DATA S H E E T
SOLID TANTALUM CAPACITOR
SV/F SERIES
Surface mount resin molded chip
with Built-in fuse,
Low blow-out current (2A)
The SV/F series features a built-in fuse to minimize circuit damage from over current by protection with less
than a half blow-out current of the former type.
This fuse-protected capacitor is suitable for noise absorption applications such as those required for comput-
ers, terminals and measuring instruments.
FEATURES
™
Built-in fuse protection (2A)
™
High-temperature durability for either wave soldering or reflow soldering applications
™
The same excellent performance as NEC's R series
™
Wide operating temperature range (–55˚C to +125˚C)
™
High reliability (Failure rate = 1%/1 000H at 85˚C, DC rated voltage applied)
DIMENSIONS
L
H
W
1
L
W
1
Y
Z
+
Z
–
W
2
Z
+
Z
–
H
W
2
[B2 and D2 case]
Case Code
B2
C
D2
D
L
3.5±0.2
6.0±0.3
5.8±0.3
7.3±0.3
W
1
2.8±0.2
3.2±0.3
4.6±0.3
4.3±0.3
W
2
2.3±0.1
1.8±0.1
2.4±0.1
2.4±0.1
[C and D case]
(Unit : mm)
H
1.9±0.2
2.5±0.3
3.2±0.3
2.8±0.3
Z
0.8±0.3
1.3±0.3
1.3±0.3
1.3±0.3
Y
–
0.4C
–
0.5C
MARKING
[C and D case]
[B2 and D2 case]
F
Capacitance
(
µ
F)
F
1
35 n
10
16 n
Rated voltage
(V)
Date code
Polarity (anode)
and mark of built-in fuse
The information in this document is subject to change without notice.
Document No. EC0003EJ3V1DS00 (3rd edition)
Date Published June 1996 M CP(K)
Printed in Japan
©
1992 (1996)
SV/F SERIES
PRODUCTION DATE CODE
Month
Year
1995
1996
1997
1998
Jan
a
n
A
N
Feb
b
p
B
P
Mar
c
q
C
Q
Apr
d
r
D
R
May
e
s
E
S
Jun
f
t
F
T
Jul
g
u
G
U
Aug
h
v
H
V
Sep
j
w
J
W
Oct
k
x
K
X
Nov
l
y
L
Y
Dec
m
z
M
Z
Date code will resume beginning in 1999.
PRODUCT LINE-UP AND MARKING CODE
U
R
(Vdc)
Capacitance
(
µ
F)
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
U
R
: Rated voltage
D2, D
D
C, D2
B2
B2
C
C
C
D2
D2, D
D
D2, D
D
D
C
D2, D
D
B2
C
D2, D
D
B2
C
D2
10
16
20
25
35
B2
50
C
PART NUMBER SYSTEM
BULK (Packed in poly bag)
SVF B2 1V
105
M
Capacitance tolerance
M for
±
20%
Capacitance code in pF
First two digits represent significant
figures. Third digit specifies number
of zeros to follow.
Rated voltage 1H
1V
1E
1D
1C
1A
Case code
SVF series
Tape and reel
: 50 V
: 35 V
: 25 V
: 20 V
: 16 V
: 10 V
TAPE AND REEL
TE SVFB21V105M 8 R
Packing orientation
Part number of bulk
(see left)
R : (Standard)
Orientation
Tape
Feed direction
⊕
Polarity mark
L : (Non-Standard)
Orientation
Feed direction
Tape
⊕
Polarity mark
Tape width
8 mm for B2 case
12 mm for C, D and D2 case
2
DATA SHEET EC0003EJ3V1DS00
SV/F SERIES
SPECIFICATIONS
No.
1
2
3
4
5
6
7
8
Items
Operating Temp. Range
Rated Voltage
Surge Voltage
Derated Voltage
Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle
10
13
6.3
16
20
10
20
26
13
Specifications
–55 to +125˚C
25
33
16
1.0 to 4.7
µ
F
±20%
0.01 CV (
µ
A) or 0.5
µ
A whichever is greater
1.0 to 4.7
µ
F : 0.04 max.
6.8 to 47
µ
F : 0.06 max.
:
±5%
Tangent of loss angle : Initial requirement
Leakage Current
: Initial requirement
–55˚C
0
– 12
Test Conditions
Over 85˚C, applied voltage shall be derated
on the basis of the Derated Voltage at
125˚C specified in this table item no.4
50
65
32
Vdc
Vdc
Vdc
up to 85˚C
up to 85˚C
at 125˚C
at 120 Hz
at 120 Hz
5 min. after rated voltage applied
at 25˚C, 120 Hz
at 85˚C
Surge voltage for 30 sec. (Rs = 1 kΩ)
Discharge for 4 min. 30 sec.
1 000 cycles
Step1
Step2
Step3
Step4
Step5
Step6
:
:
:
:
:
:
+25˚C
–55˚C
+25˚C
+85˚C
+125˚C
+25˚C
35
46
22
∆
C /C
9
Surge Voltage Resistance
Temp.
+85˚C
+12
0
+125˚C
+15
0
∆
C /C
10
Characteris-
tics at high
and low
temperature
Tangent of
loss angle
Leakage
Current
%
%
%
1.0 to 4.7
µ
F : 0.08
6.8 to 47
µ
F : 0.10
––
Initial
requirement
0.1 CV or 5
µ
A
whichever is
greater
1.0 to 4.7
µ
F : 0.06
6.8 to 47
µ
F : 0.08
0.125 CV or 6.25
µ
A whichever is
greater
11
Repid change of temperature
:
±5%
Tangent of loss angle : Initial requirement
Leakage Current
: Initial requirement
:
±5%
∆
C /C
Tangent of loss angle : Initial requirement
Leakage Current
: Initial requirement
:
±5%
Tangent of loss angle : 150% of Intial requirement
Leakage Current
: Initial requirement
∆
C /C
IEC68-2-14 Test N and IEC68-2-33
Guidance
–55 to +125˚C
5 cycles
IEC68-2-58 Test Td
Fully immersion to solder at 260˚C for
5 sec.
IEC68-2-3 Test Ca
at 40˚C, 90 to 95% RH, for 500H
12
Resistance to soldering
∆
C /C
13
Damp Heat (Steady state)
∆
C /C
14
Endurance
:
±10%
Tangent of loss angle : Initial requirement
Leakage Current
: 125% of Initial requirement
B2
: 2A – 5 sec. max.
at 85˚C
Rated Voltage applied for 2 000 H
15
Fuse Blow-out
Characteristics
C
: 2A – 10 sec. max.
D2, D : 2A – 20 sec. max.
at 25˚C
LEGEND
CV : Product of capacitance in
µ
F and voltage in V
∆
C /C : Capacitance change ratio
DATA SHEET EC0003EJ3V1DS00
3
SV/F SERIES
PART NUMBER WITH FUNDAMENTAL PERFORMANCE
Rated
Voltage
(Vdc)
Capacitance
(
µ
F)
4.7
15
10
15
33
33
47
3.3
4.7
6.8
16
10
15
22
22
33
2.2
4.7
20
10
10
15
22
1.5
3.3
25
6.8
6.8
10
1.0
2.2
35
4.7
4.7
6.8
1.0
50
3.3
Tangent of loss angle
max.
0.04
0.06
0.06
0.06
0.06
0.06
0.04
0.04
0.06
0.06
0.06
0.06
0.06
0.06
0.04
0.04
0.06
0.06
0.06
0.06
0.04
0.04
0.06
0.06
0.06
0.04
0.04
0.04
0.04
0.06
0.04
0.04
Leakage Current
(
µ
A) max.
0.5
1.5
1.5
3.3
3.3
4.7
0.5
0.7
1.0
1.6
2.4
3.5
3.5
5.2
0.5
0.9
2.0
2.0
3.0
4.4
0.5
0.8
1.7
1.7
2.5
0.5
0.7
1.6
1.6
2.3
0.5
1.7
Case Code
B2
C
D2
D2
D
D
B2
C
C
C
D2
D2
D
D
B2
C
D2
D
D
D
B2
C
D2
D
D
B2
C
D2
D
D
C
D2
Part Number
SVFB21A475M
SVFC1A156M
SVFD21A156M
SVFD21A336M
SVFD1A336M
SVFD1A476M
SVFB21C335M
SVFC1C475M
SVFC1C685M
SVFC1C106M
SVFD21C156M
SVFD21C226M
SVFD1C226M
SVFD1C336M
SVFB21D225M
SVFC1D475M
SVFD21D106M
SVFD1D106M
SVFD1D156M
SVFD1D226M
SVFB21E155M
SVFC1E335M
SVFD21E685M
SVFD1E685M
SVFD1E106M
SVFB21V105M
SVFC1V225M
SVFD21V475M
SVFD1V475M
SVFD1V685M
SVFC1H105M
SVFD21H335M
4
DATA SHEET EC0003EJ3V1DS00
SV/F SERIES
TAPE AND REEL SPECIFICATION
[Carrier Tape Specification and Packaging Quantity]
sprocket hole
D
0
embossed cavity
A
0
F
t
K
feed direction
E
B
0
P
1
P
2
P
0
W
(Unit : mm)
Case Code
B2
C
D2
D
A
0
±0.2
3.3
3.7
5.1
4.8
B
0
±0.2
3.8
6.4
6.2
7.7
W±0.3
8.0
12.0
12.0
12.0
F±0.05
3.5
5.5
5.5
5.5
E±0.1
1.75
1.75
1.75
1.75
P
1
±0.1
4.0
8.0
8.0
8.0
P
2
±0.05
2.0
2.0
2.0
2.0
Case Code
B2
C
D2
D
P
0
±0.1
4.0
4.0
4.0
4.0
D
0
+0.1
0
K±0.2
2.1
3.0
3.6
3.3
t
0.2
0.3
0.4
0.3
Q'ty/Reel
2 000
500
500
500
φ
1.5
φ
1.5
φ
1.5
φ
1.5
[Reel Specification]
W
1
B
D
N
C
R
W
2
A
(Unit : mm)
Tape width
8
12
A
N
C
D
B
20±0.5
20
±0.5
W
1
10.0±1.0
14.5±1.0
W
2
14.5 max.
18.5 max.
R
1
1
φ
178
±2.0
φ
178
±2.0
φ
50 min.
φ
50 min.
φ
13
±0.5
φ
13
±0.5
φ
21±0.5
φ
21±0.5
DATA SHEET EC0003EJ3V1DS00
5
