Common Mode Inductors (with Optional Header)
8100 Series
Part
Number
L (mH)
Min. @
1 KHz
I (A)*
Max.
DCR
(Ω)
Max.
Leakage
Inductance
(μH) Typ.
Dim.
A
Max.
Dim.
B
±0.01
0.455
MAX.
0.455
MAX.
0.455
MAX
0.60
0.60
0.60
0.60
0.60
0.80
0.80
0.80
0.80
0.80
0.80
0.80
0.80
0.80
0.80
0.90
0.90
0.90
Dim.
C
±0.015
Dim.
D
±0.015
Dim.
E
Max.
Dim.
F
Max.
M
Special Features
• Single layer wound
• Excellent EMI suppression capability
over wide frequency spectrum
• High current capacity
• Dielectric strength: 1500 Vrms
• Coil mount on UL 94V-0 rated plastic header
(optional)
• Fixed pin spacing allow easy PCB insertion
• Operating temperature: -55 to +105 °C
8101-RC
8102-RC
8103-RC
8104-RC
8105-RC
8106-RC
8107-RC
8108-RC
8109-RC
8110-RC
8111-RC
8112-RC
8113-RC
8114-RC
8115-RC
8116-RC
8117-RC
8118-RC
8119-RC
8120-RC
8121-RC
4
2.5
1
10
7
5
2
1
30
20
12
8
5
2.5
1.2
50
36
7.3
4
2.4
1
1.7
2.4
4.8
2.4
2.8
3.7
6.6
10
2.3
2.9
4
5.6
8.9
12.5
16
2.3
2.9
9.3
14.5
17
20
0.173
0.09
0.022
0.17
0.12
0.07
0.022
0.01
0.33
0.21
0.11
0.055
0.022
0.011
0.006
0.45
0.3
0.032
0.012
0.008
0.007
27
17
7
45
32
23
9
4.5
136
95
57
38
25
12.5
6
230
167
30.5
16
9.6
4
0.76
0.76
0.76
1.20
1.20
1.20
1.20
1.20
1.35
1.35
1.35
1.35
1.45
1.45
1.50
1.55
1.55
1.65
1.70
1.70
1.70
0.600
0.600
0.600
0.800
0.800
0.800
0.800
0.800
0.900
0.900
0.900
0.900
0.900
0.900
0.900
0.900
0.900
0.900
1.200
1.200
1.200
0.250
0.250
0.250
0.400
0.400
0.400
0.400
0.400
0.600
0.600
0.600
0.600
0.600
0.600
0.600
0.600
0.600
0.600
0.700
0.700
0.700
0.90
0.90
0.90
1.20
1.20
1.20
1.20
1.20
1.45
1.45
1.45
1.45
1.50
1.50
1.53
1.65
1.65
1.65
1.65
1.65
1.65
0.040
0.040
0.040
0.050
0.050
0.050
0.050
0.050
0.050
0.050
0.050
0.050
0.043
0.053
0.060
0.050
0.050
0.043
0.060
0.067
0.067
Notes
* Rated current to cause approx. 35 °C
temperature rise
† *RoHS Directive 2002/95/EC Jan. 27, 2003
including annex and RoHS Recast 2011/65/EU
June 8, 2011.
How to Order
8101 - ___ RC
Model
Configuration
Blank = With mounting base
1 = Without mounting header
(with vertical coil, 2-inch self-lead
length, non-tinned)
RoHS Compliant
“-RC” suffix indicates RoHS compliance.
B
A
0.12 min.
B
A
0.12 min.
E
E
D
0.09
0.15
C
F
D
0.20
C
F
2
1
3
4
2
1
3
4
2
1
3
4
2
1
3
4
8101-8103
Dimensions: Inches
8104-8121
Tel. (877) 426-8767 • Fax (951) 781-5006
25.4
www.bourns.com
REV. 11/14
