□X5
ECHU1C223□X5
ECHU1C273□X5
ECHU1C333□X5
ECHU1C393□X5
ECHU1C473□X5
ECHU1C563□X5
ECHU1C683□X5
ECHU1C823□X5
ECHU1C104□X5
↑
Dimensions (mm)
●Capacitance
tolerance : ± 2 % (G), ± 5 % (J)
Rated volt. 50 VDC
Size
Code
L
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
2.0
2.0
2.0
2.0
2.0
2.0
2.0
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
W
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.6
1.6
1.6
1.6
1.6
1.6
1.6
1.6
2.5
2.5
2.5
2.5
H
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.9
0.9
0.9
0.9
0.9
1.1
1.1
0.9
0.9
0.9
0.9
1.1
1.1
1.5
1.5
1.5
1.5
2.1
2.1
Q'ty
Part No.
Dimensions (mm)
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
K1
J1
J1
J1
J1
J1
J2
J2
H1
H1
H1
H1
H2
H2
H3
H3
G2
G2
G3
G3
ECHU1H101□X5
ECHU1H121□X5
ECHU1H151□X5
ECHU1H181□X5
ECHU1H221□X5
ECHU1H271□X5
ECHU1H331□X5
ECHU1H391□X5
4000 ECHU1H471□X5
ECHU1H561□X5
ECHU1H681□X5
ECHU1H821□X5
ECHU1H102□X5
ECHU1H122□X5
ECHU1H152□X5
ECHU1H182□X5
ECHU1H222□X5
ECHU1H272□X5
ECHU1H332□X5
ECHU1H392□X5
ECHU1H472□X5
ECHU1H562□X5
ECHU1H682□X5
ECHU1H822□X5
3000 ECHU1H103□X5
ECHU1H123□X5
ECHU1H153□X5
ECHU1H183□X5
ECHU1H223□X5
ECHU1H273□X5
ECHU1H333□X5
ECHU1H393□X5
ECHU1H473□X9
2000 ECHU1H563□X9
ECHU1H683□X9
ECHU1H823□X9
ECHU1H104□X9
ECHU1H124□X9
ECHU1H154□X9
ECHU1H184□X9
ECHU1H224□X9
↑
L
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
4.8
4.8
4.8
4.8
4.8
6.0
6.0
6.0
6.0
W
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.25
1.6
1.6
1.6
1.6
1.6
1.6
1.6
2.5
2.5
2.5
2.5
2.5
2.5
2.5
3.3
3.3
3.3
3.3
3.3
4.1
4.1
4.1
4.1
H
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
0.9
1.1
1.1
1.1
1.1
1.5
1.5
1.5
2.1
2.1
1.5
1.5
1.5
2.1
2.1
1.9
1.9
2.5
2.8
Size
Code
Q'ty
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
J1
H1
H1
H1
H1
H1
H2
H2
G1
G1
G2
G2
G2
G3
G3
E1
E1
E1
E2
E2
D1
D1
D3
D4
3000
2000
3000
2000
Cap. tol. code
■Recommended
for Land Dimensions (mm)
Land dimensions
Size
Code
A
Reflow soldering
B
C
K1
J1,J2
H1,H2,H3
G1,G2,G3
E1,E2
D1,D3,D4
0.6
0.8
1.8
1.8
3.0
4.0
2.0
2.4
3.6
3.6
5.6
7.0
0.7
1.1
1.4
2.3
3.0
3.8
❈
It is not warrantable that you can mount the capacitor without trouble under all the mounting condition when
“Recommender for Land dimensions” is adopted.
Design, Specifications are subject to change without notice.
Ask factory for technical specifications before purchase and/or use.
Whenever a doubt about safety arises from this product, please inform us immediately for technical consultation without fail.
