SPECIFICATIONS
Current Rating:
Contact Resistance:
Insulator Resistance:
Insulator:
Contact Material:
Contact Plating:
Operating Temp:
Pos
06
08
10
12
14
16
20
22
26
30
34
36
40
44
50
60
68
80
0.5 Amp
30m Ohm Max.
1000M ohm min.
PBT Glass Fiber UL94V-0, Black
Phosphor Bronze
See Table
-40C ~ +105C
A
8.01
9.28
10.55
11.82
13.09
14.36
16.90
18.17
20.71
23.25
25.79
27.06
29.60
32.14
35.95
42.30
47.38
55.00
Dimensions
B
2.54
3.81
5.08
6.35
7.62
8.89
11.43
12.70
15.24
17.78
20.32
21.59
24.13
26.67
30.48
36.83
41.91
49.53
C
2.54
3.81
5.08
6.35
7.62
8.89
11.43
12.70
15.24
17.78
20.32
21.59
24.13
26.67
30.48
36.83
41.91
49.53
A
B
C
C
D
D
E
E
Series
CFC
.050”x.050” Flat
Cable Socket
F
Positions
XX
06-80 See Chart
Polarized
P
P=Polarized
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Finish
XX
GDYY=Gold
YY=Flash if blank,
03,05,10,15,20,3u”
F
Date
03/24/05
03/24/05
03/24/05 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
CFC-C-XX-P-XX
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: IDC Socket
