ELM1-685 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> ELM1-685

ELM1-685: DescriptionLED Mounting Hardware,; CategoryLED optoelectronic/LED photoelectric; File Size18KB，1 Pages; ManufacturerBivar; Environmental Compliance

Download Datasheet Parametric View All

ELM1-685 Overview

LED Mounting Hardware,

ELM1-685 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Bivar
Reach Compliance Code	unknown
Optoelectronic device types	LED MOUNTING HARDWARE

Preview

Download Datasheet

View All

REV.

DESCRIPTION

DATE

APPROVED

Engineering Update w/o Changes

Material Update.

02/26/04

11/10/05

M. C.

0.030±0.005

TYP.

Ø.200 [Ø5.1mm]

0.025±0.005

TYP.

Ø.100 [Ø2.5mm]

REF. C/L

3. TOLERANCE "L" DIMENSION:

0.030 - 0.500 (1.0 - 12.7mm)±0.005(0.1mm)

0.505 - 0.750 (12.8 - 19.1mm)±0.008(0.2mm)

0.755 - 1.250 (19.2 - 31.8mm)±0.015(0.4mm)

2. MATERIAL: PVC ALLOY, 94V-0, BLACK. BIVAR MATERIAL CODE 58-BK.

CYBERTECH CYBERSHIELD PVC ALLOY, CS1534WX-BLK02N BLACK.

1. GENERAL SPECIFICATIONS: BIVAR EXTRUDED PRODUCT SPECIFICATION BV00-E105.

STANDARD TOLERANCE

( UNLESS OTHERWISE SPECIFIED )

DECIMALS

ANGULAR

± .1

.XX

± .01

.XXX ± .005

DESIGNED:

X°

± 1°

4 THOMAS, IRVINE, CA. 92618

TEL: (949) 951-8808

FAX: (949) 951-3974

TITLE:

EXTRUDED, SELF-RETAINING LED MOUNT

DATE:

PART NO:

REVISION:

Shane Irving

CHECKED:

02/03/98

DATE:

ELM 1

SHEET #

CAGE CODE : 32559

CAD GENERATED DOCUMENT,

M. Chen

12/17/02

DO NOT MEASURE DRAWING.
