BRIGHT LED ELECTRONICS CORP.

SINCE 1981

BRM-4040-8-FB4.3

INFRARED RECEIVER MODULE

●

Description

1. The BRM-4040-8 –FB4.3 is miniaturized infrared receivers

for remote control and other applications requiring

improved ambient light rejection.

2. The separate PIN diode and preamplifier IC are

assembled on a single leadframe.

6.10(.240)

5.80(.20)±0.5

3.2(.12)

●

Package Dimensions:

3. The epoxy package contains a special IR filter.

4. This module has excellent performance even in

4.5

3.05(.12)

protection against uncontrolled output pulses.

4.30(.169)

3.80(.15)

disturbed ambient light applications and provides

7.6(.29)

2.10(.08)

●

Features

Photo detector and preamplifier in one package .

Internal filter for PCM frequency.

High immunity against ambient light.

Improved shielding against electric field disturbance.

5.0V supply voltage; low power consumption.

TTL and CMOS compatibility.

Suitable transmission code:NEC code,RC5 code.

3.2(.12)

2.54(.01)

26.2(1.03)±0.50

5.50(.216)

1 OUTPUT

2 GND

3 VCC

●

Applications:

1. It can be used for TVs、VTRs、audio equipment

air conditioners、 car stereo radio、toys、 home

computers and all other equipment requiring remote

control.

NOTES:

1.All dimensions are in millimeters (inches).

2.Tolerance is ±0.10mm (0.004’’) unless otherwise specified.

3.Specifications are subject to change without notice.

●

BLOCK DIAGRAM

Vcc

Vout

Limiter

B.P.F

ABLC

Demodulator

Preamp

Amp

Integrator

Comparator

GND

Ver: 1.0 Page: 1of 5
