HIGH MEGOHM CHIP RESISTORS
RESISTORS CAPACITORS COILS DELAY LINES
HR SERIES
RoHS
Term.W is RoHS
compliant &
260°C process
compatible
107
HR SERIES - Industry’s Highest Value Chip Resistors!
RCD’s HR Series offers excellent stability for applications
requiring high ohmic values such as X-Ray equipment,
photomultipliers, inoization detectors and other circuits whoc
involve low signal detection or amplification. The excellent
performance of the HR Series also makes them ideal as an
input resistor in many high impedance voltage dividers.
Resistance Range: 1MΩ to 1TΩ (10
12
Ω)
Standard Tol: ±5% up to 500MΩ, ±10/20/50% >500MΩ
Choice of terminations: lead-free, tin/lead, or gold
Low cost, popular models available from stock
Excellent thermal, voltage, and environmental stabilty
SPECIFICATIONS
R C D Ty p e
HR0 4 0 2
HR0 5 0 3
HR0 6 0 3
HR0 8 0 5
HR1 2 0 6
HR1 2 1 0
HR2 0 1 0
HR2 5 1 2
1
Wa tta g e
.0 6 3 W
.0 3 W
.1W
.1 2 5 W
.2 5 W
.3 3 W
.5 W
1W
Ma x .
W o r k in g
Vo lta g e
50V
50V
50V
150V
200V
200V
200V
250V
Te rmin a tio n
Ty p e
W
S
W
W
W
W
W
W
R e s is t a n c e R a n g e
1
A ± .0 1 [ 2 .5 4 ]
1M - 470M
1M - 100M
1M - 10G
1M - 1T
1M - 1T
1M - 470M
1M - 470M
1M - 1G
.0 2
[.5 1 ]
.0 2 5
[.6 4 ]
.0 3 1
[1 .3 ]
.0 5
[1 .2 5 ]
.0 6 2
[1 .6 ]
.0 9 8
[2 .5 ]
.1 0 2
[2 .6 ]
.1 2 5
[3 .2 ]
D im e n s io n s
B ± .0 1 [ 2 .5 4 ]
.0 4
[1 .0 2 ]
.0 5
[1 .2 7 ]
.0 6 1
[1 .5 5 ]
.0 7 9
[2 .0 ]
.1 2 6
[3 .2 ]
.1 2 6
[3 .2 ]
.1 9 7
[5 .0 ]
.2 5
[6 .3 5 ]
H Ma x .
.0 1 8
[.4 5 ]
.0 2 4
[.6 ]
.0 2 2
[.5 5 ]
.0 2 6
[.6 6 ]
.0 2 6
[.6 6 ]
.0 2 6
[.6 6 ]
.0 2 6
[.6 6 ]
.0 2 8
[.7 ]
t Ty p .
.0 1
[.2 5 ]
.0 1 2
[.3 ]
.0 1 2
[0 .3 ]
.0 1 2
[0 .3 ]
.0 1 6
[0 .4 ]
.0 2
[0 .5 ]
.0 2
[0 .5 ]
.0 2
[0 .5 ]
Consult factory for resistance values outside of the standard range
TYPICAL PERFORMANCE CHARACTERISTICS
Voltage Coef. 5V-15V*
.01%/ V up to 10
8
Ω,
.05%/ V 10
9
Ω,
.2%/ V 10
10
Ω,
1%/ V 10
11
Ω,
300ppm<10
7
Ω,
500ppm10
7
- 10
9
Ω,
1000ppm >10
9
-10
10
Ω,
2000ppm >10
10
-10
11
Ω,
2500ppm >10
11
-10
12
Ω
0.5%
∆R
1%
∆R
0.5%
∆R
0.5%
∆R
0.25%
∆R
0.5%
∆R
1.0%
∆R
within tol. @ 50V 25°C
B
H
t
A
Termination Type W: Wraparound
(standard on all sizes except HR0503)
A
t
H
B
Termination Type S: Single Sided (HR0503)
Temperature Coef. (25-125°C)
Thermal Shock (-55° to +125°C)
Short Time Overload (2 x Max V, 5S)
Low Temp. Operation (-55°C, 1 hr)
High Temp. Exposure (125°C, 100 hrs)
Resistance to Solder Heat
Moisture Resistance
Load Life(1000 hrs.)
DC Resistance
* VC is based on HR1206 and larger (smaller sizes have higher VC’s)
DERATING CURVE
Resistors may be operated up to full rated power & voltage, with
consideration of mounting layout and environmental conditions
% OF RATED POWER
P/N DESIGNATION:
HR0805
RCD Type
Resis.Code:
2 digits & multiplier (105=1M, 106=10M,
107=100M, 1G0=1G, 10G=10G, 100G=100G, 1T0=1T
Tolerance Code:
N=50%, M=20%, K=10%, J=5%
Packaging:
B = Bulk, T = Tape & Reel
-
107 - J T
100
80
60
40
20
0
-55
40
50
60
70
80
90
100 110 120
AMBIENT TEMPERATURE (°C)
130
140
150
Termination:
W= Lead-free (Tin-plated), Q= Tin/Lead,
G= Gold plated
RCD Components Inc,
520 E.Industrial Park Dr, Manchester, NH, USA 03109
rcdcomponents.com
Tel: 603
-
669
-
0054 Fax: 603
-
669
-
5455 Email:sales@rcdcomponents.com
FA103A Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
