KXO-01 Series Crystal Clock Oscillators
TTL Drive - TTL Compatible
FEATURES
1) Lower Cost
2) 14 pin DIP compatible
3) Wide frequency range
(8MHz - 50MHz)
4) All metal package minimizes
RF radiation
5) Meets FCC EMI specifications
6) Solder coated pins
7) 25 pieces per tube
8) Sold in increments of 100
pieces
ƒ
O
: 8.0 to 50 MHz
HOW TO ORDER
KXO-01 - 1 - 32.0000M T
1
2
1
2
3
4
Type: (Kyocera Crystal Oscillators)
Frequency precision:
0 = ±50ppm (special)
1 = ±100ppm
Frequency
Packaging: T = Tube
3
4
SPECIFICATIONS (KXO-01)
Parameters
Output Frequency
Frequency Precision
Aging Rate
Operating Temperature Range
Storage Temperature Range
Voltage
Electrical Current Consumption
Duty Ratio
“0” Level
Output
“1” Level
Rise and Fall Time
Fan Out
V
DD
I
DD
S
y
V
OL
V
OH
T
R
, T
F
Code
f
out
∆f/f
o
∆f/f
T
opr
Rating
8 to 50
0:±50
1±100
±5
0 to ±70
-55 to +125
5±0.5
35 max
40 to 60
0.4 max
2.4 min
15 max
10 max
1 to 10
Unit
MHz
ppm
ppm
ppm/y
°C
°C
VDC
mA
%
V
V
nsec
nsec
TTL
1.4V DC level
At I
OL
=16mA
At I
OH
=400µA
8 to 32MHz
32.1 to 50MHz
0 to 70°C
4.5V to 5.5V
Remarks
DIMENSIONS
#1
#7
5.08
(.200)
6.35
±0.5
(.250
±.02
)
0.8
(.031)
4 – ø0.45
(.018)
13 max.
(.512)
11 max.
(.433)
4.58
±0.5
(.180
±.02
)
7.62
±0.3
(.300
±.01
)
19 max.
(.748)
21 max.
(.827)
#14
12.2
±0.5
(.480
±.02
)
15.24
±0.3
(.600
±.01
)
#8
Units: mm (inch)
43
KXO-01 Series Crystal Clock Oscillators
TTL Drive - TTL Compatible
MARKING
MFG. ID
PART NUMBER
OUTPUT FREQUENCY
COUNTRY OF ORIGIN
DATE CODE
DOT (INDICATING PIN 1)
ƒ
O
: 8.0 to 50 MHz
PIN CONNECTION
PIN #
FUNCTION
N.C.
Case /GND
Output
+5.0V D.C.
KXO-01-1
40.0000MHz
9801 JAPAN
1
7
8
14
POPULAR FREQUENCY LIST
8.0000MHz
10.0000MHz
12.0000MHz
14.31818MHz
16.0000MHz
19.6608MHz
20.0000MHz
24.0000MHz
25.0000MHz
32.0000MHz
40.0000MHz
50.0000MHz
TEST CIRCUIT
5.0V
SHAPE OF OUTPUT WAVE
T
F
H
T
R
TP
A
14
KXO-01
C
L
V
DD
V
1
0.1µF
7
15pF
8
400Ω
2.4V
1.4V
0.4V
L
A
B
CL=15pF max
(Inclusive of test jig and
probe capacitance)
Duty
Ratio=
A X100
A+B
44
