PME294
• EMI suppressor, class Y1, metallized paper
• Safety capacitor, ceramic replacement
• 470 – 4700 pF, 440 VAC, +115 °C, test voltage 4000 VAC 60 s
• Self-extinguishing encapsulation. The
material is recognized according to
UL 94 V-0.
• Very precise positioning of the leads in
relation to the case giving efficient
utilisation of PC board space.
• Excellent self-healing properties.
Ensures long life even when subjected to
frequent overvoltages.
• High dU/dt capability.
• Good resistance to ionisation due to
impregnated dielectric.
• The capacitors meet the most stringent
IEC humidity class, 56 days.
• The impregnated paper ensures excellent
stability giving outstanding reliability
properties, especially in applications
having continuous operation.
TYPICAL APPLICATIONS
Safety capacitor for bridging of double or
reinforced insulation applications requiring
voltage test up to 4000 VAC 60 seconds.
PME294 can be left in place during this test.
CONSTRUCTION
Multi-layer metallized paper. Encapsulated
and impregnated in self-extinguishing material
meeting the requirements of UL 94V-0.
TECHNICAL DATA
Rated voltage
Capacitance range
Capacitance tolerance
Temperature range
Climatic category IEC
Approvals
Dissipation factor tan
δ
Insulation resistance
440 VAC 50/60 Hz
470 – 4700 pF
± 20%
–40 to +115 °C
40/115/56/B
S, N, D, FI, VDE, SEV, IMQ, UL, CSA
l = standard : 30 +5/-0 mm
option : short leads, tolerance +0/-1 mm
(standard 6 mm, code R06)
Other lead lengths on request
≤
1.3 % at 1 kHz
≥
12000 MΩ
Measured at 500 VDC after 60 s, +23°C
Tabulated self-resonance frequencies f
0
refer to 5 mm
lead length.
Recommended voltage:
≤
1500 VDC
The 100% screening factory test is carried out at
4000 VAC, 50 Hz, 2 s. The voltage level is selected to
meet the requirements in applicable equipment standards.
All electrical characteristics are checked after the test.
Resonance frequency
In DC applications
Test voltage between
terminals
ENVIRONMENTAL TEST DATA
Vibration
IEC 60068-2-6
Test Fc
IEC 60068-2-29
Test Eb
IEC 60068-2-20
Test Ta
EN 132400
IEC 60384-14 (1993)
EN 132400
IEC 60068-2-3
Test Ca
+40°C and 90 – 95% R.H.
56 days
3 directions at 2 hour each
10 – 500 Hz at 0.75 mm or 98 m/s
2
4000 bumps at 390 m/s
2
No visible damage
No open or short circuit
No visible damage
No open or short circuit
Wetting time < 1 s
Bump
Solderability
Solder globule method
Active flammability
Passive flammability
Humidity
165
PME294
ARTICLE TABLE
Quantity per package
reel
R30
R06 taped
Weight
pcs
pcs pcs
g
500
500
500
500
500
500
500
400
400
400
400
400
250
250
1000
1000
1000
1000
1000
1000
800
600
600
600
600
600
400
400
600
600
600
600
600
600
600
400
400
400
400
400
400
400
1.7
1.7
1.7
1.8
1.8
2.0
2.1
2.5
2.5
2.6
3.0
3.0
3.6
3.6
Approvals
f
O
MHz
64.0
59.0
54.0
49.0
46.0
43.0
40.0
37.0
33.0
31.0
30.0
27.0
24.0
22.0
Max
dU/dt
V/µs
2000
2000
2000
2000
2000
2000
2000
2000
2000
2000
2000
2000
2000
2000
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
√
Article code
1 st block
PME294RB3470M
PME294RB3560M
PME294RB3680M
PME294RB3820M
PME294RB4100M
PME294RB4120M
PME294RB4150M
PME294RB4180M
PME294RB4220M
PME294RB4250M
PME294RB4270M
PME294RB4330M
PME294RB4390M
PME294RB4470M
Capaci- Max dimensions
tance
in mm
pF
B
H
L
470
560
680
820
1000
1200
1500
1800
2200
2500
2700
3300
3900
4700
5.5
5.5
5.5
5.5
5.5
5.5
5.5
7.5
7.5
7.5
7.5
7.5
8.5
8.5
12.0
12.0
12.0
12.5
12.5
14.0
14.5
13.0
13.0
13.5
15.5
15.5
17.0
17.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
18.0
p
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
15.0
APPROVALS/REFERENCE DOCUMENTS
Country
S
N
D
Fl
VDE
SEV
IMQ
UL
= Sweden
= Norway
= Denmark
= Finland
= Germany
= Switzerland
= Italy
= USA
Specification
EN 132400
EN 132400
EN 132400
EN 132400
EN 132400
EN 132400
EN 132400
UL 1414 (U
R
= 250 VAC)
Double protection
C22.2. No 1
C22.2. No. 8
Approval reference
9902042/01
P99100386
308446
205353
91852
99.7 70114.01
V4715
E73869
53108
53108
•
•
•
•
•
MARKING
RIFA
RIFA article code
Rated capacitance
Rated voltage
Climatic category according to
IEC 60068-1, appendix A
• Passive flammability class
• Approval marks
• Manufacturing code (year, month)
CSA = Canada
ORDERING INFORMATION
Article code
1st block
See article table
Pos. 13, capacitance tolerance code:
M = ± 20%
2nd block
Options:
Short leads: e.g. 6 mm, add R06
in pos. 14–16.
Reel taped: Add T0 or T1 in pos. 14–15.
PACKING
Capacitors in standard design (lead length
30 mm) and with lead length 5 or 6 mm are
packed bulk in a box with dimensions 245
x 145 x 80 mm. Quantity/package as per
article table.
Reels with taped capacitors are packed 10
in a box with dimension 370 x 370 x 560
mm. The standard quantity/reel is for 360
mm reel. If 500 mm reel is required, it must
be specified when ordering and the
quantity is 2 x the given quantity.
P M E 2 9 4 R B 4 2
1 2
2
0 M
R
14
0
6
17 18 19 20
3 4 5 6 7 8 9 10 11 12 13
15 16
166
