WSLP3921, WSLP5931
www.vishay.com
Vishay Dale
Power Metal Strip
®
Resistors, Very High Power (to 15 W),
Low Value (down to 0.0001
),
Surface Mount
FEATURES
• All welded construction of the Power Metal
Strip
®
resistors are ideal for all types of current
sensing,
voltage
division
and
pulse
applications
• Proprietary processing technique produces
extremely low resistance values, down to
0.0001
• Sulfur resistance by construction that is
unaffected by high sulfur environments
DESIGN SUPPORT TOOLS AVAILABLE
3D Models
• Specially selected and stabilized materials allow for high
power rating (to 15 W)
• Very low inductance 0.5 nH to 5 nH
• Low thermal EMF (< 3 μV/°C)
• AEC-Q200 qualified
(1)
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
D
D
3
3
Design Tools
Notes
• Follow link to Overview of Automotive Grade Products for more details:
www.vishay.com/doc?49924
(1)
Flame retardance test may not be applicable to some resistor technologies
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
WSLP3921
WSLP3921
WSLP5931
WSLP5931
WSLP5931
WSLP5931
SIZE
3921
3921
5931
5931
5931
5931
POWER RATING
P
70 °C
W
5.0
9.0
7.0
8.0
10.0
15.0
TOLERANCE
%
1.0, 5.0
1.0, 5.0
1.0, 5.0
1.0, 5.0
1.0, 5.0
1.0, 5.0
RESISTANCE VALUE
RANGE
2m to 4m
0.2m to 1m
3m
2m
0.2m to 1m
0.1m
RESISTANCE VALUES
CURRENTLY AVAILABLE
(1)
2m, 2.5m, 3m, 4m
0.2m, 0.3m, 0.5m, 0.7m, 1m
3m
2m
0.2m, 0.3m, 0.5m, 1m
0.1m
WEIGHT
(typical)
g/1000 pieces
281
281
398
398
398
398
Note
(1)
Other values may be available, contact factory
GLOBAL PART NUMBER INFORMATION
GLOBAL PART NUMBERING: WSLP39212L000FEA
(visit
www.vishay.net
Vishay Dale parts numbering manual for all options)
W
S
L
P
3
9
2
1
2
L
0
0
0
F
E
A
SPECIAL
(3)
(up to 2 digits)
Reserved for
future specials
GLOBAL MODEL
(8 digits)
WSLP3921
WSLP5931
RESISTANCE VALUE
(1)
(5 digits)
L
= m
L5000
= 0.0005
2L000
= 0.002
TOLERANCE CODE
(1 digit)
F
= ± 1.0 %
J
= ± 5.0 %
PACKAGING CODE
(2)
(2 digits)
EA
= lead (Pb)-free, tape/reel
EK
= lead (Pb)-free, bulk
Note
(1)
WSL marking (www.vishay.com/doc?30327)
(2)
Packaging code: EB (lead (Pb)-free) is non-standard packaging codes designating 1000 piece reels. These non-standard packaging codes
are identical to our standard EA (lead (Pb)-free), except that they have a package quantity of 1000 pieces
(3)
Follow link for customization capabilities:
www.vishay.com/doc?48163
Revision: 14-Mar-2019
Document Number: 30176
1
For technical questions, contact:
ww2bresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
WSLP3921, WSLP5931
www.vishay.com
Vishay Dale
RESISTOR CHARACTERISTICS
WSLP3921
WSLP5931
+125 for 0.2 m
± 300 for 0.1 m
± 175 for 0.3 m, 0.5 m and 0.7 m
± 225 for 0.2 m
± 175 for 0.3 m and 0.5 m
± 75 for 1 m to 4 m and 2.5 m
± 75 for 1 m to 4 m
< 20
-65 to +170
(P x
R)
1/2
TECHNICAL SPECIFICATIONS
PARAMETER
Component temperature coefficient
(including terminal)
(1)
TCR measured from -55 °C to 150 °C
Element TCR
(2)
Operating temperature range
Maximum working voltage
(3)
UNIT
ppm/°C
ppm/°C
°C
V
Notes
(1)
Component TCR - total TCR that includes the TCR effects of the resistor element and the copper terminal
(2)
Element TCR - only applies to the alloy used for the resistor element
(3)
Maximum working voltage - the WSL is not voltage sensitive, but is limited by power / energy dissipation and is also not ESD sensitive
DIMENSIONS
in inches (millimeters)
H
L
T
Typical
sensing
traces
W
D
1
3
2
1) Resistive element: Fe-Cr
(element material used is
dependent on resistance
value)
2) Terminal:
solid
copper
3) Terminal / element weld
I
b
d
Notes
• 3D models available: 3921 model
www.vishay.com/doc?30315;
5931 model
www.vishay.com/doc?30317
• Surface mount solder profile recommendations:
www.vishay.com/doc?31052
DIMENSIONS
in inches (millimeters)
SOLDER PAD DIMENSIONS
in inches (millimeters)
MODEL
L
W
H
T
d
b
l
0.394 ± 0.010
0.205 ± 0.010
0.020
0.080 ± 0.010
0.106 ± 0.010
0.244 ± 0.010
0.220 ± 0.005
WSLP3921
(10.0 ± 0.254)
(5.20 ± 0.254)
(0.5)
(2.00 ± 0.254)
(2.70 ± 0.254)
(6.20 ± 0.254)
(5.60 ± 0.13)
0.591 ± 0.010
0.305 ± 0.010
0.020
0.157 ± 0.010
0.205 ± 0.010
0.344 ± 0.010
0.220 ± 0.005
WSLP5931
(15.0 ± 0.254)
(7.75 ± 0.254)
(0.5)
(4.00 ± 0.254)
(5.20 ± 0.254)
(8.75 ± 0.254)
(5.60 ± 0.13)
GLOBAL MODEL
RESISTANCE VALUE
(m)
0.2
0.3
0.5
0.7
1.0
2.0
3.0
4.0
0.1
0.2
0.3
0.5
1.0
2.0
3.0
THERMAL RESISTANCE
(1)
(°C/W)
2.7
3.8
5.8
6.3
10.9
12.0
20.7
22.8
2.4
2.4
3.5
5.7
7.2
13.2
19.3
“D” THICKNESS
(Inches)
0.0560
0.0510
0.0300
0.0205
0.0150
0.0270
0.0170
0.0130
0.0490
0.0490
0.0300
0.0180
0.0330
0.0155
0.0105
ELEMENT MATERIAL
WSLP3921
Mn-Cu-Sn
WSLP3921
Mn-Cu
WSLP3921
Mn-Cu
WSLP3921
Mn-Cu
WSLP3921
Mn-Cu
WSLP3921
Fe-Cr
WSLP3921
Fe-Cr
WSLP3921
Fe-Cr
WSLP5931
Mn-Cu-Sn
WSLP5931
Mn-Cu
WSLP5931
Mn-Cu
WSLP5931
Mn-Cu
WSLP5931
Fe-Cr
WSLP5931
Fe-Cr
WSLP5931
Fe-Cr
Note
(1)
The full power rating of Power Metal Strip resistors are dependent upon the ability of the circuit board to dissipate the heat energy created
in the resistance element. It is recommended to follow common design practices for power semiconductors that ensure the junction
temperature is maintained with in thermal limits by using large pad surfaces, thermal vias, heavier copper weights, internal layers as well as
other thermal spreading features. The Thermal resistance values provided function in the same manner as junction to terminal temperature
Revision: 14-Mar-2019
Document Number: 30176
2
For technical questions, contact:
ww2bresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
WSLP3921, WSLP5931
www.vishay.com
DERATING - AMBIENT TEMPERATURE
Rated Power in %
120
100
80
60
40
20
0
-65 -50
Vishay Dale
DERATING - TERMINAL TEMPERATURE
P/P
Norm
in %
120
100
80
60
40
20
0
Stability < 1.0 %
Stability < 0.5 %
0
20
40
60
80
100
120
140
160
180
-25
0
25
50
70
100
125
150 170
Ambient Temperature in °C
Terminal Temperature
T
K
in °C
PULSE CAPABILITY
click to get started
VE
TI
A
TR
S
L
U
IL
S
S
E
O
RP
PU
Y
NL
O
www.vishay.com/resistors/power-metal-strip-calculator
PERFORMANCE
TEST
Thermal shock
Short time overload
Low temperature operation
High temperature storage
Bias humidity
Mechanical shock
Vibration
Load life at 70 °C
Resistance to solder heat
Moisture resistance
CONDITIONS OF TEST
-55 °C to +150 °C, 1000 cycles, 15 min at each extreme
5 x rated power for 5 s
-65 °C for 24 h
1000 h at +170 °C
+85 °C, 85 % RH, 10 % bias, 1000 h
100
g’s
for 6 ms, 5 pulses
Frequency varied 10 Hz to 2000 Hz in 1 min, 3 directions, 12 h
1000 h, 1.5 h “ON”, 0.5 h “OFF”
3 x at 250 °C ± 5 °C for 30 s ± 5 s
MIL-STD-202, method 106, 0 % power, 7b not required
TEST LIMITS
± 1.0 %
± 0.5 %
± 0.5 %
± 1.0 %
± 0.5 %
± 0.5 %
± 0.5 %
± 1.0 %
± 0.5 %
± 1.0 %
PACKAGING
MODEL
WSLP3921
WSLP5931
REEL
TAPE WIDTH
16 mm/embossed plastic
24 mm/embossed plastic
DIAMETER
330 mm/13"
330 mm/13"
PIECES/REEL
3000
1500
CODE
EA
EA
Notes
• Embossed carrier tape per EIA-481
(1)
Additional packaging details at
www.vishay.com/doc?20051
Revision: 14-Mar-2019
Document Number: 30176
3
For technical questions, contact:
ww2bresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
