Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case: SOT23F
Case Material: Molded Plastic. “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.012 grams (Approximate)
Description
This low saturation 100V PNP transistor offers extremely low on-state
losses, making it ideal for use in DC-DC circuits and various driving
and power management functions. The SOT23F package is pin
compatible with the industry standard SOT23 footprint, but offers
lower profile and higher dissipation for applications where power
density is of utmost importance.
Applications
Boost Converters
MOSFET and IGBT Gate Drivers
Lamp and Relay Driver
Motor Drive
Siren Driver
SOT23F
C
E
B
C
B
E
Top View
Device Symbol
Top View
Pin Configuration
Ordering Information
(Note 4)
Product
ZXTP19100CFFTA
Notes:
Compliance
AEC-Q101
Marking
1E1
Reel Size (inches)
7
Tape Width (mm)
8
Quantity per Reel
3,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
