HLMP-KA45
T-1 (3 mm) High Intensity InGaN Lamp
Data Sheet
Description
This blue LED is designed in an industry standard T-1
package with clear and non-diffused optics. This lamp
is ideal for use as indicators and for general purpose
lighting.
Features
•
Popular T1 diameter package
•
General purpose leads
•
Reliable and rugged
•
Binned for color and intensity
•
InGaN blue dice
Applications
•
Status indicators
•
Small message panel
•
Running and decorative lights for commercial use
•
Back-lighting
•
Consumer audio
Package Dimensions
1.14 (0.045)
0.51 (0.020)
3.43 (0.135)
2.92 (0.115)
0.65 (0.026) MAX.
Ø 3.17 (0.125)
2.67 (0.105)
4.70 (0.185)
4.19 (0.165)
6.35 (0.250)
5.58 (0.220)
Notes:
1. All dimensions are in millimeters (inches).
2. An epoxy meniscus may extend about 1 mm (0.040") down the leads.
24.1 (0.95) MIN.
CATHODE
1.52 (0.060)
1.02 (0.040)
2.79 (0.110)
2.29 (0.090)
0.55 (0.022) SQ. TYP.
0.40 (0.016)
CAUTION:
Device are Class I ESD sensitive. Please observe appropriate precautions dur-
ing handling and processing. Refer to Application Note AN-1142 for additional details.
Ordering Information
HLM P -X X X X – X X X X X
Mechanical Option
00: Bulk
Color Bin Selection
0: Full color bin distribution
Maximum Iv Bin Options
0: Open (No maximum limit)
Others: Please refer to the Iv Bin Table
Minimum Iv Bin Options
Please refer to the Iv Bin Table
Viewing Angle
45:50 degree
Color
A: Blue
Package
K: T-1
Absolute Maximum Ratings at T
A
= 25°C
Parameter
DC Forward Current
[1]
Peak Pulsed Forward Current
Average Forward Current
Power Dissipation
LED Junction Temperature
Operating Temperature Range
Storage Temperature Range
Note:
1. Derate linearly as shown in Figure 2.
HLMP-KA45 (Blue)
30
100
30
116
115
–35 to +85
–35 to +85
Unit
mA
mA
mA
mW
°C
°C
°C
2
Device Selection Guide
Color and Dominant
Wavelength
λd
(nm) Typ
Blue 470
Blue 470
Part Number
HLMP-KA45-E00xx
HLMP-KA45-J00xx
Luminous Intensity
Iv (mcd) at 20 mA
Min.
85
240
Luminous Intensity
Iv (mcd) at 20 mA
Max.
–
Notes:
1. The luminous intensity is measured on the mechanical axis of the lamp package.
2. The optical axis is closely aligned with the package mechanical axis.
3. The dominant wavelength,
λ
d
is derived from the CIE Chromaticity Diagram and represents the color of the lamp.
Electrical /Optical Characteristics Table at T
A
= 25°C
Parameter
Forward Voltage
Capacitance
Thermal Resistance
Viewing Angle
Dominant Wavelength
Peak Wavelength
Spectral Halfwidth
Symbol
VF
C
RθJ-PIN
2θ1/2
λd
λP
Δλ1/2
Min.
2.8
Typ.
40
465
50
470
464
24
Max.
3.8
Units
V
pF
°C/W
deg
nm
nm
nm
Test Conditions
IF = 20 mA
VF = 0, f = 1 MHz
LED Junction-to-Cathode Lead
IF = 20 mA
Peak of Wavelength of Spectral
Distribution at IF = 20 mA
Wavelength Width at Spectral
Distribution ½ Power Point at
IF = 20 mA
Notes:
1. 2
θ
1/2
is the off-axis angle where the luminous intensity is 1/2 the on axis intensity.
2. The dominant wavelength,
λ
d
, is derived from the Chromaticity Diagram and represents the color of the lamp.
3
1
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
35
30
FORWARD CURRENT – mA
25
20
15
10
5
380
430
480
530
580
WAVELENGTH - nm
630
680
0
0
20
40
60
AMBIENT TEMPERATURE – °C
80
100
Rθ
J-A
= 780°C/W
Figure 1. Relative Intensity vs Wavelength
RELATIVE INTENSITY
Figure 2. Maximum forward current vs. ambient temperature based on
Tjmax = 115°C
30
25
FORWARD CURRENT - mA
20
15
10
5
0
0
1
2
FORWARD VOLTAGE - V
3
4
RELATIVE INTENSITY
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
-90 -75 -60 -45 -30 -15 0 15 30 45 60 75
ANGULAR DISPLACEMENT – DEGREES
90
Figure 3. Forward Current vs Forward Volatge
Figure 4. Radiation pattern
4
Intensity Bin Limit
Intensity Range (mcd)
Bin
C
D
E
F
G
H
J
K
L
M
N
P
Q
Color Categories
Lambda (nm)
Max.
65.0
85.0
110.0
140.0
180.0
240.0
310.0
400.0
520.0
680.0
880.0
1150.0
1500.0
Min.
50.0
65.0
85.0
110.0
140.0
180.0
240.0
310.0
400.0
520.0
680.0
880.0
1150.0
Color
Blue
Cat #
1
2
3
4
5
Min.
460.0
464.0
468.0
472 .0
476.0
Max.
464.0
468.0
472 .0
476.0
480.0
Tolerance for each bin limit is ±0.5nm.
Mechanical Option Matrix
Mechanical Option Code
00
Definition
Bulk Packaging, minimum increment
500 pcs/bag
Maximum tolerance for each bin limit is ±15%.
Note:
All categories are established for classification of products. Products
may not be available in all categories. Please contact your local Avago
representative for further clarification/information.
For product information and a complete list of distributors, please go to our web site:
www.avagotech.com
Avago, Avago Technologies, and the A logo are trademarks of Avago Technologies in the United States and other countries.
Data subject to change. Copyright © 2005-2010 Avago Technologies. All rights reserved.
AV02-0921EN - November 3, 2010
