STR9012

Description
5-Terminal, Low Dropout Voltage Dropper Type
CategoryPower/power management    The power supply circuit
File Size52KB，5 Pages
ManufacturerSANKEN
Websitehttp://www.sanken-ele.co.jp/en/
Download Datasheet Parametric Compare View All

STR9012 Overview

5-Terminal, Low Dropout Voltage Dropper Type

STR9012 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerSANKEN
Parts packaging codeSIP
package instructionSIP, SIP5,.1,215
Contacts5
Reach Compliance Codeunknow
ECCN codeEAR99
AdjustabilityFIXED
Maximum drop-back voltage 11 V
Maximum absolute input voltage30 V
Maximum input voltage25 V
Minimum input voltage13 V
JESD-30 codeR-PSIP-T5
length36 mm
Maximum grid adjustment rate0.08%
Maximum load regulation0.2%
Number of functions1
Output times1
Number of terminals5
Working temperatureTJ-Max125 °C
Operating temperatureTJ-Mi-30 °C
Maximum output current 14 A
Maximum output voltage 112.2 V
Minimum output voltage 111.8 V
Nominal output voltage 112 V
Package body materialPLASTIC/EPOXY
encapsulated codeSIP
Encapsulate equivalent codeSIP5,.1,215
Package shapeRECTANGULAR
Package formIN-LINE
Certification statusNot Qualified
Regulator typeFIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height26.2 mm
surface mountNO
technologyBIPOLAR
Terminal formTHROUGH-HOLE
Terminal pitch5.45 mm
Terminal locationSINGLE
Maximum voltage tolerance1.67%

Preview

Download Datasheet
qSTR9000
Series
STR9000 Series
5-Terminal, Low Dropout Voltage Dropper Type
sFeatures
•
•
•
•
•
•
5-terminal regulator with two screw mount package
Output current: 4.0A
Low dropout voltage :V
DIF
≤1V
(at I
O
=4A)
Fine adjustment of output voltage
Output ON/OFF control
Built-in foldback overcurrent protection circuits
sApplications
• For stabilization of the secondary stage of switching power supplies
• Electronic equipment
sAbsolute
Maximum Ratings
Parameter
DC Input Voltage
DC Output Current
Power Dissipation
Junction Temperature
Ambient Operating Temperature
Storage Temperature
Thermal Resistance (junction to case)
Symbol
V
IN
I
O
P
D1
P
D2
T
j
T
op
T
stg
R
th(j-c)
Ratings
STR9005
25
4.0
75(T
C
=25°C)
3.2(Without heatsink, stand-alone operation)
–30 to +125
–20 to +100
–30 to +125
1.25
STR9012/9015
30
Unit
V
V
W
W
°C
°C
°C
°C/W
(T
a
=25°C)
sElectrical
Characteristics
Ratings
Parameter
Input Voltage
Output Voltage
Symbol
min.
V
IN
V
O
Conditions
V
DIF
Dropout Voltage
Conditions
1.0
Conditions
Line Regulation
Load Regulation
Temperature Coefficient of Output Voltage
Ripple Rejection
Overcurrent Protection
Starting Current
Output ON/OFF Control Voltage
(Voltage between terminal No.3 and 5)
Voltage with Output Off
∆V
OLINE
Conditions
∆V
OLOAD
Conditions
∆V
O
/∆T
a
R
REJ
Conditions
I
S1
Conditions
V
O
(ON)
V
O
(OFF)
V
O
Conditions
V
IN
=8V, I
O
=0A
2.0
0.5
V
IN
=15V, I
O
=0A
4.1
V
IN
=8V
0.6
2.0
0.5
V
IN
=20V, I
O
=0A
4.1
V
IN
=16V
0.6
2.0
0.5
10
40
±0.5
54
30
100
V
IN
=6 to 15V, I
O
=2.0A
V
IN
=8V, I
O
=0 to 3.0A
I
O
=4.0A
30
80
±1.5
54
f=100 to 120H
Z
4.1
V
IN
=20V
0.6
80
200
50
100
±1.5
54
100
200
6
4.9
5.0
V
IN
=8V, I
O
=2.0A
0.5
I
O
=2.0A
1.0
1.0
STR9005
typ.
max.
15
5.1
min.
13
11.8
12.0
V
IN
=16V, I
O
=2.0A
0.5
STR9012
typ.
max.
25
12.2
min.
16
14.8
15.0
V
IN
=20V, I
O
=2.0A
0.5
STR9015
typ.
max.
25
15.2
(T
a
=25°C)
Unit
V
V
V
mV
mV
mV/°C
dB
A
V
V
V
V
IN
=13 to 25V, I
O
=2.0A
V
IN
=16V, I
O
=0 to 3.0A
V
IN
=16 to 25V, I
O
=2.0A
V
IN
=20V, I
O
=0 to 3.0A
*Output is turned on when voltage between terminal No.3 and 5 is less than 0.6V, and turned off if more than 2.0V.
66

STR9012 Related Products

STR9012 STR9015 STR9005 STR9000
Description 5-Terminal, Low Dropout Voltage Dropper Type 5-Terminal, Low Dropout Voltage Dropper Type 5-Terminal, Low Dropout Voltage Dropper Type 5-Terminal, Low Dropout Voltage Dropper Type
Is it Rohs certified? incompatible incompatible incompatible -
Parts packaging code SIP SIP SIP -
package instruction SIP, SIP5,.1,215 SIP, SIP5,.1,215 SIP, SIP5,.1,215 -
Contacts 5 5 5 -
Reach Compliance Code unknow unknow unknow -
ECCN code EAR99 EAR99 EAR99 -
Adjustability FIXED FIXED FIXED -
Maximum drop-back voltage 1 1 V 1 V 1 V -
Maximum absolute input voltage 30 V 30 V 25 V -
Maximum input voltage 25 V 25 V 15 V -
Minimum input voltage 13 V 16 V 6 V -
JESD-30 code R-PSIP-T5 R-PSIP-T5 R-PSIP-T5 -
length 36 mm 36 mm 36 mm -
Maximum grid adjustment rate 0.08% 0.1% 0.03% -
Maximum load regulation 0.2% 0.2% 0.1% -
Number of functions 1 1 1 -
Output times 1 1 1 -
Number of terminals 5 5 5 -
Working temperatureTJ-Max 125 °C 125 °C 125 °C -
Operating temperatureTJ-Mi -30 °C -30 °C -30 °C -
Maximum output current 1 4 A 4 A 4 A -
Maximum output voltage 1 12.2 V 15.2 V 5.1 V -
Minimum output voltage 1 11.8 V 14.8 V 4.9 V -
Nominal output voltage 1 12 V 15 V 5 V -
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY -
encapsulated code SIP SIP SIP -
Encapsulate equivalent code SIP5,.1,215 SIP5,.1,215 SIP5,.1,215 -
Package shape RECTANGULAR RECTANGULAR RECTANGULAR -
Package form IN-LINE IN-LINE IN-LINE -
Certification status Not Qualified Not Qualified Not Qualified -
Regulator type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR -
Maximum seat height 26.2 mm 26.2 mm 26.2 mm -
surface mount NO NO NO -
technology BIPOLAR BIPOLAR BIPOLAR -
Terminal form THROUGH-HOLE THROUGH-HOLE THROUGH-HOLE -
Terminal pitch 5.45 mm 5.45 mm 5.45 mm -
Terminal location SINGLE SINGLE SINGLE -
Maximum voltage tolerance 1.67% 1.33% 2% -
