HIgH FrequenCy Power ProDuCts
L10-xxxx QTR-Pak
TM
High Reliability, SMT Dual Inductors/1:1 Transformers
RoHS
COMPLIANT
Parallel
BH Part
Number
L10-1004
7
L10-1005
L10-1006
L10-1007
L10-1008
L10-1009
L10-1010
L10-1011
L10-1012
L01-0726
L10-1016
L10-1017
L10-1018
L10-1019
L10-1020
L10-1021
L10-1022
L10-1023
L10-1024
L10-1025
L10-1026
L10-1027
L10-1028
L10-1029
L10-1032
L10-1037
L10-1038
L10-1042
L10-1043
L10-1044
L10-1047
L10-1048
Loc (uH)
@0ADC
1.36
1.85
2.41
3.05
3.77
4.56
5.43
6.37
7.39
8.48
12.21
13.61
15.08
18.25
21.72
25.49
29.56
33.93
38.60
43.58
48.86
54.44
60.32
66.50
86.86
126.82
135.72
174.32
184.73
200.90
247.35
272.38
Typical Loc
(uH) Biased
2
1.1
1.5
1.9
2.4
3.0
3.6
4.3
5.1
5.9
6.8
9.8
10.9
12.1
14.6
17.4
20.4
23.6
27.1
30.9
34.9
39.1
43.6
48.3
53.2
69.5
101.5
108.6
139.5
147.8
160.7
197.9
217.9
Max Current
(Adc)
3
11.87
10.17
8.90
7.91
7.12
6.47
5.94
5.48
5.09
4.75
3.96
3.75
3.56
3.24
2.97
2.74
2.54
2.37
2.23
2.09
1.98
1.87
1.78
1.70
1.48
1.23
1.19
1.05
1.02
0.98
0.88
0.84
Parallel DCR
(Ohms)
1
0.004
0.004
0.005
0.007
0.010
0.011
0.012
0.013
0.018
0.019
0.023
0.024
0.041
0.045
0.049
0.066
0.071
0.076
0.104
0.110
0.117
0.155
0.164
0.172
0.243
0.373
0.386
0.437
0.450
0.596
0.661
0.694
Loc (uH)
@0ADC
5.4
7.4
9.7
12.2
15.1
18.2
21.7
25.5
29.6
33.9
48.9
54.4
60.3
73.0
86.9
101.9
118.2
135.7
154.4
174.3
195.4
217.8
241.3
266.0
347.4
507.3
542.9
697.3
738.9
803.6
989.4
1089.5
Series
Typical Loc
(uH) Biased
2
4.3
5.9
7.7
9.8
12.1
14.6
17.4
20.4
23.6
27.1
39.1
43.6
48.3
58.4
69.5
81.6
94.6
108.6
123.5
139.5
156.3
174.2
193.0
212.8
278.0
405.8
434.3
557.8
591.1
642.9
791.5
871.6
Max Current
(Adc)
3
5.94
5.09
4.45
3.96
3.56
3.24
2.97
2.74
2.54
2.37
1.98
1.87
1.78
1.62
1.48
1.37
1.27
1.19
1.11
1.05
0.99
0.94
0.89
0.85
0.74
0.61
0.59
0.52
0.51
0.49
0.44
0.42
Series DCR
(Ohms)
1
0.015
0.018
0.020
0.029
0.040
0.045
0.049
0.053
0.072
0.077
0.092
0.097
0.163
0.180
0.196
0.264
0.284
0.304
0.415
0.441
0.467
0.622
0.654
0.687
0.972
1.491
1.543
1.748
1.800
2.384
2.645
2.776
Pb
1. Parallel DCR = DCR per winding / 2. Series DCR = DCR per winding x 2.
2. Inductance measured at 25˚ C.
3. Max. current measured at 25˚ C, 20% inductance roll-off. Above 85˚ C operating temp., max. current is reduced.
4. Plots of Inductance vs. Current available for all above parts. Contact BH.
5. Reflow: 30 Seconds @ 260˚ C maximum.
6. T&R available: 400 per 13" reel, 1,200 minimum release. Smaller quantities shipped in JEDEC trays.
7. Highlighted part numbers are standard products. Others are available as non-standard parts with longer lead times.
8. RoHS parts designated with “L” (e.g., L10-1007). The same part as non-RoHS designated with “5” (e.g., 510-1007).
9. Both RoHS and non-RoHS pins have matte Sn over Ni barrier over brass. Solder is SAC or Sn63/Pb37, respectively.
10. Above parts available with Sn90/Pb10 plated pins on a “custom” part basis. Contact BH for details.
1
4
1
4
1
4
2
3
2
3
2
3
Parallel
Series
Transformer
