345728-9

Description
SOCKET, DIP28, IC SOCKET
CategoryThe connector    socket
File Size115KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

345728-9 Overview

SOCKET, DIP28, IC SOCKET

345728-9 Parametric

Parameter NameAttribute value
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
Contact to complete cooperationGOLD (30)
Contact completed and terminatedGOLD (10) OVER NICKEL
Device slot typeIC SOCKET
Type of equipment usedDIP28
Shell materialGLASS FILLED POLYETHYLENE POLYESTER
JESD-609 codee4
Manufacturer's serial number345728
Number of contacts28
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Socket/C ard Products
>
Product Feature Selector
> Product Details
345728-9 Product Details
Live Product Chat
Product Photo
DIP Sockets
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
345728-9
T E I nternal N umber: 3 4 5 7 2 8 - 9
Product Highlights:
l
DIP Socket
l
Number of Positions = 28
l
Row-to-Row Spacing = 15.24 mm
l
Through Hole C ontact Termination Type
l
Mount Style = Vertical
View all Features
Superseded
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= DIP Socket
l
Number of Positions
= 28
l
Profile = Standard
l
Frame Style
= Open
l
Leg Style
= Straight
Electrical Characteristics:
l
Insulation Resistance (M?) = 10,000
l
C ontact Resistance (m?) = 30
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.84 [0.112]
l
Solder Tail C ontact Plating = Gold (10) over Nickel
Body Related Features:
l
Row-to-Row Spacing (mm [in])
= 15.24 [0.600]
l
Mount Style
= Vertical
l
C enterline (mm [in])
= 2.54 [0.100]
Contact Related Features:
l
C ontact Termination Type
= Through Hole
l
C ontact Base Material
= Beryllium C opper
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Style
= Screw Machine
l
Mating C ontact Type
= Inner Spring
Configuration Related Features:
l
Height Above PC Board (mm [in])
= 2.80 [0.110]
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Conditions for Usage:
l
Temperature Range (?C ) = 105
Packaging Related Features:
l
Packaging Method
= Tube
Other:
l
Brand = AMP
