INCHANGE Semiconductor
isc
Silicon NPN Power Transistor
2SC3250
DESCRIPTION
·Low
Collector Saturation Voltage
·Collector-Emitter
Breakdown Voltage-
: V
(BR)CEO
= 300V (Min)
·Good
Linearity of h
FE
·100%
avalanche tested
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for use in humidifier , DC/DC converter and
general purpose applications
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Pulse
Collector Power Dissipation
@ T
C
=25℃
Junction Temperature
Storage Temperature Range
VALUE
300
300
7
0.1
0.2
15
150
-55~150
UNIT
V
V
V
A
A
W
℃
℃
isc Website
：
www.iscsemi.cn
1
isc & iscsemi
is registered trademark
INCHANGE Semiconductor
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
CE(sat)
V
BE(ON)
I
CBO
I
EBO
h
FE-1
h
FE-2
f
T
C
OB
PARAMETER
Collector-Emitter Breakdown Voltage
Collector-Emitter Saturation Voltage
Base-Emitter On Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
Current-Gain—Bandwidth Product
Output Capacitance
CONDITIONS
I
C
= 30mA ; I
B
= 0
I
C
= 50mA; I
B
= 5mA
I
C
= 30mA ; V
CE
=10V
V
CB
= 300V; I
E
= 0
V
EB
= 7V; I
C
= 0
I
C
= 5mA ; V
CE
= 50V
I
C
= 30mA ; V
CE
= 10V
I
E
= 20mA ; V
CE
= 30V
I
E
= 0 ; V
CB
= 10V;f
test
= 1.0MHz
50
30
70
MIN
300
2SC3250
TYP.
MAX
UNIT
V
1.5
1.2
100
100
250
V
V
μA
μA
100
5
MHz
pF
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time
without notification. The information contained herein is presented only as a guide for the
applications of our products.
ISC products are intended for usage in general electronic equipment. The products are not
designed for use in equipment which require specialized quality and/or reliability, or in
equipment which could have applications in hazardous environments, aerospace industry, or
medical field. Please contact us if you intend our products to be used in these special
applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any
particular purpose, nor does ISC assume any liability arising from the application or use of
any products, and specifically disclaims any and all liability, including without limitation
special, consequential or incidental damages.
