Pin Strip |
Spacing 5.0 mm
STL950/..G-5.0-V-P2.6-BK-HT
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
-
-
-
-
-
-
Order Data (Spacing 5.0 mm)
Insulating Material
Material
Flammability Class
PPA
UL 94 V-0
2
3
4
11.20
16.20
21.20
26.20
31.20
36.20
41.20
STL950/2G-5.0-V-P2.6-BK-HT
STL950/3G-5.0-V-P2.6-BK-HT
STL950/4G-5.0-V-P2.6-BK-HT
STL950/5G-5.0-V-P2.6-BK-HT
STL950/6G-5.0-V-P2.6-BK-HT
STL950/7G-5.0-V-P2.6-BK-HT
STL950/8G-5.0-V-P2.6-BK-HT
Poles
Width (mm)
Article Designation
Article
Number
50950025387R
50950035387R
50950045387R
50950055387R
50950065387R
50950075387R
50950085387R
PU
140
140
140
140
140
140
140
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
8
Dimensions
PCB Hole Diameter
1.4 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
Materials
Contact Pin
Copper
Alloy
Accessoires
Figure
Designation
Article Number
Coding Star CS2-5.0/5.08-LIGHT Order Data: 50000000028
GREY-HT
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
217 - 245 °C
60 s
Tape on Reel
Poles
Reel (RD/")
13
13
13
13
13
13
13
Width (R/mm) Pitch (RP/mm)
32
32
56
56
56
56
56
20
20
20
20
20
20
20
Pieces (PCS)
140
140
140
140
140
140
140
2
Colours
BLACK, RAL 9011
Colours according to RAL, there may be variations on colour due to production conditions.
3
4
5
6
Counterparts (Spacing 5.0 mm)
Terminal Block
AK950
AK955
AK1100
AK1110
AK1200
AK3950
AK4951
7
8
In combination of connectors with different admission data, the lower value is valid.
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
15 A
C
150 V
15 A
D
300 V
10 A
250 V
12 A
III
1.60 kV
1.30 kV
1.60 kV
4.0 kV
3
