SAF-XC164D-32F40FBB datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAF-XC164D-32F40FBB

SAF-XC164D-32F40FBB: DescriptionMicrocontroller, 16-Bit, FLASH, 40MHz, CMOS, PQFP100, 0.50 MM PITCH, GREEN, PLASTIC, TQFP-100; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，75 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

SAF-XC164D-32F40FBB Overview

Microcontroller, 16-Bit, FLASH, 40MHz, CMOS, PQFP100, 0.50 MM PITCH, GREEN, PLASTIC, TQFP-100

SAF-XC164D-32F40FBB Parametric

Parameter Name	Attribute value
Maker	Infineon
package instruction	LFQFP,
Reach Compliance Code	compli
Has ADC	NO
Address bus width	24
bit size	16
maximum clock frequency	16 MHz
DAC channel	NO
DMA channel	NO
External data bus width	16
JESD-30 code	S-PQFP-G100
length	14 mm
Number of I/O lines	79
Number of terminals	100
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
ROM programmability	FLASH
Maximum seat height	1.6 mm
speed	40 MHz
Maximum supply voltage	2.7 V
Minimum supply voltage	2.35 V
Nominal supply voltage	2.5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	14 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

Data Sheet, V1.0, Aug. 2006

XC164D-32F/32R

16-Bit Single-Chip Microcontroller

with C166SV2 Core

Microcontrollers

XC164D-32

Derivatives

Table of Contents

2.1

2.2

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

3.12

3.13

3.14

3.15

3.16

3.17

4.1

4.2

4.3

4.3.1

4.3.2

4.3.3

4.3.4

4.3.5

5.1

5.2

Summary of Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

General Device Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Pin Configuration and Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Functional Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Subsystem and Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Bus Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Central Processing Unit (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interrupt System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-Chip Debug Support (OCDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Capture/Compare Units (CAPCOM1/2) . . . . . . . . . . . . . . . . . . . . . . . . . . .

The Capture/Compare Unit CAPCOM6 . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Purpose Timer (GPT12E) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . .

Real Time Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Asynchronous/Synchronous Serial Interfaces (ASC0/ASC1) . . . . . . . . . .

High Speed Synchronous Serial Channels (SSC0/SSC1) . . . . . . . . . . . .

TwinCAN Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clock Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parallel Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instruction Set Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical Parameters

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Definition of Internal Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-chip Flash Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Clock Drive XTAL1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Testing Waveforms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Bus Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Package and Reliability

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Flash Memory Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Data Sheet

V1.0, 2006-08

SAF-XC164D-32F40FBB Related Products

	SAF-XC164D-32F40FBB	SAF-XC164D-32F20F BB	SAF-XC164D-32F40F BB
Description	Microcontroller, 16-Bit, FLASH, 40MHz, CMOS, PQFP100, 0.50 MM PITCH, GREEN, PLASTIC, TQFP-100	IC MCU 16BIT 256KB FLASH 100TQFP	IC MCU 16BIT 256KB FLASH 100TQFP
speed	40 MHz	20MHz	40MHz
core processor	-	C166SV2	C166SV2
core size	-	16-bit	16-bit
Connectivity	-	CANbus，EBI/EMI，SPI，UART/USART	CANbus，EBI/EMI，SPI，UART/USART
Peripheral	-	PWM，WDT	PWM，WDT
Number of I/Os	-	79	79
Program storage capacity	-	256KB（256K x 8）	256KB（256K x 8）
Program memory type	-	flash memory	flash memory
RAM capacity	-	12K x 8	12K x 8
Voltage - Power Supply (Vcc/Vdd)	-	2.35 V ~ 2.7 V	2.35 V ~ 2.7 V
Oscillator type	-	internal	internal
Operating temperature	-	-40°C ~ 85°C（TA）	-40°C ~ 85°C（TA）
Package/casing	-	100-LQFP	100-LQFP
Supplier device packaging	-	100-TQFP（14x14）	100-TQFP（14x14）
