2.54 mm pitch connectors
Straight DIP type male connector for PCBs
DIC-149( )-( )P[Z-149( )-( )P]
●
Configuration of product Part No.
For PCBs
Straight DIP
0.6✕0.4 mm square contacts
DIC-149 ( )- ( )P
➀
➁
➂
➀
Series name
➁
Contact plating
Blank: Min. 0.7
µm
Gold plate
A
: Min. 0.4
µm
Gold plate
B
: Min. 0.2
µm
Gold plate
C
: Min. 0.76
µm
Gold plate
E
: Min. 0.1
µm
Gold plate
➂
No. of contacts: 1- 24
(A)
B
2.54
2.54
0.6≈0.4
0.4
➁
4.7
●
Dimensions
Part No.
DIC-149( )-1P
DIC-149( )-2P
DIC-149( )-3P
DIC-149( )-4P
DIC-149( )-5P
A
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
B
-
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
10
➀
6.5
œ0.4
DIC-149( )-6P
DIC-149( )-7P
DIC-149( )-8P
DIC-149( )-9P
DIC-149( )-10P
DIC-149( )-11P
DIC-149( )-12P
Since these products are supplied to customers by cutting off to
the specified number of contacts, both sides of the insulator
may have cutaway surfaces.
DIC-149( )-13P
DIC-149( )-14P
DIC-149( )-15P
DIC-149( )-16P
DIC-149( )-17P
DIC-149( )-18P
DIC-149( )-19P
DIC-149( )-20P
DIC-149( )-21P
--0
0.8
+0.1
2.54
--
+0.05
●
Components
➀
Insulator
➁
Contacts
B
--0.1
PCB layout for reference only
+
DIC-149( )-22P
DIC-149( )-23P
DIC-149( )-24P
Mating connectors:
DIC series of Shunt plugs for 0.6✕0.4 mm square contacts
Others
Wire
wrapping Crimping Soldering
IDC
Press-in
SMT
DIP
