Document 233-1
SMT Power Inductors - LPO1704 Series
We now offer an improved version of
this series: LPO6610.
It has identical electrical specifications and footprint,
and comes in a more robust package that features part
identification marking. We will, however, continue to
produce the LPO1704 indefinitely.
Measuring just 1 mm high, the
LPO1704 is the world’s lowest pro-
file power inductor!
This series has been specially de-
signed for applications requiring the
smallest possible footprint and low-
est height: notebook computers,
PDAs, PC Cards, mobile phones and
other handheld products.
The specially designed ceramic case totally protects the
winding while the flat top provides the best possible
surface for pick and place handling.
1
0.216
max
5,50
0.040
max
1,00
0.260
max
6,60
0.168
Ø
4,30
0.192
4,90
0.100
2,50
0.134
3,40
0.100
2,50
Part number
LPO1704-122M_
LPO1704-152M_
LPO1704-222M_
LPO1704-332M_
LPO1704-472M_
LPO1704-682M_
LPO1704-103M_
LPO1704-153M_
LPO1704-223M_
LPO1704-333M_
LPO1704-473M_
LPO1704-683M_
LPO1704-104M_
LPO1704-154M_
LPO1704-224M_
LPO1704-334M_
1
L
2
DCR
±20% max
(µH) (Ohms)
1.2 0.08
1.5 0.10
2.2 0.12
3.3 0.16
4.7 0.20
6.8
10
15
22
33
0.32
0.41
0.55
0.85
1.3
1.8
2.5
3.5
5.0
7.0
15.0
1
SRF
typ
(MHz)
190
140
115
90
88
66
55
42
38
29
22
18
14
12
10
8
2
Isat
3
(A)
2.1
1.9
1.6
1.3
1.1
0.90
0.80
0.65
0.50
0.40
0.35
0.30
0.25
0.18
0.16
0.13
3
Irms
4
(A)
1.7
1.5
1.4
1.2
1.1
0.85
0.75
0.60
0.52
0.42
0.36
0.30
0.26
0.21
0.18
0.13
0.029
0,750
XXX
Alternate
marking
0.185
4,70
Recommended
0.270
Land
6,90
Pattern
47
68
100
150
220
330
0.150
3,80
Parts/reel: 7″ 1000 Tape width: 12 mm
For packaging data see Tape and Reel Specifications section.
1. When ordering, please specify packaging code:
LPO1704-334M_
C
=
7” machine-ready reel
EIA-481 embossed plastic tape (1000 per reel).
B
=
Less than full reel
In tape, but not machine-ready. To have a leader
and trailer added ($25 charge), use code letter C instead.
2. Tested at 100 kHz, 0.1 Vrms, 0 Adc.
3. DC current at which the inductance drops 10% (typ) from its value without
current.
4. Average current for a 40°C rise above 25°C ambient.
5. Operating temperature range -40°C to +85°C.
6. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Specifications subject to change without notice.
Document 233-1
Revised 05/28/03
