with Ground-Fingers and EMI/Shrinkboot Backshell
VG95328 V
Bayonet-Lock
Straight Plug Connector
VG95328
Connectors
Shell Size and
Insert
Arrangements
Alternate Insert
Rotation
W, X, Y or Z
(N = Normal)
VG95328
V
Connector
Style
18-11
S
S
- Socket
P
- Pin
N
L2
D4
D2 D3
3.5
+ 0.3
L1
D1
TABLE I: DIMENSIONS
Shell size
8
10
12
14
16
18
20
22
24
D1
Max.
19.8
23.5
26.5
30.0
33.1
35.3
38.8
42.0
45.1
D2
+ 0.15
-0
9.40
12.60
15.75
18.40
21.60
24.40
26.00
29.40
32.50
13.8
16.6
19.8
23.0
26.2
29.0
32.3
36.6
39.8
D3
Limit
-2.00
-1.60
-1.65
-2.20
-2.20
-2.20
-2.30
-2.20
-3.30
7.0
10.4
13.9
16.5
19.7
22.3
25.5
28.7
31.8
D4
Limit
+2.5
+2.1
+1.7
+2.2
+2.1
+2.4
+2.4
+2.4
+2.5
L1
Max.
23
23
23
23
23
23
28
28
28
L2
Min.
6.5
6.5
6.5
6.5
6.5
8.5
8.5
8.5
8.5
Maximum
Weight in
Grams
14
16
23
30
43
46
63
78
84
© 2008 Glenair, Inc.
www.glenair.com
CAGE Code 06324
Printed in U.S.A.
E-Mail: sales@glenair.com
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
50
with Ground-Fingers and EMI/Shrinkboot Backshell
Contact Arrangements
Arrangement
8 - 3A
10 - 6
12 - 3
12 - 10
14 - 5
14 - 12
14 - 15
14 - 19
16 - 8
16 - 23
16 - 26
18 - 11
18 - 32
20 - 16
20 - 41
22 - 21
22 - 55
24 - 61
Cl. Isol.
Rating
I
I
II
I
II
I
I
I
II
I
I
II
I
II
I
II
I
I
55
61
α
Alternate Insert Orientations
16
Arrangement
8 - 3A
10 - 6
3
12 - 3
12 - 10
5
14 - 5
14 - 12
14 - 15
14 - 19
8
16 - 8
16 - 23
16 - 26
11
18 - 11
18 - 32
16
20 - 16
20 - 41
21
22 - 21
22 - 55
24 - 61
α
Dim. contact size
20
3
6
10
8
14
19
22
26
32
41
1
4
1
Degrees
W
60
90
180
60
40
43
17
30
54
158
60
62
85
238
45
16
30
90
119
138
318
126
135
142
180
155
92
90
110
165
152
270
275
241
222
333
225
175
226
270
349
314
324
338
340
265
347
155
315
180
331
234
270
184
295
273
X
(120)
Y
Z
Normal
Position
MATERIALS
SHELLS
Aluminum Alloy
IAW QQ-A-591 Shells
Stainless Steel
Coupling Pins
Stainless Steel Spring
Alternate Position
with Pin Contacts
Alternate Position with
Solder Contacts
STANDARD FINISH
(For QQ-A-591 Aluminum Shells)
Requirements
Thermal Shock
Salt Spray After
Thermal Shock
Electical Conductivity
Abrasion Resistance
Cadmium with Olive
Drab Passivation
IAW QQ-P-416
-55°C + 125°C
500 hour
Very Good
Very Good
Printed in U.S.A.
E-Mail: sales@glenair.com
INSERTS (Temperature Range)
High Insulation Synthetic Rubber
(Chloroprene): -55°C/+125°C
CRIMP CONTACTS
Copper Alloy with Gold Plating Over Nickel
© 2008 Glenair, Inc.
www.glenair.com
CAGE Code 06324
GLENAIR, INC. • 1211 AIR WAY • GLENDALE, CA 91201-2497 • 818-247-6000 • FAX 818-500-9912
51
VG95328
Connectors
VG95328 V
Bayonet-Lock
