AMEL10-12SMJZ-STD

Description
AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.9; Efficiency (%): 81; Max Capacitive load (µF): 2000; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 76; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25
CategoryPower/power management    The power supply circuit
File Size266KB，3 Pages
ManufacturerAimtec
Websitehttp://www.aimtec.ca/
Environmental Compliance
Download Datasheet Parametric Compare View All

AMEL10-12SMJZ-STD Overview

AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.9; Efficiency (%): 81; Max Capacitive load (µF): 2000; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 76; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25

AMEL10-12SMJZ-STD Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerAimtec
package instruction,
Reach Compliance Codeunknow
ECCN codeEAR99
Analog Integrated Circuits - Other TypesAC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage264 V
Minimum input voltage85 V
Nominal input voltage115 V
JESD-30 codeR-PXMA-X4
length76 mm
Number of functions1
Output times1
Number of terminals4
Maximum operating temperature55 °C
Minimum operating temperature
Maximum output voltage12.24 V
Minimum output voltage11.76 V
Nominal output voltage12 V
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formMICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)NOT SPECIFIED
surface mountNO
technologyHYBRID
Temperature levelCOMMERCIAL
Terminal formUNSPECIFIED
Terminal locationUNSPECIFIED
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum total power output10 W
Fine-tuning/adjustable outputNO
width31.5 mm

Preview

Download Datasheet
Click on Series name for product info on aimtec.com
Series AMEL10-MJZ
10 Watt | AC-DC / DC-DC Converter
FEATURES:
•
I/O Isolation 4000VAC
•
Operating Temp: -25
°
C to +70
°
C
•
Over current, Over Voltage
•
Input: 85-264VAC, 47-440Hz, or 100-370VDC
•
•
•
Low no load consumption ≤0.5W
Continuous Short Circuit Protection
Up to 83% efficiency
Models
Single output
Model
AMEL10-3.3SMJZ
AMEL10-5SMJZ
AMEL10-9SMJZ
AMEL10-12SMJZ
AMEL10-15SMJZ
AMEL10-24SMJZ
Input Voltage
(VAC/Hz)
85-264/47-440
85-264/47-440
85-264/47-440
85-264/47-440
85-264/47-440
85-264/47-440
Input
Voltage
(VDC)
100-370
100-370
100-370
100-370
100-370
100-370
Max Output
wattage
(W)
6.6
10
10
10
10
10
Output
Voltage
(V)
3.3
5
9
12
15
24
Output
Current max
(A)
2.00
2.00
1.10
0.90
0.70
0.45
Maximum
capacitive
load
(µF)
15,000
12,000
6,000
2,000
1,500
500
Efficiency
(%)
71
76
80
81
82
83
*Output power must not exceed the listed values.
All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at rated output load unless
otherwise specified.
Input Specifications
Parameters
Current
Inrush current <2ms (cold start)
Leakage current
External fuse
Input dissipation
Conditions
115VAC
230VAC
115VAC
230VAC
slow blow type
No Load
Typical
0.23
0.15
Maximum
10
20
0.25
Units
A
A
A
A
mA
A
W
2
≤0.5
Output Specifications
Parameters
Voltage accuracy
Line regulation
Load regulation
Ripple & Noise
Hold up time
Conditions
3.3V output
Others
Full load
10-100% load
20MHz bandwidth
230VAC
Typical
±3
±2
±0.5
±1
50
80
Maximum
Units
%
%
%
mV p-p
ms
100
Isolation Specifications
Parameters
Tested I/O voltage
Isolation resistance
Conditions
60 sec
Typical
>1000
Rated
4000
Units
VAC
MΩ
General Specifications
Parameters
Switching frequency
Protection class
Over current protection
Over voltage protection
Short circuit protection
Short circuit restart
Operating temperature
www.aimtec.com
F 052e R8.B
Conditions
100% load
Auto recovery
Typical
65
Class II
110 - 200
Zener Diode Clamp
Continuous
Auto recovery
-25 to +70
Maximum
Units
KHz
% of Iout
See derating table
o
C
Tel: +1 514 620 2722
1 of 3
Toll free: + 1 888 9 AIMTEC (924 6832)
North America only
REV: 02/20/A

AMEL10-12SMJZ-STD Related Products

AMEL10-12SMJZ-STD AMEL10-15SMJZ-STD AMEL10-24SMJZ-ST AMEL10-3.3SMJZ-STD AMEL10-3.3SMJZ-ST AMEL10-5SMJZ-ST AMEL10-12SMJZ-ST AMEL10-15SMJZ-ST AMEL10-24SMJZ-STD AMEL10-5SMJZ-STD
Description AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.9; Efficiency (%): 81; Max Capacitive load (µF): 2000; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 76; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 15; Output voltage max: 15; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.7; Efficiency (%): 82; Max Capacitive load (µF): 1500; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 76; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 70; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 24; Output voltage max: 24; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.45; Efficiency (%): 83; Max Capacitive load (µF): 500; Package type: Encapsulated; Mounting: Screw terminal; W (in): 1.24; L (in): 2.99; H (in): 1.09; W (mm): 31.5; L (mm): 76; H (mm): 27.8; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 3.3; Output voltage max: 3.3; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 2; Efficiency (%): 71; Max Capacitive load (µF): 15000; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 27.8; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 70; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 3.3; Output voltage max: 3.3; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 2; Efficiency (%): 71; Max Capacitive load (µF): 15000; Package type: Encapsulated; Mounting: Screw terminal; W (in): 1.24; L (in): 2.99; H (in): 1.09; W (mm): 31.5; L (mm): 27.8; H (mm): 27.8; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 70; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 5; Output voltage max: 5; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 2; Efficiency (%): 76; Max Capacitive load (µF): 12000; Package type: Encapsulated; Mounting: Screw terminal; W (in): 1.24; L (in): 2.99; H (in): 1.09; W (mm): 31.5; L (mm): 76; H (mm): 27.8; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 70; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 12; Output voltage max: 12; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.9; Efficiency (%): 81; Max Capacitive load (µF): 2000; Package type: Encapsulated; Mounting: Screw terminal; W (in): 1.24; L (in): 2.99; H (in): 1.09; W (mm): 31.5; L (mm): 76; H (mm): 27.8; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 70; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 15; Output voltage max: 15; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.7; Efficiency (%): 82; Max Capacitive load (µF): 1500; Package type: Encapsulated; Mounting: Screw terminal; W (in): 1.24; L (in): 2.99; H (in): 1.09; W (mm): 31.5; L (mm): 76; H (mm): 27.8; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 24; Output voltage max: 24; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 0.45; Efficiency (%): 83; Max Capacitive load (µF): 500; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 76; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25 AC/DC Converter; Product Weight (grams): 90; Input voltage min (V): 85; Input voltage max (V): 264; Input frequency (Hz): 47-440; Output voltage min: 5; Output voltage max: 5; Output voltage dual assymetric (y/n): Single; Output Power (W): 10; Max Output current (A): 2; Efficiency (%): 76; Max Capacitive load (µF): 12000; Package type: Encapsulated; Mounting: Screw terminal DIN rail; W (in): 1.24; L (in): 2.99; H (in): 1.28; W (mm): 31.5; L (mm): 76; H (mm): 32.4; Min Operating temperature: -25; Max operating temperature (°C): 70; Isolation (VAC): 4000; EMC compliance 1: EN 55011 Class A; Case material: Plastic (flammability to UL 94V-0) ; Application 3 (Medical): 1; Application 4 (building automation/IoT): 1; Application 5 (Industrial): 1; MTBF (h): 300000; Derating : 55; Voltage Accuracy (%): ±3; Line Regulation (% of Vin): ±0.5; Load Regulation %: ±0.5; Ripple & Noise (mV p-p): 100; Switching Frequency typ (KHz): 65; Short circuit protection: Continuous; Leakage current (mA): 0.25
Is it lead-free? Lead free Lead free Lead free Lead free Lead free Lead free Lead free Lead free Lead free Lead free
Is it Rohs certified? conform to conform to conform to conform to conform to conform to conform to conform to conform to conform to
Maker Aimtec Aimtec Aimtec Aimtec Aimtec Aimtec Aimtec Aimtec Aimtec Aimtec
Reach Compliance Code unknow unknown unknown unknown unknown unknown unknow unknow unknow unknow
Analog Integrated Circuits - Other Types AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE AC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage 264 V 264 V 264 V 264 V 264 V 264 V 264 V 264 V 264 V 264 V
Minimum input voltage 85 V 85 V 85 V 85 V 85 V 85 V 85 V 85 V 85 V 85 V
Nominal input voltage 115 V 115 V 115 V 115 V 115 V 115 V 115 V 115 V 115 V 115 V
JESD-30 code R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4 R-PXMA-X4
length 76 mm 76 mm 76 mm 76 mm 76 mm 76 mm 76 mm 76 mm 76 mm 76 mm
Number of functions 1 1 1 1 1 1 1 1 1 1
Output times 1 1 1 1 1 1 1 1 1 1
Number of terminals 4 4 4 4 4 4 4 4 4 4
Maximum operating temperature 55 °C 55 °C 55 °C 55 °C 55 °C 55 °C 55 °C 55 °C 55 °C 55 °C
Maximum output voltage 12.24 V 15.3 V 24.48 V 3.399 V 3.399 V 5.1 V 12.24 V 15.3 V 24.48 V 5.1 V
Minimum output voltage 11.76 V 14.7 V 23.52 V 3.201 V 3.201 V 4.9 V 11.76 V 14.7 V 23.52 V 4.9 V
Nominal output voltage 12 V 15 V 24 V 3.3 V 3.3 V 5 V 12 V 15 V 24 V 5 V
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
surface mount NO NO NO NO NO NO NO NO NO NO
technology HYBRID HYBRID HYBRID HYBRID HYBRID HYBRID HYBRID HYBRID HYBRID HYBRID
Temperature level COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL COMMERCIAL
Terminal form UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED
Terminal location UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED UNSPECIFIED
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Maximum total power output 10 W 10 W 10 W 6.6 W 6.6 W 10 W 10 W 10 W 10 W 10 W
Fine-tuning/adjustable output NO NO NO NO NO NO NO NO NO NO
width 31.5 mm 31.5 mm 31.5 mm 31.5 mm 31.5 mm 31.5 mm 31.5 mm 31.5 mm 31.5 mm 31.5 mm
