FastCon-Twist
,
coloured
Pitch 1,27 mm /
UL-Style 20184
TYP :
JFCR28L-xxT127
one side laminated
Conductor: AWG 28, CU-braid tinned, 7x0,127 (7/36) 0,09mm²
Each pair of conductors are combined
with a beige conductor.
Colour combination complying to IEC :
brown, red, orange, yellow, green, blue,
violet, grey, white, black
Technical data
Temperature rating
Voltage raiting
Test voltage
Current rating
Conductor insulation
: - 20° C ~ + 105° C
: ≤ 300V / 50 Hz
Order-No.
: ≥ 2000V / 50 Hz eff. 1 min.
: ≤ 1.0 A / 20° C
: PVC- coloured
flame retardant VW-1
: PVC – transparent (1 side)
: UL VW-1
: 94 Shore (A) ± 3
: ≤ 228 Ω / km at 20° C
: ≥ 100 M Ω x km at 20° C
: ≤ 69 pF/m
: 100 Ω
: NE 3.8 / FE 1.5
: 5.4 ns/m
: 20184
JFCR28L-10T127
JFCR28L-14T127
JFCR28L-16T127
JFCR28L-20T127
Carrier foil
Flame retardant
Shore hardness
Conductor resistance
Insulation resistance
Capacity by 1 kHz
Impedance
Side to side cross talk %
Delay time
UL- STYLE
CHARACTERISTICS:
The cores of these
FastCon-Twist-flat
ribbon cables are
twisted in pairs (approx. 445mm), being however
separated at regular spacing (50.8mm). In this position
an insulation displacement connector can be connected.
The area of use is preferably there where opposing
influences of several flat ribbon cables or interference of
the signal through other disturbance factors are to be
expected. Furthermore, a lessening of the > Crosstalk <
compared to standard flat ribbon cables is achieved.
JFCR28L-24T127
JFCR28L-25T127
JFCR28L-26T127
JFCR28L-34T127
JFCR28L-37T127
JFCR28L-40T127
JFCR28L-50T127
JFCR28L-60T127
JFCR28L-64T127
Delivery program
Standard form of delivery: 30.5m on spools.
Number
pairs
5
7
8
10
12
12 +1
13
17
18 + 1
20
25
30
34
12,70 ± 0,38
17,78 ± 0,38
20,32 ± 0,38
25,40 ± 0,38
30,48 ± 0,38
31,75 ± 0,38
33,02 ± 0,38
43,18 ± 0,51
46,99 ± 0,51
50,80
±
0,51
63,50
±
0,51
76,20
±
0,51
81,28
±
0,51
11,43 ± 0,28
16,51 ± 0,28
19,05 ± 0,28
24,13± 0,28
29,21 ± 0,28
30,48 ± 0,28
31,75 ± 0,28
41,91 ± 0,38
45,72 ± 0,38
49,53
±
0,38
62,23
±
0,38
74,93
±
0,38
80,01
±
0,38
A
B
14
J.S.T Deutschland GmbH * Küferstraße 15 * D- 73650 Winterbach Tel.: 00 49 (0)71 81/ 40 07-0 Fax: - 21 *
Internet:
http://www.jst.de
e-Mail : customer.service@JST.de
Subject to changes
