218-4LPSJ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Mechanical and electronic products> switch> 218-4LPSJ

218-4LPSJ: DescriptionSlide Dip Switch, 4 Switches, SPST, Latched, 0.025A, 24VDC, Solder Terminal, Surface Mount-straight, ROHS COMPLIANT; CategoryMechanical and electronic products switch; File Size298KB，2 Pages; ManufacturerCTS; Environmental Compliance

Download Datasheet Parametric View All

218-4LPSJ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	218-4LPSJ	-	-	View	Buy Now

218-4LPSJ Overview

Slide Dip Switch, 4 Switches, SPST, Latched, 0.025A, 24VDC, Solder Terminal, Surface Mount-straight, ROHS COMPLIANT

218-4LPSJ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	CTS
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
ECCN code	EAR99
Factory Lead Time	4 weeks
body width	5.8 mm
body height	2.7 mm
Body length or diameter	6.25 mm
Maximum contact current (DC)	0.025 A
Contact (DC) maximum rated R load	.025A@24VDC
Maximum contact voltage (DC)	24 V
Electrical life	1000 Cycle(s)
Manufacturer's serial number	218
Installation features	SURFACE MOUNT-STRAIGHT
Number of switching segments	4
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
method of packing	ANTI-STATIC TUBE
seal	BOTTOM SEALED
surface mount	NO
Switch action	LATCHED
switch function	SPST
Switch type	SLIDE DIP SWITCH
Terminal surface	Gold Flash (Au)
Termination type	SOLDER
Base Number Matches	1

Preview

Download Datasheet

View All

Electrocomponents

Series 218

Data Sheet

Half Pitch, SMD DIP Switch

SMT Half Pitch DIP

Switch–Auto

Placeable

Features

Optimized Mechanical Features

• Gull-wing and "J" bend terminal configurations

• Low profile actuators prevent accidental actuation

• SPST configuration available

Optimized Contact System

• Redundant, wiping contact

• Contactor does not deflect during actuation

• 0.6 mm/.024" actuator travel

Materials

• Gold plated beryllium copper contacts

• Gold flash coated terminals

• High temperature materials (UL94V-0)

• RoHS Compliant

• Optional top tape seal for board spray washing

Electrical and Mechanical Specifications

Sw i t c h Fu n c t i o n

SPST - 2, 4, 6, 8, 10, and 12 positions

Sw i t c h Co n t ac t Res i s t an ce

100 milliohms maximum initial

100 milliohms maximum at end of life

In s u l at i o n Res i s t an c e

100 megohms minimum between

insulated terminals

Di el ec t r i c St r en g t h

350 VAC for 1 minute between

adjacent switches

No n s w i t c h i n g Rat i n g

100 mA or 50 VDC maximum

Sw i t c h Cap ac i t an c e

10 pF maximum between adjacent

closed switches

Op er at i n g Tem p er at u r e

- 55°C to +85°C

A c t u at i o n L i f e

1,000 cycles switching 25 mA @ 24 VDC

Co p l an ar i t y

Coplanarity of 0.1mm/.004" maximum

Allowable Solder Time

Up to 60 seconds at 260°C

Vi b r at i o n

Per MIL-STD-202G, method 204D, condition B

(.06" or 15G’s between 10 HZ to 2 KHz) with

no contact inconsistencies greater than 1

microsecond.

Sh o c k

Per MIL-STD-202G, method 213B, condition A

(50G’s) with no contact inconsistencies greater

than 1 microsecond.

Seal i n g

Standard bottom seal

Optional top tape seal for board spray washing

Mar k i n g

Special marking available-consult CTS

Packaging

Standard : Anti-static tube packaging

Optional : Tape and reel packaging

1-2

CTS Electrocomponents

www.ctscorp.com

06/14/17
