RL-2535
MOLDED WIREWOUND
CHIP INDUCTORS
DESCRIPTION
• Molded Chip Inductors
FEATURES & APPLICATIONS
• Leaching resistant terminations due to metal tab electrodes
• Coils encapsulated in heat-proof resin achieve accurate
dimensions and are resistant to mechanical shock or pressure
• High resistance to heat and humidity
ENVIRONMENTAL DATA
• Storage temperature range:
-40°C to +125°C
• Operating temperature range:
-40°C to +130°C
PACKAGING INFORMATION
• Packaging information: pg. 489, 494
Verify operation with sample in actual circuit. Order samples at www.rencousa.com.
MECHANICAL DIMENSIONS
U.S. Standard (mm)
PART NUMBER
RL-2535
A (MAX.)
0.23 (5.90)
B ±0.004 (0.1)
0.39 (1.00)
C (MAX.)
0.21 (5.30)
D (MAX.)
0.21 (5.30)
E (MAX.)
0.04 (1.02)
F (MAX.)
0.14 (3.60)
PART NUMBER
RL-2535
PART WEIGHT
0.5g (0.018oz)
G (REF.)
0.14 (3.60)
H (REF.)
0.08 (2.00)
I (REF.)
0.39 (1.00)
TOP VIEW
A
SIDE VIEW
D
RECOMMENDED LAND PATTERN
I
1
SCHEMATIC
C
E
B
H
F
G
2
RL-2535
Renco Part No.
RL-2535
RL-2535-1R0X
RL-2535-1R2X
RL-2535-1R5X
RL-2535-1R8X
RL-2535-2R2X
RL-2535-2R7X
RL-2535-3R3X
RL-2535-3R9X
RL-2535-4R7X
RL-2535-5R6X
RL-2535-6R8X
RL-2535-8R2X
RL-2535-100X
RL-2535-120X
RL-2535-150X
RL-2535-180X
RL-2535-220X
RL-2535-270X
RL-2535-330X
RL-2535-390X
RL-2535-470X
RL-2535-560X
RL-2535-680X
RL-2535-820X
RL-2535-101X
RL-2535-121X
RL-2535-151X
RL-2535-181X
RL-2535-221X
RL-2535-271X
RL-2535-331X
RL-2535-391X
RL-2535-471X
RL-2535-561X
RL-2535-681X
RL-2535-821X
RL-2535-102X
RL-2535-122X
Inductance
(µH)
1.00
1.20
1.50
1.80
2.20
2.70
3.30
3.90
4.70
5.60
6.80
8.20
10.00
12.00
15.00
18.00
22.00
27.00
33.00
39.00
47.00
56.00
68.00
82.00
100.00
120.00
150.00
180.00
220.00
270.00
330.00
390.00
470.00
560.00
680.00
820.00
1000.00
1200.00
DCR
Q
Q
Q
Q
Q
Max. (MHz, Min) (MHz, Min) (MHz, Min) (MHz,Min) (MHz, Min)
(Ohms)
0.0796
0.252
0.796
2.52
7.96
0.030
0.035
0.040
0.050
0.060
0.070
0.080
0.090
0.110
0.130
0.150
0.180
0.210
0.250
0.300
0.360
0.430
0.520
0.620
0.720
0.850
1.000
1.200
1.400
1.600
1.900
2.200
2.800
3.400
4.200
4.900
5.800
7.000
8.500
10.000
13.000
15.000
17.000
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
20.0
30.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Irms
(mA)
1800.0
1700.0
1600.0
1400.0
1300.0
1200.0
1120.0
1050.0
950.0
880.0
810.0
750.0
690.0
630.0
580.0
530.0
480.0
440.0
400.0
370.0
340.0
310.0
290.0
270.0
250.0
230.0
210.0
190.0
170.0
155.0
140.0
130.0
120.0
110.0
100.0
90.0
85.0
75.0
SRF
MHz
95.00
70.00
55.00
47.00
42.00
37.00
34.00
32.00
29.00
26.00
24.00
22.00
19.00
17.00
16.00
14.00
13.00
11.50
10.50
9.50
8.50
7.80
7.00
6.40
6.00
5.40
4.80
4.40
3.90
3.60
3.20
2.90
2.60
2.40
2.20
2.00
1.80
1.50
RL-2535 TABLE CONTINUES ON FOLLOWING PAGE
NOTES:
1. ELECTRICAL SPECIFICATIONS MEASURED AT 25ºC
2. Irms - CURRENT THAT CAUSES THE TEMPERATURE
TO RISE APPROX. 20ºC ABOVE AMBIENT OF 25ºC
3. Tolerance Code: J=±5% K=±10% M=±20%
RL-2535
Renco Part No.
RL-2535
RL-2535-152X
RL-2535-182X
RL-2535-222X
RL-2535-272X
RL-2535-332X
RL-2535-392X
RL-2535-472X
RL-2535-562X
RL-2535-682X
RL-2535-822X
RL-2535-103X
Inductance
(µH)
1500.00
1800.00
2200.00
2700.00
3300.00
3900.00
4700.00
5600.00
6800.00
8200.00
10000.00
DCR
Q
Q
Q
Q
Q
Max. (MHz, Min) (MHz, Min) (MHz, Min) (MHz,Min) (MHz, Min)
(Ohms)
0.0796
0.252
0.796
2.52
7.96
20.000
30.000
35.000
55.000
60.000
70.000
78.000
85.000
110.000
125.000
150.000
-
-
-
-
-
-
-
-
-
-
20.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
30.0
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Irms
(mA)
70.0
60.0
55.0
45.0
40.0
38.0
36.0
33.0
30.0
28.0
25.0
SRF
MHz
1.40
1.30
1.20
1.10
1.00
1.00
0.90
0.80
0.70
0.60
0.50
NOTES:
1. ELECTRICAL SPECIFICATIONS MEASURED AT 25ºC
2. Irms - CURRENT THAT CAUSES THE TEMPERATURE
TO RISE APPROX. 20ºC ABOVE AMBIENT OF 25ºC
3. WHEN HAND SOLDERING, APPLY SOLDER IRON TO THE PRINTED
CIRCUIT BOARD ONLY. TEMPERATURE OF THE IRON TIP SHOULD
NOT EXCEED 260°C WITH SOLDERING TIME < 3 SECONDS.
