EQRE13 Series Oscillator
Quartz Crystal Clock Oscillators XO (SPXO) LVDS (DS) 3.3Vdc 6 Pad 5.0mm x 7.0mm Ceramic Surface Mount (SMD)
2011/65 +
2015/863
168 SVHC
Revision C 06/25/2014
Electrical Specifications
Nominal Frequency
10.000MHz to 200.000MHz
Some frequencies within this range may not be available.
Frequency Tolerance/Stability
Inclusive of all conditions: Calibration Tolerance (at 25°C), Frequency
Stability over the Operating Temperature Range, Supply Voltage
Change, Output Load Change, First Year Aging at 25°C, Shock, and
Vibration
±100ppm Maximum
±50ppm Maximum
±25ppm Maximum
±20ppm Maximum
0°C to +70°C
-20°C to +70°C
-40°C to +85°C
±3ppm Maximum First Year
3.3V
DC
±5%
30mA Maximum
1.43V
DC
Typical, 1.6V
DC
Maximum
1.1V
DC
Typical, 0.9V
DC
Minimum
50mV Maximum
247mV Minimum, 330mV Typical, 454mV Maximum
1.125V Minimum, 1.250V Typical, 1.375V Maximum
Measured at 50% of waveform
50 ±10(%)
50 ±5(%)
Measured at 20% to 80% of Waveform
400pSec Maximum
50mV Maximum
100 Ohms Between Output and Complementary Output
LVDS
Click to Open Phase Noise Table
Standby (on Pad 1)
Standby (on Pad 2)
70% of V
DD
Minimum or No Connect to Enable Output and
Complementary Output
Operating Temperature Range
Aging at 25°C
Supply Voltage
Input Current
Output Voltage Logic High (V
OH
)
Output Voltage Logic Low (V
OL
)
Differential Output Error (dVod)
Differential Output Voltage (Vod)
Offset Voltage (Vos)
Duty Cycle
Rise Time/Fall Time
Offset Error (dVos)
Load Drive Capability
Output Logic Type
Phase Noise
Output Control Function
Output Control Input Voltage Logic High
(Vih)
1 of 12
28-Jan-2016 2:20 PM
Ecliptek | EQRE13 Series Oscillator
http://www.ecliptek.com/oscillators/EQRE13/
Output Control Input Voltage Logic Low
(Vil)
Standby Output Enable Time
Standby Output Disable Time
Standby Current
30% of V
DD
Maximum to Disable Output and Complementary Output
(High Impedance)
10mSec Maximum
200nSec Maximum
Without Load
10 A Maximum
Click to Open RMS Phase Jitter Table
0.2pSec Typical
1.0pSec Typical
1.5pSec Typical
40pSec Maximum
-55°C to +125°C
10mSec Maximum
RMS Phase Jitter
Period Jitter (Deterministic)
Period Jitter (Random)
Period Jitter (One Sigma)
Period Jitter (tp-p)
Storage Temperature Range
Start Up Time
2 of 12
28-Jan-2016 2:20 PM
Ecliptek | EQRE13 Series Oscillator
http://www.ecliptek.com/oscillators/EQRE13/
RMS Phase Jitter
Fj=12kHz to 20MHz (Random)
Nominal Frequency Range
10MHz to 50MHz
50.000001MHz to 99.999999MHz
100MHz to 200MHz
RMS Phase Jitter
600fSec Maximum
450fSec Maximum
200fSec Maximum
4 of 12
28-Jan-2016 2:20 PM
Ecliptek | EQRE13 Series Oscillator
http://www.ecliptek.com/oscillators/EQRE13/
Mechanical Dimensions
All Dimensions in Millimeters
Pin 1: No Connect Or Standby
Pin 2: No Connect Or Standby
Pin 3: Case/Ground
Pin 4: Output
Pin 5: Complementary Output
Pin 6: Supply Voltage
Marking Specifications
Line 1:
Line 2:
ECLIPTEK
XXXXXXM
XXXXXX = Nominal Frequency (5 digits + Decimal)
M = Frequency Unit of Measure (MHz)
XXXXX
XXXXX = Ecliptek Manufacturing Identifier
Line 3:
5 of 12
28-Jan-2016 2:20 PM
