Aluminum Electrolytic Capacitors/ ED
Snap-in Type
Series:
ED
Type:
TS
■
Features
●
Endurance : 105 °C 3000 h
●
High ripple current capability in high frequency range.
●
RoHS directive compliant
■
Specifications
Category Temp. Range
Rated W.V. Range
Nominal Cap. Range
Capacitance Tolerance
DC Leakage Current
tan
δ
–40 °C to + 105 °C
200 V.DC to 250 V.DC
220 µF to 2200 µF
±20 % (120 Hz/+20 °C)
3 CV (µA) max. After 5 minutes application of rated working voltage at +20 °C
C : Capacitance (µF) V: W.V. (V.DC)
120
0.70
500
0.85
1 k
0.90
10 k to
1.00
–25 °C to +105 °C
400 V.DC to 450 V.DC
56 µF to 560 µF
Please see the attached standard products list
Frequency (Hz)
50
60
100
Frequency Correction
Factor for Ripple Current Correction Factor
0.5
0.55
0.68
After 3000 hours application of DC voltage with specified ripple current (< rated DC working
voltage) at +105 °C±2 °C, the capacitors shall meet the following limits.
Endurance
Capacitance change
<±20
% of initial measured value
tan
δ
<
200 % of initial specified value
DC leakage current
<
initial specified value
After storage for 1000 hours at +105 °C±2 °C within no voltage applied and then being stabilized
at +20 °C, capacitors shall meet the limits specified in Endurance (With voltage treatment)
Shelf Life
■
Dimensions in mm (not to scale)
Polarity bar
Sleeve
(1
(mm)
2-φ2.0±0.1
0.0
)
10
.0
±
0.1
φD+1.0
max.
Vent
L+2.0 max.
Rated voltage etc. indicate to sleeve.
4.0±0.5
(φD)
Recommended PWB piercing plan
0.8
–0.1
(3.5)
4.0±0.5
+0.2
2.0 max.
Terminal
(t=0.8)
1.5±0.2
Top of spin
Standard terminal type does not require
terminal trimming process.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Jul. 2008
Aluminum Electrolytic Capacitors/ ED
■
Standard Products
Case size
W.V.
Cap.
(120 Hz)
(±20 %)
(µF)
270
330
390
470
560
Dia.
(mm)
22
22
22
25
22
25
22
25
30
22
25
30
22
25
30
35
25
30
35
30
35
30
35
35
35
22
22
25
22
25
22
25
30
22
25
30
25
30
35
25
30
35
30
35
30
35
35
35
Length
(mm)
25
30
30
25
35
30
40
30
25
45
35
30
50
40
30
25
45
35
30
40
35
50
40
45
50
30
30
25
35
30
40
30
25
45
35
30
40
30
25
45
35
30
40
35
45
40
45
50
Part No.
PET sleeve
Terminal Length
4.0 mm
(Without Top Plate)
EETED2D271HJ
EETED2D331HJ
EETED2D391HJ
EETED2D391JJ
EETED2D471HJ
EETED2D471JJ
EETED2D561HJ
EETED2D561JJ
EETED2D561KJ
EETED2D681HJ
EETED2D681JJ
EETED2D681KJ
EETED2D821HJ
EETED2D821JJ
EETED2D821KJ
EETED2D821LJ
EETED2D102JJ
EETED2D102KJ
EETED2D102LJ
EETED2D122KJ
EETED2D122LJ
EETED2D152KJ
EETED2D152LJ
EETED2D182LJ
EETED2D222LJ
EETED2Q271HJ
EETED2Q331HJ
EETED2Q331JJ
EETED2Q391HJ
EETED2Q391JJ
EETED2Q471HJ
EETED2Q471JJ
EETED2Q471KJ
EETED2Q561HJ
EETED2Q561JJ
EETED2Q561KJ
EETED2Q681JJ
EETED2Q681KJ
EETED2Q681LJ
EETED2Q821JJ
EETED2Q821KJ
EETED2Q821LJ
EETED2Q102KJ
EETED2Q102LJ
EETED2Q122KJ
EETED2Q122LJ
EETED2Q152LJ
EETED2Q182LJ
Specification
Ripple
tan
δ
Current
(120 Hz)
(50 kHz)
(+20 °C)
(+105 °C)
max.
(A r.m.s.)
2.03
0.15
2.23
0.15
2.44
0.15
2.44
0.15
2.64
0.15
2.64
0.15
3.05
0.15
3.05
0.15
3.05
0.15
3.45
0.15
3.45
0.15
3.45
0.15
3.76
0.15
3.76
0.15
3.76
0.15
3.76
0.15
4.06
0.15
4.06
0.15
4.06
0.15
4.47
0.15
4.47
0.15
5.08
0.15
5.08
0.15
5.48
0.15
5.89
0.15
2.03
0.15
2.23
0.15
2.23
0.15
2.44
0.15
2.44
0.15
2.64
0.15
2.64
0.15
2.64
0.15
3.05
0.15
3.05
0.15
3.05
0.15
3.45
0.15
3.45
0.15
3.45
0.15
3.76
0.15
3.76
0.15
3.76
0.15
4.06
0.15
4.06
0.15
4.47
0.15
4.47
0.15
5.08
0.15
5.48
0.15
Min. Packaging Q'ty
(V. DC)
680
200
820
1000
1200
1500
½
½
1800
2200
270
330
390
470
560
220
680
820
1000
1200
½
½
1500
1800
(pcs)
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
200
100
100
100
100
100
100
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
200
100
100
100
100
100
100
Endurance : 105 °C 3000 h
Terminal Pitch : 10 mm
½
When capacitors of
φ35
45L and
φ35
50L are mounted on PWB, reinforce them with mounting clamp or adhesives.
(Avoid using adhesives including halogenated compositions.)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Jul. 2008
Aluminum Electrolytic Capacitors/ ED
■
Standard Products
Case size
W.V.
Cap.
(120 Hz)
(±20 %)
(µF)
220
270
330
390
Dia.
(mm)
22
22
25
22
25
22
25
30
22
25
30
25
30
35
25
30
35
30
35
30
35
35
35
22
22
25
22
25
22
25
30
22
25
30
22
25
30
35
25
30
35
30
35
30
35
35
35
Length
(mm)
30
30
25
35
30
40
30
25
45
35
30
40
30
25
45
35
30
40
35
50
40
45
50
25
30
25
35
30
40
30
25
45
35
30
50
40
30
25
45
35
30
40
30
45
35
40
45
Part No.
PET sleeve
Terminal Length
4.0 mm
(Without Top Plate)
EETED2E221HJ
EETED2E271HJ
EETED2E271JJ
EETED2E331HJ
EETED2E331JJ
EETED2E391HJ
EETED2E391JJ
EETED2E391KJ
EETED2E471HJ
EETED2E471JJ
EETED2E471KJ
EETED2E561JJ
EETED2E561KJ
EETED2E561LJ
EETED2E681JJ
EETED2E681KJ
EETED2E681LJ
EETED2E821KJ
EETED2E821LJ
EETED2E102KJ
EETED2E102LJ
EETED2E122LJ
EETED2E152LJ
EETED2G820HJ
EETED2G101HJ
EETED2G101JJ
EETED2G121HJ
EETED2G121JJ
EETED2G151HJ
EETED2G151JJ
EETED2G151KJ
EETED2G181HJ
EETED2G181JJ
EETED2G181KJ
EETED2G221HJ
EETED2G221JJ
EETED2G221KJ
EETED2G221LJ
EETED2G271JJ
EETED2G271KJ
EETED2G271LJ
EETED2G331KJ
EETED2G331LJ
EETED2G391KJ
EETED2G391LJ
EETED2G471LJ
EETED2G561LJ
Specification
Ripple
tan
δ
Current
(120 Hz)
(50 kHz)
(+20 °C)
(+105 °C)
max.
(A r.m.s.)
1.83
0.15
2.03
0.15
2.03
0.15
2.23
0.15
2.23
0.15
2.44
0.15
2.44
0.15
2.44
0.15
2.64
0.15
2.64
0.15
2.64
0.15
3.05
0.15
3.05
0.15
3.05
0.15
3.45
0.15
3.45
0.15
3.45
0.15
3.76
0.15
3.76
0.15
4.06
0.15
4.06
0.15
4.47
0.15
5.08
0.15
1.14
0.15
1.30
0.15
1.30
0.15
1.46
0.15
1.46
0.15
1.53
0.15
1.53
0.15
1.53
0.15
1.60
0.15
1.60
0.15
1.60
0.15
2.03
0.15
2.03
0.15
2.03
0.15
2.03
0.15
2.23
0.15
2.23
0.15
2.23
0.15
2.44
0.15
2.44
0.15
2.64
0.15
2.64
0.15
2.84
0.15
3.05
0.15
Min. Packaging Q'ty
(V. DC)
470
250
560
680
820
1000
½
½
1200
1500
82
100
120
150
180
400
220
270
330
390
½
470
560
(pcs)
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
200
100
100
100
100
100
100
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
200
100
200
100
100
100
100
Endurance : 105 °C 3000 h
Terminal Pitch : 10 mm
½
When capacitors of
φ35
45L and
φ35
50L are mounted on PWB, reinforce them with mounting clamp or adhesives.
(Avoid using adhesives including halogenated compositions.)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Jul. 2008
Aluminum Electrolytic Capacitors/ ED
■
Standard Products
Case size
W.V.
Cap.
(120 Hz)
(±20 %)
(µF)
68
82
100
120
150
Dia.
(mm)
22
22
25
22
25
22
25
22
25
30
22
25
30
35
25
30
35
25
30
35
30
35
30
35
35
22
22
25
22
25
22
25
22
25
30
22
25
30
35
22
25
30
35
25
30
35
30
35
30
35
35
35
Length
(mm)
25
30
25
30
25
35
30
40
35
25
45
40
30
25
45
35
30
50
40
30
45
35
50
40
45
25
30
25
30
25
35
30
40
35
25
45
40
30
25
50
40
30
25
45
35
30
40
35
50
40
40
50
Part No.
PET sleeve
Terminal Length
4.0 mm
(Without Top Plate)
EETED2S680HJ
EETED2S820HJ
EETED2S820JJ
EETED2S101HJ
EETED2S101JJ
EETED2S121HJ
EETED2S121JJ
EETED2S151HJ
EETED2S151JJ
EETED2S151KJ
EETED2S181HJ
EETED2S181JJ
EETED2S181KJ
EETED2S181LJ
EETED2S221JJ
EETED2S221KJ
EETED2S221LJ
EETED2S271JJ
EETED2S271KJ
EETED2S271LJ
EETED2S331KJ
EETED2S331LJ
EETED2S391KJ
EETED2S391LJ
EETED2S471LJ
EETED2W560HJ
EETED2W680HJ
EETED2W680JJ
EETED2W820HJ
EETED2W820JJ
EETED2W101HJ
EETED2W101JJ
EETED2W121HJ
EETED2W121JJ
EETED2W121KJ
EETED2W151HJ
EETED2W151JJ
EETED2W151KJ
EETED2W151LJ
EETED2W181HJ
EETED2W181JJ
EETED2W181KJ
EETED2W181LJ
EETED2W221JJ
EETED2W221KJ
EETED2W221LJ
EETED2W271KJ
EETED2W271LJ
EETED2W331KJ
EETED2W331LJ
EETED2W391LJ
EETED2W471LJ
Specification
Ripple
tan
δ
Current
(120 Hz)
(50 kHz)
(+20 °C)
(+105 °C)
max.
(A r.m.s.)
1.08
0.15
1.14
0.15
1.14
0.15
1.30
0.15
1.30
0.15
1.46
0.15
1.46
0.15
1.53
0.15
1.53
0.15
1.53
0.15
1.60
0.15
1.60
0.15
1.60
0.15
1.60
0.15
2.03
0.15
2.03
0.15
2.03
0.15
2.40
0.15
2.40
0.15
2.40
0.15
2.54
0.15
2.54
0.15
2.73
0.15
2.73
0.15
3.18
0.15
0.95
0.15
1.08
0.15
1.08
0.15
1.14
0.15
1.14
0.15
1.30
0.15
1.30
0.15
1.46
0.15
1.46
0.15
1.46
0.15
1.53
0.15
1.53
0.15
1.53
0.15
1.53
0.15
1.60
0.15
1.60
0.15
1.60
0.15
1.60
0.15
2.03
0.15
2.03
0.15
2.03
0.15
2.45
0.15
2.45
0.15
2.64
0.15
2.64
0.15
2.82
0.15
3.53
0.15
Min. Packaging Q'ty
(V. DC)
420
180
220
270
330
390
½
470
56
68
82
100
120
150
450
180
220
270
330
½
390
470
(pcs)
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
200
200
100
200
100
100
100
100
100
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
100
200
100
100
100
100
100
100
Endurance : 105 °C 3000 h
Terminal Pitch : 10 mm
½
When capacitors of
φ35
45L and
φ35
50L are mounted on PWB, reinforce them with mounting clamp or adhesives.
(Avoid using adhesives including halogenated compositions.)
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
Jul. 2008
京公网安备 11010802033920号
EEWORLD
