WDCL-C-B-L-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Optical fiber> WDCL-C-B-L-4

WDCL-C-B-L-4: DescriptionWavelength Division Mux/Demux, 1570nm Min, 1610nm Max, SC/APC Connector; CategoryWireless rf/communication Optical fiber; File Size268KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric Compare View All

WDCL-C-B-L-4 Overview

Wavelength Division Mux/Demux, 1570nm Min, 1610nm Max, SC/APC Connector

WDCL-C-B-L-4 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknow
Other features	ITS ALSO OPERATES IN 1500 TO 1563 NM WAVELENGTH
Connection Type	SC/APC CONNECTOR
Fiber optic equipment types	WAVELENGTH DIVISION MUX/DEMUX
Fiber type	SMF-28
Maximum insertion loss	0.8 dB
Minimum isolation	25 dB
Maximum operating temperature	65 °C
Minimum operating temperature
Maximum operating wavelength	1610 nm
Minimum operating wavelength	1570 nm
Nominal operating wavelength	1590 nm
minimum return loss	50 dB

Preview

Download Datasheet

View All

WDM

C Band and L Band FWDM

Parameter

Operating Wavelength Range (Pass Band)

Operating Wavelength Range (Reflect Band)

Insertion Loss (Pass Band)

Insertion Loss (Reflect Band)

Isolation (Pass Band)

Isolation (Reflect Band)

Pass Band Ripple

Return Loss

Directivity

PDL

PMD

Maximum Power Handling

Operating Temperature

Storage Temperature

Package Dimension

Bare Fiber (B)

900

µm

loose tube (L)

Specification

1500-1563 nm or 1570-1610 nm

1570-1610 nm or 1500-1563 nm

≤

0.8 dB

≤

0.5 dB

≥

25dB

≥

12 dB

≤

0.3 dB

≥

50 dB

≥

55 dB

≤

0.1 dB

≤

0.1 ps

300 mW

- 0° C ~ + 65° C

- 40° C ~ + 85° C

5.5 mm (Φ) x 35 mm (L)

5.5 mm (Φ) x 39 mm (L)

Note 1: All values specified are without connectors.

Note2: Higher performance specifications are available upon request.

Note3: Fiber Type – Corning SMF-28e.

Note4: Over operating temperature, all SOP.

W D C L

C: C band reflection

L: L band reflection

Fiber Length

A: 1 meter

B: 1.5 meter

S: Special

Pigtail Style

(=Package style)

B: bare fiber

L: 900

µm

loose tube

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/ UPC

C: ST

www.lighteltech.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax

WDCL-C-B-L-4 Related Products

	WDCL-C-B-L-4	WDCL-C-A-L-7
Description	Wavelength Division Mux/Demux, 1570nm Min, 1610nm Max, SC/APC Connector	Wavelength Division Mux/Demux, 1570nm Min, 1610nm Max, LC/UPC Connector
Maker	Lightel Technologies Inc.	Lightel Technologies Inc.
Reach Compliance Code	unknow	unknown
Other features	ITS ALSO OPERATES IN 1500 TO 1563 NM WAVELENGTH	ITS ALSO OPERATES IN 1500 TO 1563 NM WAVELENGTH
Connection Type	SC/APC CONNECTOR	LC/UPC CONNECTOR
Fiber optic equipment types	WAVELENGTH DIVISION MUX/DEMUX	WAVELENGTH DIVISION MUX/DEMUX
Fiber type	SMF-28	SMF-28
Maximum insertion loss	0.8 dB	0.8 dB
Minimum isolation	25 dB	25 dB
Maximum operating temperature	65 °C	65 °C
Maximum operating wavelength	1610 nm	1610 nm
Minimum operating wavelength	1570 nm	1570 nm
Nominal operating wavelength	1590 nm	1590 nm
minimum return loss	50 dB	50 dB
