T-1
3/4
(5 mm) Oval Precision
Optical Performance LED Lamps
Technical Data
Sun Power Series
HLMP-ABxx HLMP-BBxx
HLMP-ADxx HLMD-BDxx
HLMP-AGxx HLMP-BGxx
HLMP-ALxx HLMP-BLxx
HLMP-AMxx HLMP-BMxx
Benefits
• Viewing Angle Designed for
Wide Field of View
Applications
• Red, Green, and Blue
Radiation Patterns Matched
for Full Color Signs
• Superior Outdoor
Environmental Performance
Features
• Smooth, Consistent Spatial
Radiation Patterns
• Wide Viewing Angle
Major Axis 70˚
Minor Axis 35˚
• High Luminous Output
• Two Red and Amber
Intensity Levels Available:
AlInGaP (bright) and
AlInGaP II (brightest)
• Colors:
472 nm Blue
526 nm Green
590/592 nm Amber
626/630 nm Red
• Superior Resistance to
Moisture
• UV Resistant Epoxy
• Choice of Package Options
Description
These Precision Optical
Performance oval LEDs are
specifically designed for Full
Color/Video and Passenger
Information signs. The oval
shaped radiation pattern (35˚ x
70˚) and high luminous intensity
ensure that these devices are
excellent for wide field of view
outdoor applications where a wide
viewing angle and readability in
sunlight are essential. These
lamps have very smooth, matched
radiation patterns ensuring
consistent color mixing in full
color applications, and message
uniformity across the viewing
angle of the sign.
High efficiency LED materials are
used in these lamps: Aluminum
Indium Gallium Phosphide
(AlInGaP) for amber and red, and
Indium Gallium Nitride (InGaN)
for blue and green. There are two
families of red and amber lamps,
AlInGaP and the higher
performance AlInGaP II. Each
lamp is made with an advanced
optical grade epoxy offering
superior high temperature and
high moisture resistance in
outdoor applications. The
package epoxy contains both
UV-a and UV-b inhibitors to
reduce the effects of long term
exposure to direct sunlight.
Designers can select parallel
(where the axis of the leads is
parallel to the wide axis of the
oval radiation pattern) or
perpendicular orientation.
Designers can also choose
between lamps with or without
standoffs. The red and amber
lamps are available in tinted
versions.
Applications
• Full Color/Video Signs
• Variable Message Signs
Passenger Information
Advertising
Time/Temperature
CAUTION: The Blue and Green LEDs are Class 1 ESD sensitive. Please observe appropriate
precautions during handling and processing. Refer to Agilent Application Note AN-1142 for
additional details.
2
Package Dimensions
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
0.70 (0.028)
MAX.
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
2.54 ± 0.38
(0.100 ± 0.015)
A
CATHODE
LEAD
31.60 MIN.
(1.244)
1.00 MIN.
(0.039)
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
1.50 ±0.15
(0.059 ± 0.006)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
0.70 (0.028)
MAX.
2.54 ± 0.38
(0.100 ± 0.015)
B
+ 0.13
11.70 – 0.08
CATHODE
LEAD
31.60 MIN.
(1.244)
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
0.70 (0.028)
MAX.
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
2.54 ± 0.38
(0.100 ± 0.015)
1.00 MIN.
(0.039)
(
+ 0.005
0.461 – 0.003
)
C
CATHODE
LEAD
31.60
MIN.
(1.244)
1.00 MIN.
(0.039)
8.71 ± 0.20
(0.343 ± 0.008)
5.00 ± 0.20
(0.197 ± 0.008)
1.50 ±0.15
(0.059 ± 0.006)
0.50 ± 0.10 SQ. TYP.
(0.020 ± 0.004)
0.70 (0.028)
MAX.
2.54 ± 0.38
(0.100 ± 0.015)
D
CATHODE
LEAD
31.60 MIN.
(1.244)
1.00 MIN.
(0.039)
NOTES:
1. ALL DIMENSIONS ARE IN MILLIMETERS (INCHES).
2. LEADS ARE MILD STEEL, SOLDER DIPPED.
3. TAPERS SHOWN AT TOP OF LEADS (BOTTOM OF LAMP PACKAGE) INDICATE AN
EPOXY MENISCUS THAT MAY EXTEND ABOUT 1 mm (0.040 IN.) DOWN THE LEADS.
4. RECOMMENDED PC BOARD HOLE DIAMETERS:
– LAMP PACKAGES A AND C WITHOUT STAND-OFFS: FLUSH MOUNTING AT BASE
OF LAMP PACKAGE = 1.143/1.067 mm (0.044/0.042 IN.).
– LAMP PACKAGES B AND D WITH STAND-OFFS: MOUNTING AT LEAD STAND-OFFS.
3
Part Numbering Scheme
HLMP-(1)(2)(3)(4)
where (1) = Leadframe
Orientation
“A” = Parallel
“B” = Perpendicular
where (2) = Color Option
“L” = 590/592 nm Amber
“G” = 626 nm Red
“D” = 630 nm Red
“M” = 525 nm Green
“B” = 472 nm Blue
where (3) = Standoff Option
“0” = Without
“1” = With
where (4) = Tint Option
“1” or “6” = Matching Color
Tints
Refer to selection guides for
available combinations.
AlInGaP Device Selection Guide (Amber, Red)
Color and Luminous Luminous
Typical
Intensity Intensity
Dominant I
V
(mcd) at I
V
(mcd) at
Leads
Wavelength
20 mA
20 mA
Tinting
with
λ
d
(nm)
Min.
Typ.
Type Stand-Offs
Amber 590
Amber 590
Amber 590
Amber 590
Red 626
Red 626
Red 626
Red 626
270
270
270
270
270
270
270
270
600
600
600
600
600
600
600
600
Amber
Amber
Amber
Amber
Red
Red
Red
Red
No
Yes
No
Yes
No
Yes
No
Yes
Part Number
HLMP-AL01
HLMP-AL11
HLMP-BL01
HLMP-BL11
HLMP-AG01
HLMP-AG11
HLMP-BG01
HLMP-BG11
Lead
Frame
Orientation
Parallel
Parallel
Perpendicular
Perpendicular
Parallel
Parallel
Perpendicular
Perpendicular
Package
Drawing
A
B
C
D
A
B
C
D
Notes:
1. The luminous intensity is measured on the mechanical axis of the lamp package.
2. The optical axis is closely aligned with the package mechanical axis.
3. The dominant wavelength
λ
d
, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.
4
AlInGaP2 Device Selection Guide (Amber, Red)
Color and Luminous Luminous
Typical
Intensity Intensity
Dominant I
V
(mcd) at I
V
(mcd) at
Leads
Wavelength
20 mA
20 mA
Tinting
with
λ
d
(nm)
Min.
Typ.
Type Stand-Offs
Amber 592
Amber 592
Amber 592
Amber 592
Red 630
Red 630
Red 630
Red 630
590
590
590
590
590
590
590
590
1300
1300
1300
1300
1300
1300
1300
1300
Amber
Amber
Amber
Amber
Red
Red
Red
Red
No
Yes
No
Yes
No
Yes
No
Yes
Part Number
HLMP-AL06
HLMP-AL16
HLMP-BL06
HLMP-BL16
HLMP-AD06
HLMP-AD16
HLMP-BD06
HLMP-BD16
Lead
Frame
Orientation
Parallel
Parallel
Perpendicular
Perpendicular
Parallel
Parallel
Perpendicular
Perpendicular
Package
Drawing
A
B
C
D
A
B
C
D
InGaN Device Selection Guide (Blue, Green)
Color and Luminous Luminous
Typical
Intensity Intensity
Dominant I
V
(mcd) at I
V
(mcd) at
Leads
Wavelength
20 mA
20 mA
Tinting
with
λ
d
(nm)
Min.
Typ.
Type Stand-Offs
Green 526
Green 526
Green 526
Green 526
Blue 472
Blue 472
Blue 472
Blue 472
590
590
590
590
205
205
205
205
1300
1300
1300
1300
400
400
400
400
Green
Green
Green
Green
Blue
Blue
Blue
Blue
No
Yes
No
Yes
No
Yes
No
Yes
Part Number
HLMP-AM01
HLMP-AM11
HLMP-BM01
HLMP-BM11
HLMP-AB01
HLMP-AB11
HLMP-BB01
HLMP-BB11
Lead
Frame
Orientation
Parallel
Parallel
Perpendicular
Perpendicular
Parallel
Parallel
Perpendicular
Perpendicular
Package
Drawing
A
B
C
D
A
B
C
D
Notes:
1. The luminous intensity is measured on the mechanical axis of the lamp package.
2. The optical axis is closely aligned with the package mechanical axis.
3. The dominant wavelength
λ
d
, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.
5
Absolute Maximum Ratings at 25˚C
Amber and Red
DC Forward Current
Peak Pulsed Forward Current
Average Forward Current (Pulsed Operation)
Reverse Voltage (I
R
= 100
µA)
Reverse Voltage (I
R
= 10
µA)
Power Dissipation
LED Junction Temperature
Operating Temperature Range
Storage Temperature Range
Soldering Temperature
120 mW
130˚C
–40˚C to +100˚C
–40˚C to +120˚C
260˚C for 5 sec.
50 mA
100 mA
30 mA
[1]
5V
5V
120 mW
100˚C
–40˚C to +80˚C
–40˚C to +100˚C
260˚C for 5 sec.
Blue and Green
30 mA
100 mA
30 mA
Note:
1. Higher pulsed average currents can be used under certain conditions. Refer to Agilent Application Brief I-024.
Intensity Bin Limits
(mcd at 20 mA)
Bin
Name
G
H
J
K
L
M
N
P
Q
R
S
Min.
140
180
240
310
400
520
680
880
1150
1500
1900
Max.
180
240
310
400
520
680
880
1150
1500
1900
2500
Amber Bin Limits
(nm at 20 mA)
Bin
Name
1
2
4
6
Min.
584.5
587.0
589.5
592.0
Max.
587.0
589.5
592.0
594.5
Green Color Bin Limits
(nm at 20 mA)
Bin
Name
1
2
3
4
5
Min.
520.0
524.0
528.0
532.0
536.0
Max.
524.0
528.0
532.0
536.0
540.0
Tolerance for each bin limit is
±
0.5 nm.
Tolerance for each bin limit is
±
0.5 nm.
Blue Color Bin Limits
(nm at 20 mA)
Bin
Name
1
2
3
4
5
Min.
460.0
464.0
468.0
472.0
476.0
Max.
464.0
468.0
472.0
476.0
480.0
Tolerance for each bin limit is
±
15%.
Tolerance for each bin limit is
±
2 nm.
Note:
1. Bin categories are established for classification of products. Products may not be available in all bin categories. Please contact your
Agilent representative for information on currently available bins.
