FR201G thru FR207G
GLASS FAST RECOVERY RECTIFIERS
REVERSE VOLTAGE
- 50
to
1000
Volts
FORWARD CURRENT
- 2.0
Amperes
DO-15
FEATURES
●
Fast switching for high efficiency
●
Low cost
●
Diffused junction
●
Low reverse leakage current
●
Low forward voltage drop
●
High current capability
●
The plastic material carries UL recognition 94V-0
.034(0.9)
.028(0.7)
1.0(25.4)
MIN.
DIA
.300(7.6)
.230(5.8)
.140(3.6)
.104(2.6) DIA.
MECHANICAL DATA
●
Case: JEDEC DO-15 molded plastic
●
Polarity: Color band denotes cathode
●
Weight: 0.015 ounces , 0.4 grams
●
Mounting position: Any
1.0(25.4)
MIN.
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25℃ ambient temperature unless otherwise specified.
Single phase, half wave ,60Hz, resistive or inductive load.
For capacitive load, derate current by 20%
CHARACTERISTICS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Current
Peak Forward Surage Current
8.3ms Single Half Sine-Wave
Super Imposed on Rated Load(JEDEC Method)
Peak Forward Voltage at 2.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage
@T
J
=25℃
@T
J
=100℃
@T
A
=50
℃
SYMBOL FR201G FR202G FR203G FR204G FR205G FR206G FR207G
V
RRM
V
RMS
V
DC
I
(AV)
50
35
50
100
70
100
200
140
200
400
280
400
2.0
600
420
600
800
560
800
1000
700
1000
UNIT
V
V
V
A
I
FSM
V
F
I
R
T
RR
C
J
R
θJA
T
J
T
STG
150
30
70
1.3
5.0
100
250
20
25
-50 to +150
-50 to +150
500
A
V
uA
ns
pF
℃/W
℃
℃
Maximum Reverse Recovery Time(Note 1)
Typical Junction Capacitance (Note2)
Typical Thermal Resistance (Note3)
Operating Temperature Range
Storage Temperature Range
NOTES: 1.Measured with I
F
=0.5A,I
R
=1A,I
RR
=0.25A
2.Measured at 1.0 MHz and applied reverse voltage of 4.0V DC
3.Thermal resistance junction of ambient.
~ 65 ~
RATING AND CHARACTERTIC CURVES
FR201G thru FR207G
FIG. 1
–
FORWARD CURRENT DERATING CURVE
2.0
AVERAGE FORWARD CURRENT
AMPERES
70
PEAK FORWARD SURGE CURRENT,
AMPERES
60
50
40
30
20
10
0
1
2
5
10
20
50
100
FIG. 2
–
MAXIMUM NON-REPETITIVE SURGE CURRENT
SINGLE PHASE HALF WAVE 60Hz
RESISTIVE OR INDUCTIVE LOAD
1.5
1.0
0.5
PULSE WIDTH 8.3
ms
SINGLE HALF-SINE-WAVE
(JEDEC METHOD)
0
25
50
75
100
125
150
175
AMBIENT TEMPERATURE (℃)
NUMBER OF CYCLES AT 60Hz
FIG.3
–
TYPICAL JUNCTION CAPACITANCE
100
INSTANTANEOUS FORWARD CURRENT,(A)
10
FIG.4-TYPICAL FORWARD CHARACTERISTICS
FR201G - FR204G
1.0
CAPACITANCE ,(pF)
10
FR205G - FR207G
T
J
= 25°C
0.1
T
J
= 25°C f = 1 MHz
PULSE WIDTH 300us
1
1
4
10
100
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
REVERSE VOLTAGE ,VOLTS
INSTANTANEOUS FORWARD VOLTAGE ,VOLTS
~ 66 ~
