Optoway
1310 nm LASER DIODE MODULES
UNCOOLED MQW-FP LD WITH RECEPTACLE
FEATURES
1310 nm typical emission wavelength
High reliability, long operation life
High temperature operation without active cooling
Build-in InGaAs monitor
FL-3500
********************************************************************************************************************************************************
FL-3500 SERIES
*******************************************************************************************************************************************************
APPLICATION
Trunk Line, FitL
DESCRIPTION
FL-3500 series are designed for coupling a single mode optical fiber with 1310 nm MQW-FP uncooled
laser diode. FL-3500 series are the best kits as light sources for telecom and datacom applications.
ELECTRICAL AND OPTICAL CHARACTERISTICS (T
C
=25 °C)
Symbol
I
th
V
OP
P
f
Parameter
Threshold Current
Operating Voltage
Optical Output Power
Part No:FL-350XX
FL-351XX
FL-352XX
FL-353XX
FL-354XX
Center Wavelength
Spectral Width
Rise And Fall Times
Part No:FL-35XX
FL-35XXS
Tracking Error
PD Monitor Current
PD Dark Current
CW
CW, I
F
=Ith+20mA
CW, I
F
=Ith+20mA
0.2
0.5
1.0
2.0
3.0
1290
0.5
1.0
2.0
3.0
-
1330
3
226
150
1.0
mW
Test Conditions
Min.
Typ.
10
1.2
Max.
15
1.5
Unit
mA
V
λc
Δλ
t
r
, t
f
CW, I
th
+20mA
CW, I
th
+20mA, RMS
I
F
=I
th
, I
th
+20mA,20~80%
1310
1
nm
nm
ps
dB
μA
ΔP
f
/ P
f
I
m
I
D
APC, -40~+85 ºC
CW, I
th
+20mA ,V
RD
=1V
V
RD
=5V
-1.0
100
0.1
μA
C
t
PD Capacitance
V
RD
=5V, f=1MHz
10
15
pF
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
4/15/2009 V3.0
Optoway
ABSOLUTE MAXIMUM RATINGS (T
C
=25 ºC)
Symbol
P
o
V
RL
V
RD
I
FD
T
opr
T
stg
Parameter
Optical Output Power
(350XX/351XX/352XX/353XX/354XX)
LD Reverse Voltage
PD Reverse Voltage
PD Forward Current
Operating Temperature
Storage Temperature
Ratings
0.5/1.0/1.5/3/4
2
10
1.0
-40~+85
-40~+85
Unit
mW
V
V
mA
ºC
ºC
FL-3500
********************************************************************************************************************************************************
MECHANICAL DIMENSION (mm) and PIN ASSIGNMENT
Max.L
SC RECEPTACLE
(FL-35XXX-SX)
Max.L
SC RECEPTACLE (BOARD MOUNT)
(FL-35XXX-SBX)
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
4/15/2009 V3.0
Optoway
FL-3500
********************************************************************************************************************************************************
Max.L
FC RECEPTACLE
(FL-35XXX-FX)
Max.L
FC RECEPTACLE (BOARD MOUNT)
(FL-35XXX-FBX)
Max.L
ST RECEPTACLE
(FL-35XXX-TX)
Max. L
Dimension
F
1.2
P//N
350XX-X
351XX-X
352XX-X
350XX-XS
351XX-XS
352XX-XS
353XX-XS
354XX-XS
S
3.6
SB
3
FB
3.9
T
2.7
7
8.6
10.6
6.4
8.0
10.0
4.6
6.2
8.2
7.3
8.9
10.9
6.1
7.7
9.7
Note:
Specifications subject to change without notice.
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
4/15/2009 V3.0
Optoway
ORDER INFORMATION
Part No.: F L
−
3 5
□ □ □
−
□ □
Code
0
1
2
Pout (mW)
0.2
0.5
1
Code
Blank
S
Code
0
5
8
Speed
1.25 Gbps
2.5 Gbps
Pin Assignment
Type A
Type B
Type C
Code
Blank
S
FL-3500
********************************************************************************************************************************************************
Isolator
No
Single-Stage
Code
S
SB
F
FB
T
Connector Type
SC/PC
SC/PC (Board Mount)
FC/PC
FC/PC (Board Mount)
ST/PC
Part No.: F L
−
3 5
□ □ □
−
□
S
Code
3
4
Pout (mW)
2
3
Code
Blank
S
Code
0
5
8
Speed
1.25 Gbps
2.5 Gbps
Pin Assignment
Type A
Type B
Type C
Code
S
Isolator
Single-Stage
Code
S
SB
F
FB
T
Connector Type
SC/PC
SC/PC (Board Mount)
FC/PC
FC/PC (Board Mount)
ST/PC
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
4/15/2009 V3.0
Optoway
Revision History
Version
1.0
2.0
FL-3500
********************************************************************************************************************************************************
Subject
Initial datasheet
1. Combine 1.25G and 2.5G characteristics in one data sheet
2. Add 3mW products
3. Revise FC RECEPTACLE (BOARD MOUNT) thread thru dim.:
M2 =
> UNC-2B
4. Revise drawing
Revise order information
Release Date
2002/7/1
2007/12/1
3.0
2009/4/15
*******************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax:886-3-5979737
e-mail: sales@optoway.com.tw
http: // www.optoway.com.tw
4/15/2009 V3.0
