Low-Peak™ 600V Class RK1
LPS-RK — 600Vac/300Vdc,
1
⁄
10
-60A, Dual Element, Time-Delay Fuses
Dimensions - in
5"
(± 0.31)
Available with easyID™
open fuse indication
5.5"
(± 0.31)
0.81" (±0.008)
1.06" (±0.008)
35 to 60A
1/10 to 30A
Description:
Ultimate protection Class RK1 dual element,
current-limiting, time-delay fuses available with optional open
fuse indication on select ratings. Time-delay – 10 seconds
(minimum) at 500% of rated current.
Catalog Symbol:
LPS-RK-(amp)SP (non-indicating)
LPS-RK-(amp)SPI (indicating)
Rating:
Volts — 600Vac, 300Vdc
Amps —
1
⁄
10
-60A
IR — 300kA Vac RMS Sym.
— 100kA DC
Agency Information:
CE, UL Listed, Guide JDDZ, File E4273
CSA Certified, Class 1422-02, File 53787
Class RK1 per CSA C22.2, No. 248.12
Catalog Numbers (amps) – Non-indicating fuses
LPS-RK-
1
⁄
10
SP
LPS-RK-
2
⁄
10
SP
LPS-RK-
3
⁄
10
SP
LPS-RK-
4
⁄
10
SP
LPS-RK-
1
⁄
2
SP
LPS-RK-
6
⁄
10
SP
LPS-RK-
8
⁄
10
SP
LPS-RK-1SP
LPS-RK-1
1
⁄
8
SP
LPS-RK-1
1
⁄
4
SP
LPS-RK-1
4
⁄
10
SP
LPS-RK-1
1
⁄
2
SP
LPS-RK-1
6
⁄
10
SP
LPS-RK-1
8
⁄
10
SP
LPS-RK-2
1
⁄
4
SP
LPS-RK-2
1
⁄
2
SP
LPS-RK-2
8
⁄
10
SP
LPS-RK-3SP
LPS-RK-3
2
⁄
10
SP
LPS-RK-3
1
⁄
2
SP
LPS-RK-4SP
LPS-RK-4
1
⁄
2
SP
LPS-RK-5SP
LPS-RK-5
6
⁄
10
SP
LPS-RK-6SP*
LPS-RK-6
1
⁄
4
SP*
LPS-RK-7SP*
LPS-RK-8SP*
LPS-RK-9SP*
LPS-RK-10SP*
LPS-RK-12SP*
LPS-RK-15SP*
LPS-RK-17
1
⁄
2
SP*
LPS-RK-20SP*
LPS-RK-25SP*
LPS-RK-30SP*
LPS-RK-35SP*
LPS-RK-40SP*
LPS-RK-45SP*
LPS-RK-50SP*
LPS-RK-60SP*
Features:
• Industry’s only UL Listed and CSA Certified fuse with a
300kA Vac interrupting rating that exceeds requirements for
virtually all applications
• Current-limitation for maximum short-circuit protection
• Easy selective coordination with all Low-Peak fuses using
simple 2:1 ampacity ratio
• “No damage” Type “2” protection for IEC and NEMA
starters when properly sized
• High inrush current motor protection
• Time-delay permits 130% FLA sizing for back-up motor
protection
• Protection against single-phase motor damage
• Low watt loss power consumption
Applications:
• Feeder and Branch Circuits
• Motors
• Transformers
• Solenoids
• General Purpose Circuits
Recommended Fuse Blocks
Fuse Amps
0-30
35-60
1-Pole
R60030-1
R60060-1
2-Pole
R60030-2
R60060-2
3-Pole
R60030-3
R60060-3
For additional information on the R600 Series of 600 volt fuse
blocks, see data sheet # 1111.
Fuse Reducers For Class R Fuses
Equipment
Fuse Clips
60A
100A
200A
Desired Fuse
(Case) Size
30A
30A
60A
60A
Catalog Numbers
(Pairs) 600V
NO.663-R
NO.216-R
NO.616-R
NO.626-R
* Open fuse indication available by inserting the suffix “I,” e.g., LPS-RK-15SPI.
Requires 75Vac minimum voltage.
Carton Quantity and Weight
Amp Rating
0–30
35–60
Carton Qty.
10
10
For additional information on Class R fuse reducers, see
Data Sheet 1118.
0713
BU-SB13684
Page 1 of 3
Data Sheet # 1001
Low-Peak™ 600V Class RK1
LPS-RK — 600Vac/300Vdc,
1
⁄
10
-60A, Dual Element, Time-Delay Fuses
Time-Current Characteristic Curves–Average Melt
12 to 60 Amps
400,000
300,000
200,000
Current-Limitation Curves
B
INSTANTANEOUS PEAK LET-THROUGH CURRENT IN AMPS
100,000
90,000
80,000
70,000
60,000
50,000
40,000
30,000
20,000
10,000
9,000
8,000
7,000
6,000
5,000
4,000
3,000
2,000
30A
A
100,000
200,000
PROSPECTIVE SHORT-CIRCUIT CURRENT - SYMMETRICAL RMS AMPS
Current-Limiting Effects
Prosp.
Let-Through Current
S.C.C.
(Apparent RMS Symmetrical Vs. Fuse Rating)
30A
60A
1000
1000
1000
2000
1000
1000
3000
1000
1000
5000
1000
2000
10,000
1000
2000
15,000
1000
2000
20,000
2000
3000
25,000
2000
3000
30,000
2000
3000
35,000
2000
3000
40,000
2000
3000
50,000
2000
3000
60,000
2000
4000
70,000
2000
4000
80,000
2000
4000
90,000
2000
4000
100,000
2000
4000
150,000
3000
5000
200,000
3000
5000
250,000
3000
6000
300,000
3000
6000
The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin is
intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice, any technical information
contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
0713
BU-SB13684
Page 3 of 3
Data Sheet # 1001
300,000
1,000
30,000
10,000
20,000
40,000
60,000
80,000
1,000
2,000
3,000
4,000
6,000
8,000
AMP RATING
60A
