InGaAs-PIN/Preamp
Receiver
FEATURES
• Data rate up to 622Mb/s
• High Responsivity: 0.85A/W at 1,310nm
• High temperature operation up to 85°C
FRM3Z621KT/LT
KT
APPLICATIONS
• Medium bit rate standard medium haul optical
transmission system at STM-4 (OC-12)
DESCRIPTION
These PIN preamplifiers use an InGaAs PIN with a GaAs IC preamplifier.
Package style is a hermetically sealed, epoxyless coaxial package
with a multimode fiber pigtail.
LT
Edition 1.1
July 2004
1
FRM3Z621KT/LT
ABSOLUTE MAXIMUM RATINGS (Ta=25°C)
Parameter
Storage Temperature
Operating Case Temperature
IC Supply Voltage
PD Supply Voltage
PD Reverse Current
Maximum Input Power
Symbol
Tstg
Top
Vss
Vr
Ir
Po max
InGaAs-PIN/Preamp
Receiver
Ratings
-40 to +85
-40 to +85
-7 to +0
0 to +20
500
0
Unit
°C
°C
V
V
µA
dBm
OPTICAL & ELECTRICAL CHARACTERISTICS (Ta=-40° to +85°C, Vss=-5.2V, Vr=5V level and
λ=1,310/1,550nm
unless otherwise specified)
Parameter
Responsivity
Transimpedance
Bandwidth
Symbol
R
Zt
BW
Test Conditions
λ=1,310nm
AC, RL=50Ω,
Pin <-15dBm
AC-Coupled, RL=50Ω,
-3dBm from 1MHz
622Mb/s NRZ, 2
23
-1
P.R.B.S., B.E.R.=10
-10
Ta=25°C
Ta=-40 to +85°C
Maximum Input Optical Power
Power Supply Current
Recommended Supply
PD Voltage
Optical Return Loss
Equivalent Input Current Density
Pmax
Iss
Vss
Vr
ORL
in
Note (1)
-
-
-
-
avg. within 435MHz
Min.
0.8
3.0
435
Limits
Typ.
0.85
3.5
-
Max.
-
-
-
Unit
A/W
KΩ
MHz
Sensitivity
Pr
-
-
-7
-
-5.46
5
30
-
-32.5
-31
-
-
-5.2
-
-
2.64
-32
-30.5
-
40
-4.94
20
-
3.2
dBm
dBm
dBm
mA
V
V
dB
pA/ Hz
Note: (1) Maximum Input Optical Power, Pmax is defined as the optical power when the variation of F.W.H.M. of the output waveform is less than 10%
compared with that of the low input; optical power level.
(2) No data is accompanied with each device.
(3) Optical characteristics are specified on the condition that single mode fiber is used as the
optical source for testing.
2
InGaAs-PIN/Preamp
Receiver
Fig. 1 Normarized Output Voltage
as a function of Peak Photo Current
Ta = 25°C
Vss=-5.2V
VR=5V
CW condition
RL=∞
λ=1,310nm
FRM3Z621KT/LT
Fig. 2 Relative Frequency Response
Delta Output Voltage
∆Vout
(V)
Relative Response (dB)
0
-0.1
-0.2
-0.3
-0.4
-0.5
-0.6
50
Photo Current (µA)
+3
Pin=-10dBm
0
-3
-6
-9
Pin=-30dBm
Ta = 25°C
Vss=-5.2V
VR=5V
AC-Coupled
RL=50Ω
λ=1,310/1,550nm
1
10
100
100
1000
Frequency, f(MHz)
Fig. 3 Equivalent Input Noise Current Density
10
Fig. 4 Eye diagram with a 1,310nm, 622Mbps NRZ,
2
23
-1 PRBS incident signal at Tc = 25°C
50mV/Div
200ps/Div
Equivalent input noise current density
in (pA/ Hz)
5
Ta = 25°C
Vss=-5.2V
AC-Coupled
RL=50Ω
Pin=-7dBm
with Bessel filter
1
10
100
Frequency, f (MHz)
1000
3
FRM3Z621KT/LT
InGaAs-PIN/Preamp
Receiver
Fig. 5 Bit Error Rate at 1,310nm and a 622Mbps NRZ
2
23
-1 PRBS for various case temperature
10
-3
Ta=25°C
10
-4
85°C
λ=1,310nm
622Mb/s
NRZ
Vss=-5.2V
VR=5V
10
-5
Bit Error Rate
10
-6
-40°C
10
-7
10
-8
10
-9
10
-10
10
-11
10
-12
-40
-35
-30
-25
Received Optical Power (dBm)
“KT” PACKAGE
GND
UNIT: mm
2-C1.5
VR
VSS
14.0±0.15
17.0±0.2
8.4±0.2
Ø0.9±0.1
OUT
4-Ø0.45±0.05
Ø6.0 MAX
P.C.D. 2.0±0.2
P.C.D. 4.0±0.2
Ø7.2 MAX
2.5±0.1
4.4 MAX
10.0 MIN
32.0 MAX
GND
VR
2.0±0.1
4.2±0.2
1000 MIN
VSS
8.4±0.2
OUT
“LT” PACKAGE
GND
VR
VSS
VR
UNIT: mm
VSS
14.0±0.15
17.0±0.2
Ø0.9
OUT
P.C.D. 2.0±0.2
4-Ø0.45±0.05
Ø6.0 MAX
P.C.D. 4.0±0.2
OUT
7.6 MAX
1.0±0.1
2.5±0.1
Ø7.2 MAX
GND
32.0 MAX
1000 MIN
10.0 MIN
4
InGaAs-PIN/Preamp
Receiver
For further information please contact:
FRM3Z621KT/LT
CAUTION
Eudyna Devices Inc. products contain
gallium arsenide
(GaAs)
which can be hazardous to the human body and the environment.
For safety, observe the following procedures:
Eudyna Devices USA Inc.
2355 Zanker Rd.
San Jose, CA 95131-1138, U.S.A.
TEL: (408) 232-9500
FAX: (408) 428-9111
www.us.eudyna.com
• Do not put this product into the mouth.
• Do not alter the form of this product into a gas, powder, or liquid
through burning, crushing, or chemical processing as these by-products
are dangerous to the human body if inhaled, ingested, or swallowed.
• Observe government laws and company regulations when discarding this
product. This product must be discarded in accordance with methods
specified by applicable hazardous waste procedures.
Eudyna Devices Europe Ltd.
Network House
Norreys Drive
Maidenhead, Berkshire SL6 4FJ
United Kingdom
TEL: +44 (0) 1628 504800
FAX: +44 (0) 1628 504888
Eudyna Devices Asia Pte Ltd.
Hong Kong Branch
Rm. 1101, Ocean Centre, 5 Canton Rd.
Tsim Sha Tsui, Kowloon, Hong Kong
TEL: +852-2377-0227
FAX: +852-2377-3921
Eudyna Devices Inc. reserves the right to change products and specifications
without notice. The information does not convey any license under rights of
Eudyna Devices Inc. or others.
© 2004 Eudyna Devices USA Inc.
Printed in U.S.A.
Eudyna Devices Inc.
Sales Division
1, Kanai-cho, Sakae-ku
Yokohama, 244-0845, Japan
TEL: +81-45-853-8156
FAX: +81-45-853-8170
5
