SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
B4155
1960,00 MHz
Ceramic package
DCC6C
Features
q
Low-loss RF filter for mobile telephone
PCS systems, receive path
q
Usable passband 60 MHz
q
No matching network required for operation
at 50
Ω
q
Ceramic Package for
Surface Mounted
Technology
(SMT)
Terminals
q
Ni, gold-plated
Dimensions in mm, approx. weight 0,037 g
Pin configuration
2
1, 3
5
4, 6
Input
Input - ground
Output
Output - ground
Type
LB95D
Ordering code
B39202-B4155-U410
Marking and Package
according to
C61157-A7-A67
Packing
according to
F61074-V8088-Z000
Electrostatic Sensitive Device
(ESD)
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
ESD voltage
Input power max.
T
T
stg
V
DC
V
ESD
P
IN
– 20/+ 80
– 40/+ 85
0
50
5
0
˚C
˚C
V
V
dBm
dBm
source and load impedance 50
Ω
peak power of GSM signal,
duty cycle 1 : 8
CDMA signal
2
Apr 14, 2000
SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
B4155
1960,00 MHz
T
= +25 +- 5˚C
Z
S
= 50
Ω
Z
L
= 50
Ω
min.
typ.
1960,0
max.
—
MHz
Center frequency
Maximum insertion attenuation
1930,0 ...1990,0
Amplitude ripple
(p-p)
1930,0 ...1990,0
Input VSWR
1930,0 ...1990,0
Output VSWR
1930,0 ...1990,0
MHz
MHz
f
c
α
max
MHz
∆α
MHz
—
—
2,8
3,5
dB
—
1,3
2,0
dB
—
1,8
2,1
—
1,8
2,1
Attenuation
10,0
600,0
1500,0
1830,0
1900,0
2010,0
2020,0
2070,0
5000,0
... 600,0
...1500,0
...1830,0
...1900,0
...1910,0
...2020,0
...2070,0
...5000,0
...6000,0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
α
20,0
18,0
20,0
20,0
11,0
10,0
20,0
20,0
10,0
22,0
19,5
22,0
35,0
21,0
17,0
26,0
23,0
18,0
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
3
Apr 14, 2000
SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
B4155
1960,00 MHz
T
= -20 to +80˚C
Z
S
= 50
Ω
Z
L
= 50
Ω
min.
typ.
1960,0
max.
—
MHz
Center frequency
Maximum insertion attenuation
1930,0 ...1990,0
Amplitude ripple
(p-p)
1930,0 ...1990,0
Input VSWR
1930,0 ...1990,0
Output VSWR
1930,0 ...1990,0
MHz
MHz
f
c
α
max
MHz
∆α
MHz
—
—
3,1
4,1
dB
—
1,6
2,6
dB
—
1,8
2,1
—
1,8
2,1
Attenuation
10,0
600,0
1500,0
1830,0
1900,0
2010,0
2020,0
2070,0
5000,0
... 600,0
...1500,0
...1850,0
...1900,0
...1910,0
...2020,0
...2070,0
...5000,0
...6000,0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
α
20,0
18,0
20,0
15,0
8,5
7,5
15,0
20,0
10,0
22,0
19,5
22,0
35,0
16,5
13,0
26,0
23,0
18,0
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
4
