T495X337M006ASE045 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> T495X337M006ASE045

T495X337M006ASE045: DescriptionTantalum Capacitor, Polarized, Tantalum (dry/solid), 6.3V, 20% +Tol, 20% -Tol, 330uF, Surface Mount, 2917, CHIP; CategoryPassive components capacitor; File Size716KB，8 Pages; ManufacturerKEMET; Websitehttp://www.kemet.com

Download Datasheet Parametric View All

T495X337M006ASE045 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	T495X337M006ASE045	-	-	View	Buy Now

T495X337M006ASE045 Overview

Tantalum Capacitor, Polarized, Tantalum (dry/solid), 6.3V, 20% +Tol, 20% -Tol, 330uF, Surface Mount, 2917, CHIP

T495X337M006ASE045 Parametric

Parameter Name	Attribute value
Maker	KEMET
package instruction	, 2917
Reach Compliance Code	unknow
ECCN code	EAR99
capacitance	330 µF
Capacitor type	TANTALUM CAPACITOR
dielectric materials	TANTALUM (DRY/SOLID)
leakage current	0.0198 mA
Installation features	SURFACE MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR, EMBOSSED PLASTIC, 7/13 INCH
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	6.3 V
ripple current	1723 mA
size code	2917
surface mount	YES
Delta tangent	0.08
Terminal shape	J BEND

Preview

Download Datasheet

View All

SOLID TANTALUM CHIP CAPACITORS

T495 SERIES—Low ESR, Surge Robust

FEATURES

•

Designed for very low ESR

High ripple current capability

High surge current capability

100% accelerated steady-state aging

100% Surge Current test

Meets or Exceeds EIA Standard 535BAAC

Available tested per DSCC Dwg. 95158

Operating Temperature: -55˚C to +125˚C

CATHODE (-) END

VIEW

SIDE VIEW

•

New Extended Values for Low ESR

Low Equivalent Series Inductance ( 2.5nH ESL)

Precision-molded, laser-marked case

Symmetrical, compliant terminations

Taped and reeled per EIA 481-1

RoHS Compliant & Leadfree Terminations (see

www.kemet.com for lead transition)

OUTLINE DRAWING

ANODE (+) END

VIEW

BOTTOM VIEW

Termination

cutout at

KEMETs

Option,

either end

STANDARD T495 DIMENSIONS

Millimeters (Inches)

Case Size

KEMET

EIA

3216-18

3528-21

6032-28

7343-31

7343-43

7260-38

3.2 ± 0.2

(.126 ± .008)

3.5 ± 0.2

(.138 ± .008)

6.0 ± 0.3

(.236 ± .012)

7.3 ± 0.3

(.287 ± .012)

7.3 ± 0.3

(.287 ± .012)

7.3 ± 0.3

(.287 ± .012)

1.6 ± 0.2

(.063 ± .008)

2.8 ± 0.2

(.110 ± .008)

3.2 ± 0.3

(.126 ± .12)

4.3 ± 0.3

(.169 ± .012)

4.3 ± 0.3

(.169 ± .012)

6.0 ± 0.3

(.236± .012)

1.6 ± 0.2

(.063 ± .008)

1.9 ± 0.1

(.075 ± .008)

2.5 ± 0.3

.098 ± .012)

2.8 ± 0.3

(.110 ± .012)

4.0 ± 0.3

(.157 ± .012)

3.6 ± 0.2

(.142 ± .008)

F ±0.1

1.2

(.047)

2.2

(.087)

2.2

(.087)

2.4

(.094)

2.4

(.094)

4.1

(.161)

S ±0.3

0.8

(.031)

0.8

(.031)

1.3

(.051)

1.3

(.051)

1.3

(.051)

1.3

(.051)

B ±0.15

(Ref) ±(.006)

0.4

(.016)

0.4

(.016)

0.5

(.020)

0.5

(.020)

0.5

(.020)

0.5

(.020)

X (Ref)

0.10 ± 0.10

(.004 ± .004)

0.10 ± 0.10

(.004 ± .004)

0.10 ± 0.10

(.004 ± .004)

0.10 ± 0.10

(.004 ± .004)

0.10 ± 0.10

(.004 ± .004)

0.10 ± 0.10

(.004 ± .004)

P (Ref)

0.4

(.016)

0.5

(.020)

0.9

(.0235)

0.9

(.0235)

1.7

(.067)

0.9

(.035)

R (Ref)

0.4

(.016)

1.0

(.039)

1.0

(.039)

1.0

(.039)

1.0

(.039)

1.0

(.039)

T (Ref)

0.13

(.005)

0.13

(.005)

0.13

(.005)

0.13

(.005)

0.13

(.005)

0.13

(.005)

A (Min)

1.4

(.055)

1.1

(.043)

3.1

(.122)

3.8

(.150)

3.8

(.150)

3.8

(.150)

G (Ref)

1.1

(.043)

1.8

(.071)

2.8

(.110)

3.5

(.138)

3.5

(.138)

3.5

(.138)

E (Ref)

1.3

(.051)

2.2

(.087)

2.4

(.094)

3.5

(.138)

3.5

(.138)

3.5

(.138)

Notes: 1. Metric dimensions govern

2. (Ref) Dimensions provided for reference only

LOW PROFILE T495 DIMENSIONS

Millimeters (Inches)

Case Size

KEMET

EIA

3528-12

7343.2

3.5 ± 0.2

(.138 ± .008)

7.3 ± 0.3

(.287 ± .012)

2.8 ± 0.2

(.110 ± .008)

4.3 ± 0.3

(.169 ± .012)

1.2

(.047)

2.0

(.079)

2.2

(.087)

2.4

(.094)

0.8

(.031)

1.3

(.051)

0.05

(.002)

0.05

(.002)

0.13

(.005)

0.13

(.005)

1.1

(.043)

3.8

(.150)

1.8

(.071)

3.5

(.138)

2.2

(.087)

3.5

(.138)

H Max.

F ±0.1

S ±0.3

X (Ref)

T (Ref)

A (Min)

G (Ref)

E (Ref)

Notes:

1. Metric dimensions govern.

2. (Ref) - Dimensions provided for reference only.

3. No dimensions provided for B, P or R because low profile cases do not have a bevel or a notch.

T495 Series - ORDERING INFORMATION

Tantalum

Series

T495 - Low ESR, Surge Robust

495

107

010

E100

E100 = ESR in Milliohmns = 100 mOhms

E1K5 = ESR in Ohms = 1.5 Ohms

4095 = DSCC Dwg. 95158 Designator

ESR

Case Size

B, C, D, T, V, X

Capacitance Picofarad Code

Capacitance Tolerance

M = ±20%, K = ±10%

T = 100% Tin (Sn) Plated

H = Tin/Lead (SnPb 5% Pb min)

G = Gold Plated

Lead Material

Failure Rate

A = Not Applicable

First two digits represent significant figures. Third digit

specifies number of zeros to follow.

Voltage

Solid Tantalum Surface Mount
